- Page 1 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Installation Instructions / Warranty Citterio Terrano Carlton Phoenix 27831XXX 27834XXX 27835XXX Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890...
- Page 2 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Axor Citterio Wallbar Set 27831XXX Axor Terrano Wallbar Set 27834XXX Axor Carlton / Phoenix Wallbar Set 27835XXX 27831XXX 27834XXX 27835XXX This wallbar set contains the wallbar and a 63” Techniflex handshower hose. It is compatible with any Hansgrohe handshower.
- Page 3 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Axor Citterio Wallbar Installation Mark the positions for the screw holes (1). The center of the top hole should be 36” from the center of the bottom hole. Drill the holes with a 6 mm bit suitable for the wall surface (2).
- Page 4 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Axor Terrano / Carlton / Phoenix Wallbar Installation Mark the positions of the screw holes, using the holes on the mounting pieces as a template. When positioning the support element on the wall, make sure that the notch is at the bottom.
- Page 5 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Install the anchors. Seal the wall around the anchors with waterproof sealant. Screw the support elements to the wall with the screws. Note: the gold deco-rings shown in the diagram are included only with Carlton model 27835090 (chrome with gold accents).
-
Page 6: Vertical Adjustment
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Slider Adjustment Vertical adjustment easier harder To adjust the resistance of the slider, use a screwdriver to turn the adjustment screw on the back of the slider. Turning the screw clockwise makes the slider harder to move, counter-clockwise makes it easier. - Page 7 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Install the handshower (not included) Remove the protective cap from the handshower. Place a black rubber hose washer in the shorter hose end connection. Screw this end to the wall supply (not included). Place the screen washer in the longer hose end connection.
- Page 8 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Replacement Parts 27831XXX mounting set 40916000 slider 96505XXX mounting piece 97597000 cylinder screw 97661000 set screw 97660000 wall support 97696XXX hose 28276XXX Replacement Parts 27834XXX mounting set 96179000 support element 96341000 hexagon screw 97661000 97546000 slider 96505XXX hose...
- Page 9 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Replacement Parts 27835XXX mounting set 96179000 slider 96505XXX support element 96341000 97546000 hexagon screw 97661000 hose 28276XXX Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890...
-
Page 10: Limited Lifetime Consumer Warranty
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty. - Page 11 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 THIS WARRANTY DOES NOT COVER and HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse”...
