Summary of Contents for Raptor Series MAGNUM RT GTS65TY
Page 1
If you have damaged or missing parts please contact the company you purchased the product from and notify them of the issue right away. CAUTION: Do not install damaged parts!!! Raptor Series Truck Accessories | P:877.769.3765 | F: 877.875.7446 | E: sales@raptorseries.com...
Page 2
In the event that you need to ship your part back to return/exchange, please ship to the warehouse below: CYC Returns Warehouse 2415 Cathy Lane Jasper, IN 47546 Raptor Series Truck Accessories | P:877.769.3765 | F: 877.875.7446 | E: sales@raptorseries.com...
Raptor Series Warranty LIMITED TEN (10) YEAR WARRANTY For Powder Coated Steel Products CYC Engineering, Inc. guarantees the original purchaser of our products a limited ten (10) year warranty from the date of original purchase against manufacturer defects in materials, workmanship and finish under normal use.
Page 4
Rev 1 GTS65TY/GTS75TY MAGNUM RT STEPS Components: Hardware: M8 x 30 mm RTSPN175 Hex Head Bolts Bolt/Nut Plates Qty 18 Qty 6 M8 Plastic M8 Lock Push Nuts Washers Front Armor Plates Passenger Driver Side Qty 6 Qty 24 Qty 2 Side Step Bar Step Bar Qty 1...
Page 5
Rev 1 Align the Front, Center and Rear Driver’s Side Brackets with the indicated holes located on the Rocker Panel of the vehicle. Fasten the Front, Center and Rear Brackets to the Rocker Panel using two (2) M8 x 30MM F r o Hex Head Bolts, two (2) M8 Flat Washers and two (2) M8 Lock...
Page 6
Rev 1 Installing the Step Bar RTSPN175 BOLT/NUT PLATE Line up mounting points on MOUNTING BRACKET the step bar with the mounting M8 FLAT holes in each bracket. WASHER M8 LOCK Fasten the step bar to each WASHER bracket using one (1) RTSPN175 Bolt/Nut Plate, one (1) Plastic Push Nut, one (1) M8 Hex Head Nut, two (2) M8 Lock Washers,...
