human care Rebel Reconditioning Instructions

Rebel
This reconditioning instruction applies to the rollator and its available accessories and spare parts.
To continue to work safely and securely for the user, the rollator should be checked
and serviced once a year. The following measures are therefore recommended.
Cleaning & Disinfection
Water and a mild detergent are recommended for cleaning. Machine wash at 60°C for 10
minutes can be used, drying maximum 70°C for10 minutes; observe the post-treatment
requirements. Avoid flushing with pressure against bearings (wheels, front forks). NB Do not
use white spirit, petrol or other solvents.
Disinfection is performed by qualified personnel with appropriate protective equipment
and according to the disinfectant manufacturer's instructions. When cleaning, use a sponge
or soft cloth that will not scratch the product. Use an approved chemical disinfectant
containing 70-80% ethanol. Do not use abrasive cleaners, chlorine or phenol. If you have any
questions about disinfection or suitable disinfectants, please contact Human Care.
Post-treatment
Immediately after washing, rotate all bearings (wheels, front fork) 10 turns so that the
bearing grease can be distributed. Blow joints, tight spaces and drainage holes clean, then
spray with thin oil.
Paint
Check for damage to the paint. If there is any damage to the paint, use a touch-up paint to
reduce the risk of corrosion. Order from Human Care, Art. No.: F2 (see p. 3).
Tube body
Check welds and screw connections. In the event of serious corrosion, replace the rollator.
Handle
Check that the handle tubes can be pushed down into the
chassis. It should not be possible to rotate,the handle; replace
grip if necessary. NB Use only alcohol without hydrating agents.
Brakes
Check that both the moving and parking brake are working.
Cables should be whole and clamped on.
RECONDITIONING INSTRUCTIONS
Wing knob
Check the function.
Reflectors
Check that the reflectors are in placeand
are visible.
CE & MD Marking
Check that the CE and MD markings are in
pllace and that they can be read.
Wheels
Check that the wheels are not worn and
that they spin easily without noise.
Lubrication
Gate bushings and hinges should work
without noise. Lubricate if necessary.
Front forks
Check that the attachment and bearings are not loose, check that the
front fork can easily rotate and rock 4-6 times in a horizontal position. If
adjustment of the front fork is to be done, the M12 and M6 screws must be
replaced. Ensure that the locking screw above the front fork is fully screwed
in.
The folding mechanism
It should be complete and the lock should work.
Seat cushion
Check that the cushion is secure and that
the screws are tight.
Stability
Check that all wheels are firmly on the ground
and that there is no distortion in the chassis.
Test run
Perform a final check through a test run.
Locking
screw
1
