Section A - Mounting the product

Step 1:

Recommended clearance

This product must be installed with clearance at the left, right, top,

bottom, and front of the product, as shown in the figure.

Follow all local standards and regulations related to mounting an

IQ System Controller.

6 i n

3 6

6 i n

i n

6 i n

3 6 i

1 9 . 7

i n

9 . 7

NOTE: Follow all local standards and regulations related to mounting.

IQ System Controller 3M quick install guide
