Section D - Power Control System (PCS)
5. For sites with aggregate export power limit (PEL) enabled, indicate this with the label. Record the maximum operating kW value
on the label.
The label is provided as part of the IQ System Controller Literature kit.
AGGREGATE POWER EXPORT LIMIT LABEL:
Recommended area to affix: On the dead front, below the transparent breaker, position the cover for the main breaker.
6. For sites with IQ Battery Oversubscription enabled, indicate this with the label.
Record the maximum operating current value on the label.
The label is provided as part of the IQ System Controller Literature kit.
IQ BATTERY OVERSUBSCRIPTION LABEL
Recommended area to affix: On the dead front, below the transparent breaker, position the cover for the main breaker.
7. For sites with PCS enabled, indicate with following label on the wired current transformers.
When using IQ Meter Collar, the label is already present on the product and need not be applied.
The label is provided as part of the IQ System Controller Literature kit.
CT LABEL
Recommended area to affix: On the CTs. When using the IQ Meter Collar for consumption metering, this label is already present
and need not be applied to the IQ Meter Collar.
8. Use the site configurations section in the Enphase Installer App to define the PCS settings for the site.
34
125.00 +/- 0.3 mm
THE MAXIMUM POWER BACKFED BY THE SOLAR SYSTEM TO THE
UTILITY SERVICE MAY BE CONTROLLED ELECTRONICALLY. REFER
TO MANUFACTURER'S INSTRUCTIONS FOR MORE INFORMATION.
PCS CONTROLLED POWER SETTING:
DATE OF CALCULATION AND SETTING:
150.00 +/- 0.3 mm
THE NAMEPLATE (CHARGE/DISCHARGE POWER) OF THE IQ BATTERY 5P
UNITS PROTECTED BY BREAKERS ON THIS PRODUCT ARE SET ELECTRONICALLY.
REFER TO MANUFACTURER'S INSTRUCTIONS FOR MORE INFORMATION.
PCS CONTROLLED CURRENT SETTINGS FOR IQ BATTERY BREAKER:
PCS CONTROLLED CURRENT SETTINGS FOR DER BREAKER:
DATE OF CALCULATION AND SETTING:
30.0 +/- 0.3 mm
kW
AMPS
AMPS
