Raptor Series 0804-0079 Installation Instructions

0804-0079
2007-10 Toyota Tundra Crew Max

Components List:

2 – Stainless steel oval step bars
3 – Brackets-Driver Side
3 – Brackets-Passenger Side
6 – Rubber gasket

Parts List:

10 – M8-1.25 x 30 mm hex head bolts
10 – M8 Flat washers
10 – M8 Lock washers
12 – M10 Button head bolt
12 – M10 Flat washers
12 – M10 Lock washers

Installation Instruction:

1. Remove contents from box and check for damage. Verify all the parts
from the list above are present and accounted for. Please read
instructions completely before starting.
2. Determine driver side brackets. All driver side brackets are identical with
metal cup facing toward the rear of the vehicle (see Fig. 1).
3. Install driver side bracket closest to the front wheel first. Use one M8-1.25
x 30mm hex head bolt, M8 flat washer, and M8 lock washer by attaching
to underside of body panel. Hand tighten. Use existing factory hole in
body panel for install (see Fig 1).
4. Attach remaining driver side brackets to underside body panel by using
two M8-1.25 x 30mm hex head bolts, M8 flat washers and M8 lock
washers per bracket. Hand tighten. Use existing factory holes in body
panel (see Fig. 1).
5. Place driver side step bar on brackets. Each step bar is marked driver
and passenger.
6. Assemble with M10 button head bolts and M10 lock washers. 2 bolts per
bracket, 6 bolts per bar (see Fig 2). Hand tighten.
7. Repeat installation for passenger side.
