Günter & Hauer
EN
INSTRUCTION MANUAL
INDUCTION HOB
I 6 FB / I 6 FW / I 6 M / ID 33 / ID 33 W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I 6 FB and is the answer not in the manual?

Questions and answers

Related Manuals for Gunter & Hauer I 6 FB

Summary of Contents for Gunter & Hauer I 6 FB

  • Page 1 Günter & Hauer INSTRUCTION MANUAL INDUCTION HOB I 6 FB / I 6 FW / I 6 M / ID 33 / ID 33 W...
  • Page 2 Thank you for your trust and choosing GÜNTER & HAUER products! This manual was developed to facilitate the use of the product. It will help you familiarize yourself with new appliance quickly. Make sure you have received it without any damage. If damage is detected, please contact the purchasing organization where you have bought appliance.

  • Page 3: Table Of Contents

    CONTENT Safety instructions…………………......….. Product Overview……………..……………………....…..9 Using the Induction Hob………………………......15 Cooking Guidelines……………………….....………...21 Cleaning and Maintenance……...……….......……….24 Common Faults and Their Remedies......………25 Installation of the Hob………........………..27 Connecting to the Power Supply.……………......31 Specifications……………....………………....33...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Please read the following instructions carefully before using the appliance. Please save operating and installation manual for future use. If you hand over or sell this device to another person, please make sure that the manual was included with the device. Check the condition of the electrical appliance after unpacking it.
  • Page 5 OVERHEATED OIL AND FAT There is a fire hazard! Overheated oil and fat easily catch fire. Never leave fat or oil when they are heating unattended. In case of ignition of oil or fat, never pour water on fire. Extinguish it by covering the cookware with a lid or a plate.
  • Page 6 CRACKS ON THE SURFACE OF THE HOB There is a danger of electric shock! If the hob is broken or has a crack, disconnect the appliance from the electrical network. Contact the service center. If the indicator does not work, turn off the burner.
  • Page 7 REPAIR BY UNQUALIFIED PERSON There is a danger of electric shock! Unqualified repair is dangerous. Disconnect the faulty appliance from the electrical network. Contact the service center. Repair and replacement of damaged power cables must only be performed service center personnel with appropriate...
  • Page 8 CAUSES OF DAMAGE • A hard bottom of the dishes may scratch the hob. • Never place empty dishes on the burners. This may damage the hob. • Never place hot dishes on the control panel, display panel and frame of the hob.

  • Page 9: Product Overview

    After connecting to the power supply, all indicators will light up for a few seconds. 1.2. GENERAL OVERVIEW Top view of the hob I 6 FB / I 6 FW / I 6 M 1. Heating zone max. 1800 / 2100 W 2. Heating zone max. 1200 / 1500 W 3.
  • Page 10 1. Heating zone max. 1200 / 1500 W 2. Heating zone max. 1800 / 2100 W 3. Control panel Control panel I 6 FB / I 6 FW / I 6 M ID 33 / ID 33 W 1. ON/OFF switch 4. Child lock 2.
  • Page 11 The advantages of induction hobs Fast cooking: You will be surprised how fast you can cook on an induction hob. Food and liquids boil very quickly at high heat settings. Be sure to monitor the cooking process so that the food does not "escape" and evaporate. The power supply is proportional to the diameter of the dish: during induction cooking, only the part of the burner on which the dish is installed works.
  • Page 12 Induction heating technology means a radical change in traditional heating methods, because the heat is generated in the pan. Therefore, this technology has a number of advantages: • It takes less time to prepare food, since heat is generated directly in the pan, rather than indirectly through heating the glass surface.
  • Page 13 1.4. SUITABLE COOKWARE FOR INDUCTION HOB Only cookware made of ferromagnetic alloys can be used on the induction hob, for example: • steel dishes with enamel coating; • cast iron cookware; • special stainless steel cookware for induction hobs. To make sure that the cookware is suitable for the induction hob, check whether it is attracted by a magnet.
  • Page 14 In this case, the bottom of the cookware may melt and damage the glass surface of the hob. If this happens, turn off the burner and do not touch the pan. If the hob does not work after it has cooled down, contact the service center.

