- Page 1 Günter & Hauer EN USER MANUAL GLASS CERAMIC ELECTRIC HOB CER 320 / 321 CER 640...
- Page 2 Thank you for your trust and choosing GÜNTER & HAUER products! This manual was developed to facilitate the use of the product. It will help you familiarize yourself with new appliance quickly. Make sure you have received it without any damage. If damage is detected, please contact the purchasing organization where you have bought appliance.
-
Page 3: Table Of Contents
CONTENT Safety instructions............4 Installation of the Hob..........7 Connection to the Power Supply........11 Product Overview............13 Use of the Electric Hob ..Specifications..............27... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Please read these instructions carefully. Only after that you will be able to use the appliance correctly. Keep the operating and installation instructions. If you transport the appliance to another person, transfer the manual with it. Check the condition of the electrical appliance after unpacking it. If it was damaged during transportation, do not connect the hob, but contact the service center or the organization where you have purchased the product. - Page 5 THE HOB IS HEATING UP Do not touch hot cooking zones. Keep children away from the hob. Never place flammable objects on the hob. Do not store flammable objects and aerosols in drawers under the hob. WET BOTTOM OF COOKWARE AND WET COOKING ZONE There is a danger of injuries! If there is any liquid between the bottom of the pan and the cooking zone when it heated, the steam pressure will increase.
- Page 6 ATTENTION! This appliance complies with the standards of safety and electromagnetic compatibility. However, persons with pacemakers are not recommended to approach the working appliance. It is also possible that people who use other types of electronic devices, such as hearing aids, may have unpleasant sensations near the hob.
-
Page 7: Installation Of The Hob
INSTALLATION OF THE HOB Ensure that your new product is properly installed and grounded by a qualified technician. Make sure to follow these instructions! 1. SAFETY INSTALLATION RULES The electrical installation must be carried out so that a device is available to disconnect the product from the AC network, which discon- nects all poles with a distance between contacts of at least 3 mm. - Page 8 W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) CER 320/321 290 50 min. CER 640 50 min. 4. HOB INSTALLATION PARAMETERS • The hob is designed to be installed into the countertop above the kitchen cabinet, the width of which is 600 mm or more.
- Page 9 • Furniture for installation must have covering, as well as adhesives, resistant to a temperature of 100 °C. Failure to meet this requirement may result in deformation of the surface or peeling of the covering. • The distance between the hob and the vertical walls of kitchen furniture located next to it should be at least 50 mm.
- Page 10 5. HOB FIXING After installation, secure the hob to the countertop by screwing the brackets to the sides of the appliance. Adjust the position of the brackets to suit the thickness of the countertop. Mounting bracket Screw ST 3.5*8 Countertop The lower part...
-
Page 11: Connection To The Power Supply
CONNECTION TO THE POWER SUPPLY Before connecting, make sure that the operating voltage of the hob power supply, marked on the technical data plate, corresponds to the voltage of the existing AC network. The plate with technical data is located on the lower part of the hob. Before connecting the cables to the power circuit, disconnect the voltage supply! The power supply voltage of the heating elements is 220~240 V... - Page 12 After installation, it is necessary to provide full protection against contact with conductive and insulated parts. • During installation make sure that the cable is not pinched and does not come into contact with sharp edges. • Cables of nearby connected electrical appliances must not touch hot cooking zones.
-
Page 13: Product Overview
After connecting to the power supply, all indicators will light up for a few seconds. 2. GENERAL OVERVIEW Top view CER 321 CER 320 1. max. 1800 W zone 1. max. 1000/2000 W zone 2. max. 1200W zone 2. max. 1200 W zone 3. - Page 14 1. max. 1800 W zone 2. max. 1200 W zone 3. max. 1800 W zone 4. max. 1200 W zone 5. Control panel Control panel CER 320 CER 321 CER 640 1. On/off button 2. Heat level slider / buttons 3. Timer 4.
- Page 15 Do not place any objects on the touch control panel (error messages may appear). Make sure that the control panel is always clean. If the control panel is dirty or has spilled liquid on it, error messages may appear, and it may be difficult for the panel to respond to the touch of your fingers.
-
Page 16: Use Of The Electric Hob
USE OF THE ELECTRIC HOB 1. START OF COOKING After connecting the hob, you will hear a single beep and all the indicators on the panel will light up for 1 second and then go off. This means that the hob has entered a standby mode. - Page 17 2. Turn off the cooking zone using the corresponding slider or button. Set the heat level to 0. Make sure the display shows "0". Switch off the hob by tapping the ON/OFF button. The hot surface indicator informs you that the cooking zone is still too hot to touch.
- Page 18 4. AUTO SHUTDOWN It is a safety function and is activated if you forget to turn off the cooking zone. The basic auto shutdown time is shown in the table below: 1 2 3 4 5 6 7 8 9 Heat level Working time before shutdown 8 8 8 4 4 4 2 2 2...
- Page 19 4. Touch the timer button again - another "0" will start flashing. 5. Use the corresponding sensor to set the desired time (eg - 2). The alarm is now set for 25 minutes. 6. After setting the alarm time, it will start counting down immediately. The display will show the remaining time.
- Page 20 6. Once the alarm time is set, it will start counting down immediately. The display will show the remaining time. NOTE: The indicator of the active cooking zone will be indicated by a red dot in the lower right corner of the heat level indicator. 7.
- Page 21 NOTE: To check the timer of other cooking zones, touch the corresponding cooking zone selection button. The display will show the time remaining until the timer of the current cooking zone is over. 5.4. Timer cancellation 1. Select the cooking zone on which you want to disable the timer.
- Page 22 COOKING TIPS Be careful when frying, as oil and fat heat up very quickly. At extremely high temperatures, oil and fat become flammable and may cause a serious ignition and/or burns. 1. COOKING GUIDE • When a dish is brought to a boil, reduce the heat level of the cooking zone.
- Page 23 4. Turn the steak only once during cooking. The exact cooking time depends on the thickness of the steak and how well done you want it to be. The time can vary from about 2 to 8 minutes per side. Press on the steak to determine the degree of its doneness -the firmer the feel of the meat, the more well-done it will be.
- Page 24 CLEANING AND MAINTENANCE What? How? Important! Daily dirt on 1. Disconnect the hob from • When the hob is the glass the power supply. disconnected from power (fingerprints, supply, the residual heat 2. Apply the glass cleaner food or water indicators will not light up, to the glass surface that stains).
- Page 25 1. Turn off the hob. Spilled liquid • If liquid is spilled on the on control sensors, the hob may beep 2. Remove the spilled panel. or switch off. liquid. • Make sure the sensor area 3. Wipe the touch control is wiped dry before areas with a clean damp switching the hob on again.
- Page 26 TROUBLESHOOTING Problem Possible causes Solution The hob does not No power supply. • Make sure the hob is turn on. connected to the power and switched on. Check the power supply in your home. • If you checked the power supply in the house or apartment, and the hob still does not turn on, contact...
-
Page 27: Specifications
SPECIFICATIONS CER 321 CER 640 Electric hob CER 320 Cooking Zones 220-240 V ~ 220-240 V ~ 220-240 V ~ Supply Voltage 50/60 Hz 50/60 Hz 50/60 Hz Electric Power 3000 W 3200 W 6000 W Hob Size D×W×H (mm) 290×50×520... - Page 28 Günter & hauer www.gunter-hauer.eu info@gunter-hauer.de...
