OLIGHT PL-MINI VALKYRIE 2, AM-OL-PLmini 2-DT Manual

Table of Contents

Contents

1 INSIDE THE BOX
2 SPECIFICATIONS
3 CHARGING
4 ADJUSTABLE RAIL
5 OPERATION
6 NOTICE
7 WARRANTY
8 Documents / Resources
- 8.1 References
- 8.2 Download manual

INSIDE THE BOX

PL-MINI VALKYRIE 2, Wrench, 1913 and Screw, MCC Special (Magnetic Charging Cable)

SPECIFICATIONS

CHARGING

Before your first use, fully charge the light with the supplied magnetic charging cable. When the battery level is low while turned on, the side indicator will turn red. Please charge again at that time.
CHARGING - Step 1

Connect the provided magnetic charging cable to a USB power source or any USB port.
Connect the round magnetic end of the charger to the magnetic port on the bottom of the PL-Mini 2.
The indicator on the charging cable is red while charging and will turn green when fully charged.

ADJUSTABLE RAIL

Slide the rail adapter back and forth freely to fix the light in the desired position as you need.
ADJUSTABLE RAIL

OPERATION

The ambidextrous switch on the PL-MINI 2 can only be pressed down to activate the light. Pressing the side or front of the switch will not turn it on.

Momentary ON: Press and hold down either switch for momentary on. The light will stay on until the switch is released.

On/Off: Single click either switch for constant on. Single click again to turn the light off.

NOTICE

Fully charge the battery before storing the light for a long period of time.
Please keep the charging port clean. Wipe any dust off before the charge.
The LED light will work for one minute at the top output mode and gradually step down to 60 lumens within 10 minutes.
The two triggers can only be activated by pushing downward. Pushing forward or on the side of the switch will not activate the light.
Always keep the LED light firmly attached to the firearm to protect from any damage or misuse.
The PL-MINI 2 can only charge using the included magnetic charging cable (The same magnetic charging cable as PL-MINI). This cable is proprietary for this LED light and cannot be used with any other Olight products.
The Glock adapter labelled GL is already installed, which can be directly installed on Glock handguns. For firearms using Picatinny (mil-std-1913) rails, the user needs to replace the GL adapter with the included 1913 adapter using the screws and socket head wrench provided in the package.

WARRANTY

Within 30 days of purchase: Contact the original seller for repair or replacement.

Within 2 years of purchase: Contact Olight for repair or replacement.

This warranty does not cover normal wear and tear, modifications, misuse, disintegrations, negligence, accidents, improper maintenance, or repair by anyone other than an Authorized retailer or Olight itself.

EU-Declaration of Conformity can be found here CE:
https://olightworld.com/ec-declaration

USA Customer Support cs@olightstore.com
Global Customer Support customer-service@olightworld.com

Visit www.olightworld.com to see our complete product line of portable illumination tools.

Dongguan Olight E-Commerce Technology Co., Ltd
4th Floor, Building 4, Kegu Industrial Park, No 6 Zhongnan Road, Changan Town, Dongguan City, Guangdong, China.
