Adjusting the Viewfinder Diopter

Adjust the viewfinder diopter to suit your eyesight.
If it is difficult to see the viewfinder image clearly, slide the diopter
adjustment lever sideways.
You can adjust the diopter from approximately -2.5 to +1.5 m
1
Look through the viewfinder and
slide the diopter adjustment lever
left or right.
Adjust the lever until the AF frame in the
viewfinder is focused.
Point the camera at a white wall or other
bright and consistent surface.
• The Eyecup F
the factory. Diopter can be adjusted with the Eyecup F
adjustment is easier with the eyecup removed.
• To remove the Eyecup F
direction of the arrow.
To attach the Eyecup F
groove on the viewfinder eyepiece and
push it into the position.
• If it is difficult to see the viewfinder image
clearly even if you use the diopter
adjustment lever, use the optional diopter
correction lens adapter M. However, the
Eyecup F
R
adapter. (p.348)
is attached to the viewfinder portion when the camera leaves
R
, pull it out in the
R
, align it with the
R
must be removed to use this
-1
.
AF frame
attached. However,
R
61