  • Page 15: Using The Induction Hob

    Do not use cookware with uneven edges or a curved base. Make sure that the bottom of your cookware is smooth and tightly fits the glass surface, and matches the size of the heating zone. Always place dishes in the center of the heating zone. Do not move the dishes on the surface, try to put down and put up them vertically.
  • Page 16 2. Place the appropriate cookware on the heating zone. Make sure that the surface of the cookware and the heating zone clean and dry. 3. Touch the sensor that controls the selected heating zone. 4. Set the desired heating level using the slider (to the left - decreases the level, to the right - increases it).
  • Page 17 2.3. «BOOSTER» FUNCTION Turning on the «Booster» function allows you to use the maximum power of the cooking surface (for example, for quick water heating). Activation of the «Booster» function 1. Choose a heating zone with the «Booster» function. 2. Touch the booster sensor on the control panel - "P". The heat level indicator will display the "P"...
  • Page 18 When the lock is activated, all sensors except ON/OFF are inactive. You can always turn off the hob in case of an emergency. But to continue using appliance, it should be unblocked. 2.5. AUTO-SHUTDOWN Auto-shutdown is a safety function and is activated if you forget to turn off the heating zone.
  • Page 19 4. Touch the timer sensor again - another "0" will start flashing. 5. Use the slider to set desired time (e.g., "2"). The alarm is now set for 25 minutes. After setting the alarm time, it will start counting down immediately. The display will show the remaining time.
  • Page 20 5. Use the slider to set the desired time (e.g., "2"). The alarm is now set for 25 minutes. 6. After setting the alarm time, it will start counting immediately. The display will show the remaining time. NOTE: The active heating zone indicator will be illuminated as a red dot in the lower right corner of the heat level indicator.

  • Page 21: Cooking Guidelines

    NOTE: To check the timer of other heating zones, touch the corresponding cooking zone selection sensor. The display will show the time remaining until the end of the timer of the current heating zone. 2.6.4. Timer cancellation 1. Select the heating zone on which you want to disable the timer.
  • Page 22 • Cooking some products, such as rice, by evaporating the liquid may require a higher level of heat to be used to ensure that the food is cooked in the recommended time. Steak To prepare juicy and aromatic steaks, try to act according to the following recommendations: •...
  • Page 23 3.2. SETTING THE HEATING LEVELS Heat level • Gentle heating of a small amount of food • Melting chocolate, butter and fast-burning products • Slow boiling • Slow heating • Reheating • Rapid simmering • Cooking rice • Cooking pancakes •...

  • Page 24: Cleaning And Maintenance

    4. CLEANING AND MAINTENANCE What? How? Important! Daily dirt on the glass 1. Unplug the hob from the power When the hob is disconnected from the power supply, there will be no ‘hot (fingerprints and stains supply. surface’ indication but the cooking left by food or water).

  • Page 25: Common Faults And Their Remedies

    5. COMMON FAULTS AND THEIR REMEDIES Problem Possible causes What to do The hob cannot be No power. Make sure that the hob is connected turned on to the power supply. Check the voltage supply in your home. If after checking the voltage supply problems in the house or apartment, the hob does not turn on, contact the...
  • Page 26 The hob or one of the Technical error. Memorize or write down the error code, disconnect the hob from the heating zones has suddenly switched off, a power supply and contact an beep signal sounds and an authorized service center. error code appears on the display (error format: one letter and 1 or 2 numbers,...

  • Page 27: Installation Of The Hob

    6. INSTALLATION OF THE HOB Ensure that your new product is properly installed and grounded by a qualified technician. Please follow this instructions! The warranty will not cover any malfunction caused by incorrect installation. 6.1. INSTALLATION SAFETY RULES The installation must be done in such a way that to provide a full disconnection of the product from the alternating current network.
  • Page 28 Make sure the sealant is spread around the countertop without gaps. It is not recommended to additionally use silicone sealants, as this may complicate the dismantling of the hob during maintenance. When disassembling the hob, it must be pushed out from below. Kitchen furniture in which the hob will be installed, as well as furniture located next to it, must be made of heat-resistant materials.
  • Page 29 6.3. PRODUCT AND MOUNTING HOLE DIMENSIONS (MM) Model I 6 FB / I 6 FW / I 6 M 50 min ID 33 / ID 33 W 50 min * dimensions may vary; up-to-date information is available on the manufacturer's official website: www.gunter-hauer.eu 6.4.
  • Page 30 In any case, make sure that the hob is well ventilated and that vents are not blocked. NOTE: The safe distance between the hob and the furniture cabinets is at least 760 mm. B(mm) A(mm) C(mm) 50 min 20 min Air inlet hole Air outlet hole: 5 mm...

  • Page 31: Connecting To The Power Supply

    7. CONNECTING TO THE POWER SUPPLY Before connecting, make sure that the operating voltage of the hob electrical supply, marked on the technical data plate, corresponds to the voltage of the AC network. The plate with technical data is located on the lower surface of the hob.
  • Page 32 WARNING! After installation, it is necessary to provide full protection against contact with conductive and insulated parts. Make sure that the cable does not get pinched and does not contact with • sharp edges during installation. Cables of nearby connected electrical appliances must not touch hot •...

  • Page 33: Specifications

    SPECIFICATIONS Induction hob I 6 FB / I 6 FW ID 33 I 6 M ID 33 W Heating zones Supply voltage 220-240 V~ 220-240 V~ 50/60 Hz 50/60 Hz Electric power 7200 W 3600 W Dimensions W×H×D, mm 590×60×520 290×60×520...
  • Page 34 GÜNTER & HAUER www.gunter-hauer.eu info@gunter-hauer.de...
