Harman Kardon ENCHANT Manual

WHAT'S IN THE BOX


* Power cord quantity and plug type vary by regions.

POWER ON

POWER ON

WI-FI SETUP


On an Android™ or iOS device, add the speaker to your home Wi-Fi network through the Harman Kardon One app. Follow the app instructions to complete setup. * Some features require subscriptions or services not available in all countries.
WI-FI SETUP
www.apple.com
play.google.com

MUSIC STREAMING


Stream music through the Harman Kardon One app or supported music services.

BLUETOOTH PAIRING

Music streaming through Bluetooth will pause when you start music streaming through Wi-Fi.
BLUETOOTH PAIRING

BUTTON CONTROL

BUTTON CONTROL

FACTORY RESET

FACTORY RESET

TECH SPEC

General Specification

  • Model: Enchant Speaker
  • Power supply: 100 – 240 V AC, ~ 50/60 Hz
  • Total speaker power output (RMS @ THD 1%): 90 W
  • Transducer: 1x 25 mm tweeter, 1x 92 mm woofer, 2x 50 mm full-range drivers
  • Networked standby power: < 2.0 W
  • Operating temperature: 0°C – 45°C

Audio Specification

  • Frequency response: 55 Hz – 20 kHz (-6 dB)

Wireless specification

  • Bluetooth version: 5.3
  • Bluetooth profile: A2DP 1.3.2, AVRCP 1.5
  • Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
  • Bluetooth transmitter power: < 13 dBm (EIRP)
  • Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
  • 2.4G Wi-Fi transmitter frequency range: 2412 – 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
  • 2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
  • 5G Wi-Fi transmitter frequency range: 5.15 – 5.35 GHz, 5.470 – 5.725 GHz, 5.725 – 5.825 GHz
  • 5G Wi-Fi transmitter power: 5.15 – 5.25 GHz < 23 dBm, 5.25 – 5.35 GHz < 20 dBm, 5.470 – 5.725 GHz < 20 dBm, 5.725 – 5.825 GHz < 14 dBm

Dimensions

  • Dimensions (W x H x D): 163 x 205 x 163 mm / 6.4" x 8.0" x 6.4"
  • Weight: 2.16 kg / 4.76 lbs
  • Packaging dimensions (W x H X D): 212 x 318 x 212 mm / 8.35" x 12.52" x 8.35"
  • Packaging weight: 3.05 kg / 6.72 lbs

Enchant Speaker complies with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013 as a networked equipment.

  • Bluetooth/Wi-Fi wireless mode Consumers can stream Bluetooth/Wi-Fi audio to the speaker. When the product is connected through Bluetooth/Wi-Fi, the Bluetooth/Wi-Fi connection must remain active at all times to ensure proper operation. The product will enter networked standby after 10 minutes without operation. The power consumption in standby mode is less than 2.0 Watts, after which it can be re-activated via Bluetooth/Wi-Fi connection.
  • Bluetooth/Wi-Fi disconnection mode The product will enter standby mode after 10 minutes without operation. The power consumption in standby mode is less than 0.5 Watts.
