- Page 1 Instruction WE170V, WE170P, TE1120 Pedestal Read the instruction in full before starting work. If anything is unclear or incorrect, please contact your local sales office or service representative. 132902910/EN 2024.11.25...
- Page 3 Instruction 1 How to install the stand on your washing machine Warning Do not install the stand on a washer/dryer column. Caution If the washing machine is already connected to the mains, proceed as follows: 1. pull out the plug from the mains socket; 2.
- Page 4 Instruction 1.1 To install the stand 1. Loosen the nuts using the key supplied with the stand. 2. Adjust the feet to allow for an uneven floor. 3. Tighten up all check nuts. fig.X03383 4. Fit one of the rear brackets to the left side of the stands back using the screws supplied. fig.X03384 5.
- Page 5 Instruction 9. Return machine and stand to a vertical position, and screw the other bracket onto the stand and the machines back using the remaining supplied screws. fig.X03388 10. The stand is now installed; check whether your washing machines back feet rest on it . Otherwise undo them us- ing the key supplied with your washing machine.
- Page 6 Instruction 2 How to install the stand on your tumble dryer Warning Do not install the stand on a washer/dryer column. Caution If the tumble dryer is already connected to the mains, proceed as follows: 1. pull out the plug from the mains; 2.
- Page 7 Instruction 2.1 To install the stand 1. Loosen the nuts using the key supplied with the stand. 2. Adjust the feet to allow for an uneven floor. 3. Tighten up all check nuts. fig.X03383 4. Lay the machine on its left side, making sure you do not damage it. Remove the front feet and replace them with the rubber ones.
- Page 8 Instruction fig.X03396 9. Fit the rear brackets to the machines back using the previously removed screws. fig.X03397 10. The stands drawer, with a capacity of up to 20 kg, contains two dividers; they may be taken out if you wish. The drawer was designed with a special compartment inside where you can place a folding plastic box, supplied, quite useful to store your washing laundry.
- Page 12 Electrolux Professional AB 341 80 Ljungby, Sweden www.electroluxprofessional.com...
