Summary of Contents for Nice Filo
-
Page 12: Table Of Contents
3 INSTALLATION 3.1 VERIFYING THE SUITABILITY OF THE GATE AND ENVIRONMENT 3.2 VERIFYING THE PRODUCT’S APPLICATION LIMITS 3.3 PRODUCT TECHNICAL SPECIFICATIONS 3.4 PRE-INSTALLATION WORKS 3.5 INSTALLING THE FILO GEARMOTOR (model 400C/600C) INSTALLATION WITH RACK TO BE MOUNTED 3.5.1 INSTALLATION WITH EXISTING RACK 3.5.2 3.6 INSTALLING THE PHOTOCELLS model PH200 3.7 INSTALLING THE FLASHING LIGHT model FL200... -
Page 13: General Warnings: Safety - Installation - Use
GENERAL WARNINGS: SAFETY - INSTALLATION - USE (original instructions in Italian) CAUTION Important safety instructions. Observe all the instructions as improper installation may cause serious damage CAUTION Important safety instructions. It is important to comply with these instructions to ensure personal safety. Store these instructions •... -
Page 16: Installation
3.5 - INSTALLING THE FILO GEARMOTOR • All installation operations must be made with the system disconnected from the power supply. If the back-up battery is present, it must be disconnected • Incorrect installation may cause serious physical injury to those working on or using the system. -
Page 27: Flashing Light Signals
9.10.2 - Flashing light signals During the manoeuvre, the flashing light emits 1 flash each second; when there is an anomaly, it flashes quickly: see Table 8. TABLE 8 Flashes (quick) Status Action 1 flash ECSBus error At the beginning of the manoeuvre the devices present do not match those reco- gnised; check and, if necessary, try running the recognition procedure (Par. 9.2.1). 1 second pause 1 flash One or more devices may be faulty; check and, if necessary, replace them 2 flashes At the start of the manoeuvre, one or more photocells do not enable movement;... -
Page 28: Specifications
Photocells and other devices adopting this system can be connected to the ECSBus, such as safety devices, control buttons, indicator lights etc. For information on ECSBus devices, consult the Nice Home range product catalogue or visit the website www.niceforyou.com Through a recognition procedure the control unit recognises one-by-one all the devices connected and this enables it to detect with extreme precision all possible anomalies during the automation’s normal operation.
