- Page 1 Kaiyang T Series Handheld Thermal Camera User Manual V1.1.0 IRay Technology Co., Ltd. www.infiray.com...
- Page 2 Introduction to IRay Technology IRay Technology concentrates on developing infrared thermal imaging technologies and manufacturing relevant products, with completely independent intellectual property rights. IRay is committed to providing global customers with professional and competitive infrared thermal imaging products and solutions. The main products include IRFPA detectors, thermal imaging modules, and terminal thermal cameras and imagers.
-
Page 3: Table Of Contents
T Series Handheld Thermal Camera·User Manual Kaiyang Table of Contents 1 Legal Disclaimer ............................1 1.1 Legal Disclaimer ..........................1 1.2 Copyright ............................1 1.3 Quality Assurance ..........................1 2 Safety Information .............................2 3 Notice to user ............................9 3.1 Calibration ............................9 3.2 Accuracy ............................9 3.3 Video Teaching .......................... - Page 4 T Series Handheld Thermal Camera·User Manual Kaiyang 10.1.1 Charge with power adapter ....................25 10.1.2 Charge via PC ........................25 10.1.3 Using the stand-alone battery charger to charge the battery ........... 26 10.2 Turning on and turning off the camera ..................26 10.3 Laser Range Finding ........................
- Page 5 T Series Handheld Thermal Camera·User Manual Kaiyang 13.5 Changing the environmental parameters ..................52 13.6 Image Calibration ......................... 52 13.7 Set Image Mode ........................... 53 14 Analysis Setting ............................ 55 14.1 Add/Delete Analysis Tools ......................56 14.2 User Preset Settings ........................57 14.3 Move or Adjust Analysis Tools ......................58 14.4 Changing Parameters of Analysis Tool ..................
- Page 6 T Series Handheld Thermal Camera·User Manual Kaiyang 20.6.6 Brightness ...........................82 20.6.7 Volume ..........................82 20.6.8 GPS ............................ 83 20.6.9 Virtual Buttons ........................83 20.6.10 Storage Settings .......................84 20.6.11 Reset Parameters ......................84 20.6.12 Factory Reset ........................84 20.6.13 Software Update ......................85 20.7 Smart Capture ..........................
-
Page 7: Legal Disclaimer
TECHNOLOGY or this warranty will not apply. IRAY TECHNOLOGY will, at its option, repair or replace any such defective product free of charge if, upon inspection, the product or accessories prove to be defective, the user can contact with after-sales service department of IRAY TECHNOLOGY within the said warranty period. -
Page 8: Safety Information
T Series Handheld Thermal Camera·User Manual Kaiyang certified in accordance with the ISO9001 standard. We reserve the right to make changes and improvements on any of the products without prior notice. 2 Safety Information WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by IRAY Systems may void the FCC authorization to operate this equipment. - Page 9 T Series Handheld Thermal Camera·User Manual Kaiyang antenna. Applicability: Cameras with one or more laser pointers. Do not look directly into the laser beam. The laser beam can cause eye irritation. Applicability: Cameras with one or more batteries. Do not disassemble or do a modification to the battery. The battery contains safety and protection devices which, if damage occurs, can cause the battery to become hot, or cause an explosion or an ignition.
- Page 10 T Series Handheld Thermal Camera·User Manual Kaiyang Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on containers before you use a liquid. The liquids can be dangerous. Injury to persons can occur. 1. Make sure you read all applicable Material Safety Data Sheets (SDS) and warning labels on containers before you use a liquid.
- Page 11 T Series Handheld Thermal Camera·User Manual Kaiyang camera and even damage the detector in the thermal camera. Do not use the camera in temperatures more than +50 ° C (+122 ° F), unless other information is specified in the user documentation or technical data. High temperatures can cause damage to the camera.
- Page 12 T Series Handheld Thermal Camera·User Manual Kaiyang Applicability: Cameras with one or more batteries. Do not make holes in the battery with objects. Damage to the battery can occur. Applicability: Cameras with one or more batteries. Do not hit the battery with a hammer. Damage to the battery can occur. Applicability: Cameras with one or more batteries.
- Page 13 T Series Handheld Thermal Camera·User Manual Kaiyang Do not solder directly onto the battery. Damage to the battery can occur. Applicability: Cameras with one or more batteries. Do not use the battery if, when you use, charge, or put the battery in storage, there is an unusual smell from the battery, the battery feels hot, changes color, changes shape, or is in an unusual condition.
- Page 14 T Series Handheld Thermal Camera·User Manual Kaiyang range, it can decrease the performance or the life cycle of the battery. Applicability: Cameras with one or more batteries. When the battery is worn, apply insulation to the terminals with adhesive tape or equivalent materials before you discard it.
