Kodak PIXPRO FZ152, PIXPRO FZ152-BK Manual
- User manual (90 pages) ,
- User manual (90 pages)
Advertisement
Product Views
See Fig. 1
| 1 | Micro USB Port | 12 | Display Button/Arrow Button (Up) |
| 2 | Zoom Lever | 13 | Flash Button/Arrow Button (Right) |
| 3 | Shutter Button | 14 | SET Button |
| 4 | Power Button | 15 | Playback Button |
| 5 | AF Assist Beam/Self-Timer Lamp | 16 | Battery Cover |
| 6 | Flash Lamp | 17 | Delete Button/Arrow Button (Down) |
| 7 | Lens | 18 | Menu Button |
| 8 | Microphone | 19 | Macro Button/Self-Timer Button/ Arrow Button (Left) |
| 9 | Indicator Lamp | 20 | Tripod Socket |
| 10 | Fast Video Recording Button | 21 | Speaker |
| 11 | Mode Button | 22 | LCD |
Insert the Battery and the Memory Card
See Fig. 2
- Open the battery cover.
- Insert the battery into the battery compartment.
- Insert the memory card into the slot.
- Close the battery cover.
Setting the Language/Date/Time
See Fig. 3
- Press the power button to turn the camera on and the language menu will appear. Use the up/down/left/right buttons to select a language, and press the
![]()
button to confirm the language. - Use the up/down/left/right buttons again to set the date and time, and press the
![]()
button to confirm.
Taking a Picture
- Hold the camera securely.
- Use the zoom lever to select Tele or Wide position to zoom in or out on your subject.
![]()
- Press the shutter button half way to focus on the subject. when the focus frame turns green, press the shutter button completely down to take the picture.
Using the Mode Button
This camera provides a convenient mode selection button that allows you to manually switch among different camera settings with ease. Available modes are listed below:
 | Auto Mode |  | Movie Mode |
 | Manual Mode |  | Panorama Mode |
 | Portrait Mode |  | Scene Mode |
Using the Fast Video Recording Button
In shooting mode, press the
button to begin recording a video. After recording, press the button again to stop recording. The camera will store the video and return to the shooting screen.
Using the Menu Button
In each mode, press the
button to access the "Easy Menu". Press the
buttons to move among options, then press the
button to make a selection. Choosing the
within this list will provide access to the "Full Menu":
| Shooting Mode | |
 | Shoot Settings |
 | General Settings |
 | Connection Settings |
 | File Settings |
| Playback Mode | |
 | Playback Settings |
| General Settings |
| Connection Settings |
| File Settings |
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
kodakpixpro.com
