  • Page 1 Wheelchair Simba Direction for Use 000690674.GB...

  • Page 2: Wheelchair Components

    We at SUNRISE MEDICAL have been awarded the ISO-13485 certificate, which affirms the quality of our products at every stage, from R & D to production. This product complies with the standards set forth in EU and UK regulations. Options or accessories shown are available at extra cost. Simba English Rev. L...
  • Page 3 Wheelchairs: 1. Push handles 2. Backrest upholstery 3. Sideguard 4. Seat sling 5. Footrest 6. Castors 7. Footboard 8. Fork 9. Quick-release axle 10. Wheel locks 11. Handrim 12. Rear wheel Rev. L English Simba...
  • Page 4 ° 1000 MAX. MIN. MAX. MIN. MAX. MIN. 10° 10° 10° 7° 0° 0° 0° 0° < 95° 15° 110° MAX. < 95° 0° 74° MIN. MAX. 11.8 13.9 2.1 KG MIN. Simba English Rev. L...
  • Page 5 M5 = 5.0 Nm M6 = 7.0 Nm M8 = 20 Nm Rev. L English Simba...
  • Page 6 5” 123 mm 5” 123 mm 6” 111 mm 6” 111 mm 6” 111 mm 6” 111 mm 6” 123 mm 6” 123 mm 6” 123 mm 6” 123 mm 6” 123 mm 6” 123 mm Simba English Rev. L...
  • Page 7 22” (559 mm) 22” (559 mm) 22” (559 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) 24” (610 mm) Rev. L English Simba...
  • Page 8 DO NOT USE YOUR WHEELCHAIR UNTIL THIS occurred in relation to the device should be reported to the MANUAL HAS BEEN READ AND UNDERSTOOD. manufacturer and the competent authority of the Member State in which the user and/or patient is established. Simba English Rev. L...

  • Page 9: Area Of Application

    Please refer to the operating instructions of the wheelchair and the additionally mounted components. Instruct the user in the safe use of the wheelchair and the additionally mounted components. Inform users of specific warnings that need to be read, understood, and respected. Rev. L English Simba...

  • Page 10: Table Of Contents

    The manufacturer reserves the right to alter without notice any weights, measurements or other technical data shown in this manual. All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications. Dealer signature and stamp Simba English Rev. L...

  • Page 11: General Safety Notes And Driving Limits

    700 mm. If this is the case, under certain circumstances, it may not be possible to use some or all of the available escape routes from a building. It may be more difficult or Fig. A impossible to travel on public transport. Rev. L English Simba...
  • Page 12 • With all moving parts there is a natural risk of finger traps. Please handle with care • The wheelchair should not be used in heavy rain, snow, slippery, or unsound surfaces. • Do not use the wheelchair in hazardous environments. Simba English Rev. L...
  • Page 13 All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications. Lifetime • The intended lifetime of the wheelchair is 5 years. Rev. L English Simba...

  • Page 14: Transportability

    Fig.A Fig.B UPPER TORSO RESTRAINT BELT PELVIC RESTRAINT BELT Simba English Rev. L...
  • Page 15 • The wheelchair secured with front wheelchair tie down restraints. (Fig. G). • Position of the rear wheelchair tie down restraint, (Fig. H). Fig.C Fig.E Fig. G PREFERED PREFERED ZONE ZONE Fig. H Fig.D Fig. F Rev. L English Simba...

  • Page 16: Guarantee

    Repairs have been carried out, before our Customer Service has been informed of the circumstances. 7. This guarantee is subject to the law of the country in which the product was purchased from Sunrise Medical“ * Means the Sunrise Medical facility from which the product was purchased. Simba English Rev. L...

  • Page 17: Handling

    To readjust, loosen screw (1) and set the appropriate interval. Tighten screws again (see the page on torque) (Fig. 5.2). 13.0 mm 13.0 mm Standard Wheel lock (Fig. 5.3) Rev. L English Simba...

  • Page 18: Footplate Adjustment

    (Fig. 5.9). CAUTION! Fig. 5.9 The screws/bolts used on this wheelchair have thread locking fluid applied at the factory. After that they should be replaced or alternatively re-secured with threadlock to medium tightness. Simba English Rev. L...

  • Page 19: Seat

    An adjustment to the castor angle may be necessary when adjusting the rear seat height. • The screws/bolts used on this wheelchair have thread locking fluid applied at the factory. After that they should be replaced or alternatively re-secured with threadlock to medium tightness. Rev. L English Simba...

  • Page 20: Wheel Alignment

    Make sure that after any adjustment work, all screws are tightened correctly (see the page on torque). SIMBA tracking adjustment Setting the toe-in/toe-out to zero: NOTE: A wheelchair with 0° camber cylinders cannot have toe-in or toe-out.

  • Page 21: Backrest

    The adjustment ranges are 20-25 cm, 25-30 cm, 30-35 cm and 35-40 cm. Release the screws (1) and set the backrest to the desired height. Tighten up the screws again (see the page on torque) (Fig. 5.19). Rev. L English Simba...

  • Page 22: Push Handle

    Sideguard Fig. 5.20 The sideguards of the SIMBA are primarily designed for the new integrated sideguard brakes. If you have not ordered the integrated sideguard brakes then the openings in the sideguard are fitted with covers, (Fig. 5.20). WARNING! If the sideguard is used without the covers, then this presents a risk of injury.

  • Page 23: Anti-Tip Tubes

    If the screws are difficult to fit back in place, try and locate the holes with a sharp object. Ensure also that the plastic base is in the correct position before the screws are tightened again, (5.24). Rev. L English Simba...

  • Page 24: Seat Width And Seat Depth Growth

    Check the pressure after mounting or repairing a tyre. It is critical to your safety and to the wheelchair’s performance that regulation air pressure be maintained and that tyres are in good condition. Simba English Rev. L...

  • Page 25: Anterior Lateral Support (Lap Belt)

    When fastened check space between the pelvic restraint belt and user. When correctly adjusted it should not be possible to insert more than the flat of the hand between the lap belt and the user. (Fig. 6.3). Rev. L English Simba...
  • Page 26 The lap belt should be adjusted to suit the end user as detailed above. Sunrise Medical recommends that the length and fit of the belt be checked on a regular basis to reduce the risk of the end user inadvertently re-adjusting the belt to an excessive length. Simba English Rev. L...

  • Page 27: Trouble-Shooting

    Wheelchair is difficult to fold up 203211533246056 Rollstuhl TYPE: • Adjustable backrest upholstery is too stiff. Loosen it Simba ISO 7176-19:2008 accordingly. Wheelchair squeaks and rattles • Check to make sure all bolts are secure; tighten if necessary (see the section on torque).

  • Page 28: Maintenance And Care

    In general, a complete disinfection cannot be guaranteed on seams. We therefore recommend that you dispose of seat and back slings to avoid micro-bacterial contamination with active agents according to your local infection protection law. Simba English Rev. L...

  • Page 29: Technical Data

    SW + 330 mm Maximum load: 11.0 Disposal / Recycling of Materials SIMBA up to a load of 65 kg If the wheelchair has been made available to you free of Seat heights: charge, then it does not belong to you. If it is no longer...
  • Page 30 Simba English Rev. L...
  • Page 31 Rev. L English Simba...