-
Page 15: Notice To User
Kaiyang 3 Notice to user 3.1 Calibration IRAY TECHNOLOGY recommends that you verify your calibration yearly in order to ensure accuracy. You can verify the calibration through IRAY TECHNOLOGY or third-party organizations. 3.2 Accuracy For very accurate results, we recommended that you wait 5 minutes after you have started the camera before measuring a temperature. -
Page 16: Customer Help
T Series Handheld Thermal Camera·User Manual Kaiyang point. For more information see: www.recyclethis.info 4 Customer Help 4.1 FAQ You can find answers to FAQ about this model on the service support page of our official website. 4.2 Download You can download the following contents from our website: www.infiray.com Product Documentation ... -
Page 17: Introduction
T Series Handheld Thermal Camera·User Manual Kaiyang 5 Introduction 5.1 General description The T series is designed for the expert requiring the highest performance and the latest technology available. The camera series have excellent ergonomics, and can achieve high accuracy and high-quality image with high-sensitivity and high-resolution infrared detectors. -
Page 18: Packaging Contents
T Series Handheld Thermal Camera·User Manual Kaiyang continuous autofocus, the image continues to be clear, which improves work efficiency greatly. • Intelligent Work Flow: T series are integrated with Work Flow Template, which can be edited via IR_Discovery, auto image naming and complete complicated work flow with multiple image annotation and memory function. -
Page 19: Camera Overview
T Series Handheld Thermal Camera·User Manual Kaiyang 6 Camera Overview 6.1 View from the rear Name Function Description Visible light LED illuminator Infrared lens Manual focus ring Adjust camera focus manually Press the button to capture image; press and hold the button to Image capture button start/end video recording... -
Page 20: View Form The Top
T Series Handheld Thermal Camera·User Manual Kaiyang 6.2 View form the top Name Function Descriptions China mobile SIM card slot Note: unavailable for some models Standard configuration 64GB, supports hot-swapping, compatible with SD, SDHC, SDXC, and supports a maximum expansion of 2TB; You can remove the SD card and use a card reader to SD card slot transfer data to a PC or other devices;... -
Page 21: View From The Front
T Series Handheld Thermal Camera·User Manual Kaiyang 6.3 View from the front Name Function Description Power, charging, connection status indicators; Charging indicator Slow blinking green light indicates charging; Steady green light indicates fully charged. Press and hold for 3s to power on; Press and hold Power button for 3s to bring up the shutdown/restart menu;... -
Page 22: View From The Bottom
T Series Handheld Thermal Camera·User Manual Kaiyang Returns from dialog boxes; Navigates back Back Button through menus step by step. OK button: single click Programmable button: press and hold, including OK/Programmable Button voice recognition, laser range finding Note: only available for some models 6.4 View from the bottom Name Function Description... -
Page 23: Quick Start Guide
T Series Handheld Thermal Camera·User Manual Kaiyang 7 Quick Start Guide Please follow the below steps. Memory: open the silicone cap on the top, inserted the dedicated SD card in the accessories, then seal the silicone cap. Battery: open the battery compartment cap on the handle bottom, insert the dedicated battery in the accessory and close the cap of the battery compartment. - Page 24 T Series Handheld Thermal Camera·User Manual Kaiyang Image Replay Click Gallery button. Push the joystick button, select the file via up/down/left/right button. Press Ok button to enter image preview interface. Color Palettes Go to （Color Palettes）via joystick button. Enter to submenu by pressing OK button. Select a different color palette via joystick button.
- Page 25 T Series Handheld Thermal Camera·User Manual Kaiyang APP Analysis Download mobile App（Android: visit www.infiray.com, enter Support-Product Support Center, find T630, click and enter Software to download android_irpt_tas_VX.X.X_S_build_31.apk, IOS:search for IR DISCOVERY in APPSTORE, the APPSTORE Address: https://apps.apple.com/cn/app/%E7%9D%BF%E6%8E%A2/id6444423419）, start the application software, The thermal camera is connected via WLAN or hotspot, the mobile device can find and connect with the thermal camera to perform secondary analysis via search function.
