- Page 1 Installation Instructions / Warranty Raindance 27876XX1...
- Page 2 Raindance Wallbar with S 150 3-Jet Handshower 27876XX1 Rain AIR Balance AIR Whirl AIR Product Specification Max. flow rate 2.5 gpm Requires wall outlet (not included) Protection against back siphonage not included -- Hansgrohe suggests using wall outlet with inte- gral vacuum breaker 27458XX1 or accessory vacuum breaker 06510XX0.
- Page 3 Suggested installation The measurements shown are ap- proximate, and are based on a customer height of 5’11”. The wall outlet shown is for illustra- tion purposes only. It is not included with this set. Suggested Uses...
- Page 4 Installation Position the upper wall support at the desired mounting height (“X”). Mark the positions of the screw holes. Put the upper wall support away in a safe place. Dimple the tile (1). Drill the holes with a 6 mm bit suit- able for the wall surface (2).
- Page 5 Install the upper wall support. Install the lower mounting screw. Tighten both screws with a 7 mm wrench. Temporarily install the bar and lower wall support (1). Mark the positions of the screw holes (2). Put the bar and lower wall support away in a safe place. Dimple the tile (1).
- Page 6 Install the anchor. Seal the wall around the anchor with waterproof bathroom sealant. Install the bar and lower wall support (1). Install the screw and offset bushing (2). Confirm that the bar is level. If necessary, use a screw- driver to reposition the offset bushing (1). Install the screw covers (2) Place a screen washer in one end of the hose.
- Page 7 Slider Adjustment To control how easy or how difficult it is to move the slider up and down the bar, use a screwdriver to turn the adjust- ment screw. Turn the screw clockwise to make the slider harder to move, counter-clockwise to make it easier to move. User Instructions Push the selector lever to select the desired spray mode.
- Page 8 Scale Removal If limescale deposits are noticed in the spray channels, turn the water on lightly and rub across the spray channels with a finger or a sponge to dislodge them. If scale deposits are noticed on the spray face, pour about 3/4”...
- Page 9 Replacement Parts 1 handshower 28519XX1 2 hose 28276XX0 3 screen washer 94246000 4 slider 97336XX0 5 screw cover 97337XX0 6 wall support 97375XX0 7 mounting set 96179000 8 tile matching disk 28699XX0 9 hose washer 98058000 XX = color 00 = chrome 82 = brushed nickel...
- Page 10 Cleaning Recommendation for Hansgrohe Products Modern sanitary faucetry and shower fixtures consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain points when cleaning: Cleaning materials for faucets and shower products: Acids are necessary ingredients of cleaning materials for removing lime.
- Page 11 with respect to AXOR, ShowerPower and Pharo products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse”...
- Page 12 Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 770 360-9880 • Fax 770 360 9887 www.hansgrohe-USA.com...
