- Page 1 USER MANUAL VIA AI Transforma Model 1 Fanless low-power platform for Edge AI applications with MediaTek Genio 700 Octa-Core processor 1.00-04102024...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 VIA AI Transforma Model 1 User Manual Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. •...
- Page 4 VIA AI Transforma Model 1 User Manual Packing List • VIA AI Transforma Model 1 board with heatsink • 4 plastic spacers • 5V 8A AC-to-DC power adapter and cable for US and EU Ordering Information Part Number SoC Frequency Description 10GRK22S000A0 MediaTek Genio 700...
-
Page 5: Table Of Contents
VIA AI Transforma Model 1 User Manual Table of Contents Product Overview ............................1 Key Features ............................1 Product Specifications ........................... 1 Layout Diagram ............................. 4 Product Dimensions ..........................5 I/O Spacing ............................6 Height Distribution ..........................7 M.2 Slots and Standoffs Dimensions ..................... 8 On-Board I/O Pin Descriptions and Functionality ................... - Page 6 VIA AI Transforma Model 1 User Manual List of Figures Figure 01: VIA AI Transforma Model 1 board top I/O ................... 4 Figure 02: VIA AI Transforma Model 1 board bottom I/O ..................4 Figure 03: VIA AI Transforma Model 1 board front coastline I/O ................. 4 Figure 04: VIA AI Transforma Model 1 board back coastline I/O ................
- Page 7 VIA AI Transforma Model 1 User Manual List of Tables Table 01: 40-pin Raspberry Pi-type GPIO header 'J6' pinouts................9 Table 02: Watchdog jumper 'JWDG' pins and signals ..................12 Table 03: Watchdog jumper 'JWDG' settings ....................12 Table 04: Auto Power ON jumper 'J_APO' pins and signals ................
-
Page 8: Product Overview
VIA AI Transforma Model 1 User Manual 1. Product Overview Introducing the VIA AI Transforma Model 1, a powerful and versatile solution designed for a wide range of applications. This AI board is equipped with cutting-edge technology to meet the demands of modern computing and AI processing. - Page 9 VIA AI Transforma Model 1 User Manual Storage • 16GB eMMC flash memory Graphics • ARM Mali-G57 MC3 High Performance GPU • Graphics engine supporting OpenGL® ES 1.1/2.0/3.2, OpenCL ES 2.2, and Vulkan 1.0/1.1 hardware acceleration • Supports H.265 and H.264 video decoding up to 4K@75fps and video encoding up to 4K@30fps AI Processor •...
- Page 10 VIA AI Transforma Model 1 User Manual Front I/O • 1 x HDMI port • 2 x USB 2.0 ports • 2 x USB 3.1 Type A ports • 1 x USB 3.1 Type C port (supports maximum 15W output, OTG and DisplayPort Alt mode) •...
-
Page 11: Layout Diagram
VIA AI Transforma Model 1 User Manual 1.3 Layout Diagram 40-pin GPIO Micro USB for debugging LPDDR4X RAM Audio Jack GLAN Power Button MediaTek Genio 700 SoC with LED Software LPDDR4X RAM Upgrade Button 4-lane MIPI DSI eMMC HDMI 4-lane MIPI CSI 2 x USB 2.0 MicroSD 2 x USB 3.1 Type A... -
Page 12: Product Dimensions
VIA AI Transforma Model 1 User Manual Gigabit Ethernet Micro SD Card Slot Figure 04: VIA AI Transforma Model 1 board back coastline I/O 1.4 Product Dimensions 146mm 3.5mm 3.5mm 139mm Figure 05: Dimensions of the VIA AI Transforma Model 1 board (top I/O) 133.46mm 120.71mm 107.96mm... -
Page 13: I/O Spacing
VIA AI Transforma Model 1 User Manual 31.31mm 86.25 mm Figure 07: External I/O dimensions of the VIA AI Transforma Model 1 board (back coastline I/O) 1.5 I/O Spacing 5.85mm 2.89mm 9.8mm 4.88mm 8.33mm 8.79mm 5.88mm 3.19mm 5.24mm 7.13mm Figure 08: I/O spacing of the VIA AI Transforma Model 1 board (front coastline I/O) 53.3mm 38.61mm 23.34mm... -
Page 14: Height Distribution
