Phanteks GLACIER ONE M25 G2 Installation Manual
Phanteks GLACIER ONE M25 G2 Installation Manual

Phanteks GLACIER ONE M25 G2 Installation Manual

Advertisement

Quick Links

THIS MANUAL IS FOR THE FOLLOWING MODELS
Dieses Handbuch gilt für die folgenden Modelle
此手册适用于以下型号
manual es para los siguientes modelos
|
PH-GO360M25G2_DBK02
Glacier One M25-360 G2
PH-GO360M25G2_DWT02
Glacier One M25-360 G2
LEGEND
Legende | Légende | Leyenda | 说明
Remove | Entfernen | Retirer | Eliminar | 移除
Install | Installieren | Installer | Instalar | 安装
Loosen | Lösen | Desserrer | Aflojar | 拧松
Phanteks will not take responsibility for any damages incurred due to incorrect installation or
EN
usage of this product.
Phanteks übernimmt keine Verantwortung für Schäden, die durch eine falsche Installation oder
DE
Verwendung dieses Produkts entstehen.
Phanteks décline toute responsabilité en cas de dommages résultant d'une installation ou
FR
d'une utilisation incorrecte de ce produit.
Phanteks no se responsabilizará de los daños ocasionados por la instalación o el uso
ES
incorrectos de este producto.
Phanteks 不会对安装中失误造成的任何损失负责, 请仔细阅读本手册。
CN
SCOPE OF DELIVERY
Lieferumfang | Contenu de la livraison | Alcance de la entrega | 供货范围
GLACIER ONE M25 GEN2
Radiator
M25 Gen2 Fans
|
Ce manuel concerne les modèles suivants
Black
White
Installationsanleitung | Guide d'installation | Guía de instalación | 安装指南
|
Este
MOUNTING HARDWARE
Montagezubehör | Le matériel de montage | Accesorios de montaje | 安装硬件
AM4 | AM5 Stand-off
x4
Intel 2011 | 2066 Stand-off
x4
Intel 115X | 1200 Stand-off
x4
TR4 Stand-off
360 Models only
x4
Intel 1700 Stand-off
x4
Thumb Nuts
x4
Intel 115X | 1200 | 1700
Backplate
x1
ACCESSORIES
Zubehör | Accessoires | Accesorios | 配件
LINQ6 Extension Cable
500 mm
x1
LINQ6 Adapter
500 mm
x1
INSTALLATION GUIDE
Ausführung | Version | Versión | 版本 | Version 1.1
Online Manual
Online-Handbuch
Manuel en ligne
Manual en Linea
在线手册
Radiator Screws
6 mm | 6-32 UNC
x12¹
Radiator Screws
30 mm | 6-32 UNC
x12¹
Tube Clips
x3
SATA to 2-PIN Pump
Adapter
x1
PH-NDC Thermal
Compound
x1
AMD AM4 | AM5 Bracket
Intel bracket is pre-installed
x1
AMD TR4 Bracket
360 Models only
x1
Screw Cover Corners
Left | Right
x2¹
|
x2¹
Screw Cover Bridge
x4¹
¹IMPORTANCE NOTICE
Quantity may vary on radiator size.
Die Menge kann je nach Heizkörpergröße variieren.
La quantité peut varier selon la taille du radiateur.
La cantidad puede variar según el tamaño del radiador.
数量可能根据散热器尺寸而变化。
01
| www.phanteks.com
