Phanteks GLACIER ONE Series Manual

Package Contents

GLACIER ONE 240 MP

• Infinity Mirror Cap
• 240 Radiator
• 2x 120mm MP Fans

GLACIER ONE 240 MPH

• Infinity Mirror Cap
• 240 Radiator
• 2x 120mrn MP Fans
• 2x D-RGB Halos Fan Frames

GLACIER ONE 280 MP

• Infinity Mirror Cap
• 280 Radiator
• 2x 140mm MP Fans

GLACIER ONE 360 MP

• Infinity Mirror Cap
• 360 Radiator
• 3x 120mm MP Fans

GLACIER ONE 360 MPH

• Infinity Mirror Cap
• 360 Radiator
• 3x 120mm MP Fans
• 3x D-RGB Halos Fan Frames

Accessories (for all models)

Motherboard preparation

(Follow instructions for the corresponding socket)

AMD Socket AM4

1. Remove the stock mounting brackets

2. Secure the 4x AM4 Stand-offs to the motherboard


INTEL Socket / 1200 / 1366

1. Prepare the Intel Backplate for the correct socket

2. Secure the 4x 115x/1200/1366 Stand-offs to the motherboard and Intel Backplate


INTEL Socket 2011 G 2066

1. Secure the 4x Intel 2011 /2066 Stand-offs to the motherboard


Installing the pump block

1. This step is for AMD AM4 socket only
   (for Intel socket installation, go to step 3B)
   • Remove the Intel bracket from the pump

     1. Push the Intel bracket in
     2. Rotate to loosen
     3. pull the bracket off
   • Secure the AMD AM4 Bracket to the pump

     4. push the AMD bracket in
     5. rotate to fasten the bracket
2. Secure the pump unit to the stand-offs on the motherboard with the 4x Thumb Nuts


PTO TIP: The thermal compound is pre-applied. More thermal compound is included for PRO future installations

Mount the radiator and fans

We recommend to install the fans to the radiator before mounting it into the chassis.

3 Types of screws are included to mount the radiator and the fans in different options:

Option A:

Option B:

Option C (MPH models only):

Install Infinity Mirror Cap and Tube Clips

1. The Infinity Mirror Cap simply snaps into place via strong magnets. Make sure the D-RGB cable stays clear from the Thumb Nut.

   PTO TIP: Fan cables can be routed through the middle of the Tube Clips

2. OPTIONAL: Install the (3x) included Tube Clips for a tidy tube routing. Simply snap the clips on the tubes.

Connect cables
