Section C - Wiring
Aux wiring: System Shutdown Switch
NOTE: An improved SSD header kit allows for the co-location of SSD wiring and AC power
conductors in a single conduit, eliminating the need for separate conduits.
WARNING: To prevent water ingress, do not use the top
conduit entry on System Shutdown Switch.
IQ System Controller 3M quick install guide
21