VIA AI Transforma Model 1 User Manual 1.6 Height Distribution 13.3mm 8.4mm 8.4mm 16mm 16.4mm 16mm 16mm Figure 11: Height distribution of the VIA AI Transforma Model 1 board (top I/O) 1.4mm Figure 12: Height distribution of the VIA AI Transforma Model 1 board (bottom I/O) -
Page 15: Slots And Standoffs Dimensions
VIA AI Transforma Model 1 User Manual 1.7 M.2 Slots and Standoffs Dimensions 22mm 30mm M3 machine screw length = 4.5mm M.2 E-Key Slot M.2 B-Key Slot 19.9mm 47.31mm Figure 13: M.2 slots and standoffs dimensions... -
Page 16: On-Board I/O Pin Descriptions And Functionality
VIA AI Transforma Model 1 User Manual 2. On-Board I/O Pin Descriptions and Functionality This chapter provides information about the onboard I/O connectors and pin headers of the VIA AI Transforma Model 1 board. 2.1 40-pin GPIO Header The VIA AI Transforma Model 1 board comes with a 40-pin Raspberry Pi-type GPIO header labeled as ‘J6’, which can be used for connecting I2C, SPI, UART TX/RX, 5V power input, 5V/3.3V power output, GND, PWM, PCM, and 13 I/O expander GPIO devices such as Raspberry Pi supported HATs, cameras, displays, LEDs, actuators, motors, sensors, and buttons. -
Page 17: Slots
VIA AI Transforma Model 1 User Manual 2.2 M.2 Slots The VIA AI Transforma Model 1 board is equipped with a standard M.2 format 3042 key B slot labeled 'MB2' and a standard M.2 format 3042 key E slot labeled 'JWIFI', which can be used for adding Wi-Fi and 4G/5G connectivity, increased storage, NPU accelerators or other PCIe devices. -
Page 18: Onboard Jumpers And Headers
VIA AI Transforma Model 1 User Manual 2.3 Onboard Jumpers and Headers Jumper/Header Descriptions A jumper or header consists of a pair of conductive pins used to close in or bypass an electronic circuit to set up or configure a particular feature using a jumper cap. The jumper cap is a small metal clip covered by plastic. It performs like a connecting bridge to short (connect) the pair of pins. -
Page 19: Watchdog Jumper
VIA AI Transforma Model 1 User Manual 2.3.1 Watchdog Jumper The VIA AI Transforma Model 1 board comes with a 2-pin watchdog jumper labeled as 'JWDG', which can be used for enabling/disabling the watchdog function of the VIA AI Transforma Model 1 board. The watchdog jumper settings are shown below. -
Page 20: Auto Power On Jumper
VIA AI Transforma Model 1 User Manual 2.3.2 Auto Power ON Jumper The VIA AI Transforma Model 1 board comes with a 3-pin auto power ON jumper labeled as 'J_APO', which can be used for enabling or disabling the auto power ON function of the VIA AI Transforma Model 1 board. The auto power ON jumper settings are shown below. -
Page 21: Poe Header
VIA AI Transforma Model 1 User Manual 2.3.3 PoE Header The VIA AI Transforma Model 1 board comes with a 4-pin PoE header labeled as 'J19', which can be used for connecting to Raspberry Pi HATs for implementing Power-over-Ethernet. The PoE header's pins and signals are shown below. -
Page 22: Hardware Installation
VIA AI Transforma Model 1 User Manual 3. Hardware Installation This chapter describes how to fix or connect the standard accessories provided in the VIA AI Transforma Model 1 board package. 3.1 Fixing the Plastic Spacers Plastic spacers are provided to prop up the VIA AI Transforma Model 1 board for placement on a flat surface. Follow the instructions below to fix plastic spacers to each corner of the board: 1. -
Page 23: Software And Technical Support
VIA AI Transforma Model 1 User Manual 4. Software and Technical Support 4.1 Debian Support The VIA AI Transforma Model 1 features a complete software evaluation image for the Debian 12 operating system. 4.2 Technical Support and Assistance • For utilities downloads, latest documentation and information about the VIA AI Transforma Model 1, please visit our website at https://www.viatech.com/en/via-ai-transforma-model-1/. - Page 24 Taiwan Headquarters Japan China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084 Japan China...
