ADTRAN 1442544F3BD Quick Start Manual

Description
The 10 Gig XGS-PON Optical Line Termination (OLT) Class E1 SFP+ is
a single-mode fiber SFP+. The SFP+ provides a single optical
interface to a physical interface. You can use it with a 9.953 Gbps
passive optical network (PON) OLT module. The SFP+ provides a
9.953 Gbps XGS-PON interface to the supporting system.
The SFP+ is configured with an L-band 9.953 Gbps downstream
transmitter and a O-band 9.953 Gbps upstream receiver, which
work in a TDM configuration.
Description
SFP+, 10 Gb XGS-PON E1 OLT
SFP+, 10 Gb XGS-PON E1 OLT, BABA-compliant
CAUTION
Due to compliance certification requirements, use only
pluggable optics supplied by Adtran. Adtran cannot
certify system integrity with other pluggable optics.
Features
ODN Class E1 transceiver
l
Data rate: 9.953 Gbps
l
Optical receive wavelength: 1270 nm
l
Optical transmit wavelength: 1577 nm
l
Optical distance: up to 40 km
l
FDA 21 CFR 1040.10 and IEC 60825-1 Class I laser safety
l
compliant
Meets the EU RoHS Directive
l
Hot pluggable
l
WARNING
A warning indicates a hazard
that, if not avoided, could result in
death, injury, or serious property
damage.
Adtran Pluggable Optics
SFP+
10 Gb XGS-PON E1 OLT
Applications:
l
o
o
o
o
Installation
Before you install the equipment, inspect the SFP+ for damage. If
P/N
you notice damage from shipping, file a claim with the carrier and
then contact Adtran. For more information, see Warranty.
1442544F3
1442544F3BD
To install the SFP+ into an appropriate module:
1. Insert the SFP+ into the SFP+ port on the module.
2. Slide the SFP+ all the way into the SFP+ port until you hear an
audible click.
3. Remove the protective dust cover from the SFP+ and the fiber
optic cable.
4. Insert the fiber optic cable into the SFP+.
5. Continue the installation and turn-up of the host module by
using the instructions in the Quick Start Guide provided with
the module or other available system-level documentation.
For more information, see Documentation.
CAUTION
A caution indicates a hazard
that, if not avoided, could result in
service interruption, damage to
the equipment, or minor property
damage.
Doc Number: 61442544F3-13B
XGS-PON access networks
Fiber to the Premises (FTTP)
Fiber to the Building (FTTB)
Fiber to the Curb (FTTC)
CAUTION
Do not remove the protective dust cover from the SFP+
until you are ready to connect the fiber optic cable.
NOTE
SFP+ orientation varies depending on the port
orientation on the host module.
NOTE
Only use the latch on the SFP+ when removing it from
the host module. When removing the SFP+, rotate the
latch away from the SFP+. It should easily slide out of the
port.
NOTE
A note highlights additional, but
important, information or
features.
October 2024
