enphase IQ System Controller 3M Quick Install Manual page 2

The new third-generation variant of the IQ System Controller
features IQ System Controller 3M (SC200D111CMC1US01).
IQ System Controller 3M is not interchangeable with
IQ System Controller 3 and IQ System Controller 3G in the field.
The IQ System Controller 3M supports one PV and one IQ Battery 5P
port. It supports additional IQ Battery 5P or PV on the third DER port.
To install the IQ System Controller and wall-mount bracket, read and
follow all warnings and instructions in this guide and documents at
https:/ /enphase.com/support.
Enphase field engineering team can provide a digital copy of
production line test results upon request with the equipment's serial
number. Requests can be raised through
http:/ /www.enphase.com/support.
Safety warnings are listed at the end of this guide. These instructions
are not meant to be a complete explanation of how to design and
install an energy storage system. All installations must comply with
the national and local electrical codes and standards. Only qualified
electricians shall install, troubleshoot, or replace the
IQ System Controller 3M.
The Enphase IQ System Controller 3M supports a 240 V L-L/
120 V L-N split-phase supply (i.e., two phases that have a phase
angle of 180°). For use with grid supplies other than a split-phase,
an appropriate external transformer must be provided to convert
the incoming supply from the utility to a split-phase supply.
Sizing of the transformer must be done per system requirements
and must be sufficient to cover the load and distributed energy
resource (DER) requirements. Local and national electrical
codes, as well as utility interconnection requirements, must
be met by the installer when using an external transformer.
WARNING: Before installing, it is crucial to carefully
follow the instructions provided. To guarantee maximum
reliability and comply with warranty requirements, it
is essential to install the IQ System Controller according
to the instructions in this guide.
2 IQ System Controller 3M quick install guide
