Phanteks XT View - PC Case Manual

THIS MANUAL IS FOR THE FOLLOWING MODELS

Phanteks will not take responsibility for any damages incurred due to incorrect installation or usage of this product.

SCOPE OF DELIVERY

FRONT I/O

Turn off LEDs Press and hold the MODE button for two seconds to turn off LEDs, press again to turn it ON

CLEARANCE

CPU Cooler 184 mm Height
GPU 415 mm Length
GPU 184 mm Width
Power Supply 270 mm Length
360 Radiator 415 x 138 x 60 mm Top
120 Radiator 132 x 170 mm Rear

PANEL REMOVAL

1. LEFT SIDE PANEL

2. RIGHT SIDE PANEL

3. TOP DUST FILTER


Supports up to a total of 9x 120 mm

HARDWARE INSTALLATION

MAINBOARD

POWER SUPPLY

STORAGE BRACKET

TRIPLE SSD BRACKET

CABLES

D-RGB CABLES

D-RGB control buttons are deactivated if connected to a mainboard

Expand with more D-RGB products

Optional | Sync lighting to the mainboard

OPTIONAL UPGRADE

Gen4 Vertical GPU bracket PH-PGPUKT4.0 or PH-VGPUKT4.0_03
