Your satisfaction is important to us, please let us help!
If you have any questions or concerns during the installation, our support representa-
tives are available to assist you.
Please call: 1-877-769-3765 or Live Chat at www.raptorseries.com
If you have damaged or missing parts please contact the company you purchased the
product from and notify them of the issue right away.
CAUTION: Do not install damaged parts!!!
Raptor Series Truck Accessories | P:877.769.3765 | F: 877.875.7446 | E: sales@raptorseries.com
Advertisement
Related Manuals for Raptor Series MAGNUM GTS16CH
Summary of Contents for Raptor Series MAGNUM GTS16CH
- Page 1 If you have damaged or missing parts please contact the company you purchased the product from and notify them of the issue right away. CAUTION: Do not install damaged parts!!! Raptor Series Truck Accessories | P:877.769.3765 | F: 877.875.7446 | E: sales@raptorseries.com...
- Page 2 In the event that you need to ship your part back to return/exchange, please ship to the warehouse below: CYC Returns Warehouse 2415 Cathy Lane Jasper, IN 47546 Raptor Series Truck Accessories | P:877.769.3765 | F: 877.875.7446 | E: sales@raptorseries.com...
-
Page 3: Limited Lifetime Warranty
Raptor Series Warranty LIMITED TEN (10) YEAR WARRANTY For Powder Coated Steel Products CYC Engineering, Inc. guarantees the original purchaser of our products a limited ten (10) year warranty from the date of original purchase against manufacturer defects in materials, workmanship and finish under normal use. - Page 4 Rev 1 GTS14CH/GTS16CH MAGNUM RT STEPS Components: Hardware: M8 x 30 mm RTSPN175 Hex Head Bolts Bolt/Nut Plates Qty 24 Qty 8 M8 Plastic M8 Hex Head Push Nuts Nuts Passenger Driver Side Qty 8 Qty 16 Side Step Bar Step Bar Qty 1 Qty 1...
- Page 5 Rev 1 Note: When installing the brackets and bars, all hardware must be left loose until all the items are attached. Remove all contents from the package and check steps for any damage. Also, verify that all F r o components and hardware listed above are included before you begin installation.
- Page 6 Rev 1 If specified holes in the wall of the rocker panel are not threaded, remove plastic plug (5a and 5b) and insert U-Nut Clip so that the threads are facing away from you (5c and 5d). Fasten using one (1) M8 x 30 mm Hex Head Bolt, one (1) M8 Flat Washer and one (1) M8 Lock Washer (6a).
- Page 7 Rev 1 Installing on a Diesel Model with DEF Tank If installing on a diesel model with DEF tank, you must use Passenger Side Front Mounting Bracket (Diesel Only) on the FRONT BODY front mounting location. MOUNT BOLT Attach this bracket by removing the front body mount bolt (7a).
- Page 8 Rev 1 2017-C GM Diesel Trucks With DEF Tank Since these trucks have a PASSENGER SIDE 2ND LOCATION TOP MOUNTING BRACKET (17-C Diesel Only) larger DEF tank, you must use Passenger Side 2nd Location Mounting Brackets (17-C Diesel Only) to mount the steps F r o correctly.
- Page 9 Rev 1 Installing the Step Bar MOUNTING RTSPN175 BRACKET BOLT/NUT PLATE Line up mounting points on M8 FLAT the step bar with the mounting WASHER holes in each bracket. M8 LOCK WASHER Fasten the step bar to each bracket using one (1) RTSPN175 Bolt/Nut Plate, one (1) Plastic Push Nut, one (1) M8 Hex Head Nut, two (2) M8 Lock Washers,...
