- Page 1 Günter & Hauer EN USER MANUAL BUILT-IN GAS HOB GT 642 / GT 642 W...
- Page 2 Thank you for your trust and choosing GÜNTER & HAUER products! This manual was developed to facilitate the use of the product. It will help you familiarize yourself with new appliance quickly. Make sure you have received it without any damage. If damage is detected, please contact the purchasing organization where you have bought appliance.
-
Page 3: Table Of Contents
CONTENT 1. Safety instructions............4 2. Installation of the Hob...........6 3. Use of Gas Hob............13 4. Cleaning and Maintenance.........16 5. Specifications..............17... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Before installation, please read the user manual carefully. It is very important that the manual is kept with the appliance for future reference in case of any questions. If you transfer or sell this appliance to another person, make sure that the instruction manual is also transferred with it. - Page 5 Unpacking Before using the appliance, remove all packaging material, including advertising labels and protective film, if there is one. After unpacking the appliance, make sure that it was not damaged, as well as that the power cable is in good condition. Otherwise, contact the store where you have purchased the hob before putting it into operation.
-
Page 6: Installation Of The Hob
INSTALLATION OF THE HOB The operations described below must be carried out by qualified personnel in accordance with current regulations and rules. Before performing any work on the appliance, it must be disconnected from the power supply network. If power is required to perform a particular operation, make sure that all necessary precautions are taken. - Page 7 After the installation is complete, check that the pipe connections are completely sealed, for this purpose use a soapy solution and in no case use a flame. CONNECTION TO THE ELECTRICAL NETWORK For the operation of this gas hob model, it is necessary to provide power from a single-phase electrical network with a voltage of 220 ~ 230 V.
- Page 8 L (live) – brown wire N (natural) – Blue wire С – power cable (earth) – yellow-green wire Replacement of the power cable must be carried out exclusively at the technical service center or by persons with the appropriate qualifications. If it is necessary to replace the power cable, you should use a H05VV-F or H05RR-F type cable with a cross section of 3X0.75 mm that complies with...
- Page 9 ADJUSTMENT OF THE MINIMUM FLAME To adjust the minimum level, do the following: 1. Light the flame in the burner following the instructions above. 2. Set the valve to the position of minimum flame. 3. Pull out the knobs. 4. Adjust the bypass valve (bypass screw) shown in the figure with a slotted screwdriver.
- Page 10 INSTALLATION This gas hob is designed to be built into furniture that is resistant to high temperatures. The walls of the furniture must withstand a temperature of at least 75°C plus the ambient temperature in accordance with European standards. It is necessary to avoid installing the appliance near flammable materials such as curtains, etc.
- Page 11 If the hob is installed with the oven, precautions should be taken and safety regulations must be observed. Special attention should be paid to ensure that the power cable and gas pipe do not come into contact with hot parts of the oven body.
- Page 12 ROOM FOR INSTALLATION This appliance is not connected to equipment for removing combustion products. In the room where the hob is installed, a system for removing combustion products must be provided. It can be either a cooker hood or a fan on a window or vent that turns on when the appliance is in use.
-
Page 13: Use Of Gas Hob
USE OF GAS HOB On the front part of the panel there are handles for controlling gas burners (knobs). The symbols shown next to the knobs indicate their compatibility with certain burners. Max. Heat Min. Heat Ignition Burner placement All built-in gas hobs, except for automatic electric ignition, are equipped with a special protective function «gas control». - Page 14 • If there is no power supply, the burner can be ignited without an electrical device; in this case, bring the flame to the burner, press the corresponding knob and turn it counter-clockwise to the maximum position. • When the power is applied after the hob is installed or after it is disconnected, it is a normal phenomenon that the spark plug is automatically activated.
- Page 15 After igniting the burner, make sure that the flame is stable. As soon as the liquid in the pot begins to boil, reduce the heat to the minimum needed to keep it simmering. Be careful when cooking with oil or fat, because if they are overheated, ignition is possible. Therefore, it is not recommended to cook food for a long time using kitchen stones, in ceramic cookware or on cast iron plates.
-
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE Before starting maintenance and cleaning work, disconnect the appliance from the power supply. Do not use steam cleaners to clean the hob. Enameled parts It is recommended to wash the enameled parts with a warm soapy solution or a mild detergent. -
Page 17: Specifications
SPECIFICATIONS Type of gas and Nozzle Valve bypass Burners Gas usage Efficiency diameter pressure diameter № Name mBar 1/100mm 1/100 mm G30 (butane) 28-30 mBar 0,75 G31 (propane) 37 mBar 0,75 Rapid Adjustable G20 (natural) 20 mBar 115-Y 0,75 G20 (natural) 13 mBar 0,75 G30 (butane) 28-30 mBar 0,55... - Page 18 Günter & Hauer www.gunter-hauer.eu info@gunter-hauer.de...
