Bradley 5426-11 Quick Start Manual

 Model 5426-11 — Surface-Mounted, No Logo
Coreless Jumbo Dual Roll Tissue Dispenser
Product Materials
CABINET: 22 gauge stainless steel with exposed surfaces in architectural satin
finish. Welded construction with burr-free edges. Furnished with refill-indicator
viewing slots.
Capacity
Toilet Tissue Dispensers-Two coreless jumbo toilet tissue rolls with a maximum
diameter of 9" and a width of 3-3/4". Refill indicator slot reveals tissue level.
Operation
Insert toilet paper by lining up the center of the roll with indicator slots and push
the coreless rolls up inside the cavity.
Installation
Verify all rough-in dimensions prior to installation. Secure with mounting screws
(not included) at holes provided.
Guide Specification
Surface mount unit shall include dual jumbo coreless toilet tissue dis pens er and
be fabricated of stainless steel with seam less exposed surfaces in satin finish.
Shall be constructed of 22 gauge SS and have a refill indicator viewing slot.
Overall dimensions: 21" W x 6" H x 6-3/16" D.
ADA Compliant
Consult local and national accessibility codes for proper
installation guidelines.
Conformity and compliance to local and national codes is
the responsibility of the installer.
Page 1 of 2
This information is subject to change without notice.
Bradley_TPDispenser_5426-1195
2/20/2017
Coreless Jumbo Dual Roll Toilet Tissue Dispenser
5426-1195
© 2017 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
800 BRADLEY (800 272 3539) +1 262 251 6000
bradleycorp.com
