- Page 1 MGate 5105-MB-EIP Series Quick Installation Guide Version 2.4, October 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802051050013 *1802051050013*...
-
Page 2: Package Checklist
Overview The MGate 5105-MB-EIP is an industrial Ethernet gateway for Modbus RTU/ASCII/TCP and EtherNet/IP network communications. Package Checklist Before installing the MGate 5105-MB-EIP, verify that the package contains the following items: • 1 MGate 5105-MB-EIP gateway • 1 serial cable: CBL-RJ45F9-150 •... -
Page 3: Hardware Introduction
Hardware Introduction LED Indicators Color Description Power is off or a fault condition exists Steady: Power is on, and the MGate is functioning normally Green Blinking: The MGate has been located by the MGate Manager’s Location function Ready Steady: Power is on, and the MGate is booting up Blinking slowly: Indicates an IP conflict, or the DHCP or BOOTP server is not responding properly Flashing quickly: microSD card failed... -
Page 4: Reset Button
Dimensions Unit: mm (inch) Reset Button Restore the MGate to factory default settings by using a pointed object (such as a straightened paper clip) to hold the reset button down until the Ready LED stops blinking (approx. five seconds). Pull-high, Pull-low, and Terminator for RS-485 Remove the MGate 5105-MB-EIP’s top cover and you will find DIP switches to adjust each serial port’s pull-high resistor, pull-low resistor, and terminator. -
Page 5: Software Installation Information
The following figure illustrates the two mounting options: Software Installation Information Please download the user's manual and Device Search Utility (DSU) from Moxa’s website: www.moxa.com Refer to the user’s manual for additional details on using the DSU. The MGate 5105-MB-EIP also supports login via a web browser. Default IP address: 192.168.127.254 Default account: admin Default password: moxa... -
Page 6: Specifications
Power Input and Relay Output Pinouts Shielded Power Power N.O. Common N.C. Power Power Ground Input 2 Input 2 Input 1 Input 1 Specifications Power Requirements Power Input 12 to 48 VDC Power Consumption 455 mA max. Operating Temperature Standard models: 0 to 60°C (32 to 140°F) Wide temp. - Page 7 d. Provisions shall be made, either in the equipment or external to the equipment, to prevent the peak-rated voltage being exceeded by transient disturbances of more than 140% of the peak-rated voltage. Terminal block (plug matched with socket): rated at 300 V, 15 A, 105°C, 12 to 24 AWG (4.0 to 0.205 mm ) wire size, torque value 4.5 lb-in (0.509 N-m).