-
Page 26: Screen Elements
T Series Handheld Thermal Camera·User Manual Kaiyang 8 Screen Elements 8.1 General 8.1.1 Explanation Name Description Date & Time Present Date and Time Setting Button Press to enter settings interface Isotherm Button Press to open isotherm sub menu Image Calibration Press to perform manual calibration Button Flashlight... -
Page 27: Status Indicators
T Series Handheld Thermal Camera·User Manual Kaiyang Image Mode Button Press to enter image mode submenu Color Palettes Button Press to enter submenu Press to enter submenu, select spot/ line/ Analyzing Button box/circle/polygon Press to enable laser range finding function and present LRF Button target distance Extended Tool Bar... -
Page 28: Shortcut Tool Bar
T Series Handheld Thermal Camera·User Manual Kaiyang 9 Shortcut Tool Bar To open the swipe-down menu, place your finger at the top of the screen and swipe down. To perform fast configuration via shortcut tool bar, including: (WLAN), (Bluetooth), (GPS), (Projection Screen), (FTP), (Cloud),... - Page 29 T Series Handheld Thermal Camera·User Manual Kaiyang Select to configure FTP service，please refer to chapter 18 for detailed information on FTP. Select to configure cloud service, press to enable/disable, please refer to chapter 16 for detailed information on cloud. Select to configure data sharing service, press to enable/disable, please refer to chapter 19 for detailed information on data sharing.
-
Page 30: Navigating The Menu System
T Series Handheld Thermal Camera·User Manual Kaiyang 9.1 Navigating the menu system The above figures illustrate two ways of navigating menu systems: Using your finger or a stylus pen specially designed for capacitive touch usage. (Figure on the left) Using the joystick and the back button. -
Page 31: Handling The Camera
T Series Handheld Thermal Camera·User Manual Kaiyang To confirm changes and settings in menus and dialog boxes, Press Ok button or Programmable button. To leave dialog boxes and to go back in the menu system, push the back button 10 Handling the camera 10.1 Charging the battery Note: ... -
Page 32: Using The Stand-Alone Battery Charger To Charge The Battery
T Series Handheld Thermal Camera·User Manual Kaiyang 10.1.3 Using the stand-alone battery charger to charge the battery Stand-alone battery charger LED indicator: Type of signal Explanation The green LED glows continuously. No battery or the battery is fully charged. The green LED flashes. The battery is being charged. -
Page 33: Adjusting The Infrared Camera Focus
T Series Handheld Thermal Camera·User Manual Kaiyang Please follow the below steps: Go to (LRF) via joystick button. Press Ok button to turn on laser range finding to perform continuous range finding, the measured value is displayed on the top left of the screen. 10.4 Adjusting the infrared camera focus Please follow this procedure:... -
Page 34: Autofocus
T Series Handheld Thermal Camera·User Manual Kaiyang Execute one of the following operations: For far focus, rotate the focus ring clockwise. For near focus, rotate the focus ring anticlockwise. Note ： Do not touch the lens surface when you adjust the infrared camera focus manually. If this happens, ... -
Page 35: Intelligent Focus
T Series Handheld Thermal Camera·User Manual Kaiyang 10.6 Intelligent focus The infrared camera can be configured to perform intelligent focusing. Note: • When intelligent focus is enabled, you can also manually adjust the focus by rotating the focus ring. • To stop intelligent focus (e.g., to stabilize the focus before saving an image), Please press and hold the Autofocus button. -
Page 36: Assigning Functions To The Programmable Buttons
T Series Handheld Thermal Camera·User Manual Kaiyang In preview/edit mode, it is possible to pan a zoomed image by touching the screen. Please follow this procedure: 1. To zoom, click the visual button icon to wake up visual button tool bar. 2. -
Page 37: Saving And Working With Images
T Series Handheld Thermal Camera·User Manual Kaiyang 1. Go to (Settings) with joystick and press the OK button. 2. Go to AI Key customization with joystick. 3. Select one of the functions and press the OK button. 11 Saving and working with images 11.1 About image files The image files include thermal information, visual information, environmental parameter and other information, which can be analyzed after being saved, for example, changing image mode, changing... -
Page 38: Opening A Saved Image
T Series Handheld Thermal Camera·User Manual Kaiyang (Settings) > Function Settings > Image Capture Analysis = On. Follow this procedure: 1. To preview an image, press and release image capture button. This displays the preview. 2. Manual image adjustment mode is now active and the status icon is presented. -
Page 39: Displaying Image Information
T Series Handheld Thermal Camera·User Manual Kaiyang (5) Select to rename a file. (6) Select to delete a file. (7) To return to the gallery overview, push or Back button. 11.7 Displaying image information Follow this procedure： 1. Open the image in Gallery. 2. -
Page 40: Editing A Saved Image
T Series Handheld Thermal Camera·User Manual Kaiyang You can type in the text or by OCR and confirm by QR scanning. Select to save. 11.9 Editing a Saved Image You can edit a saved image. You can also edit an image in preview mode. Follow this procedure: 1.Open the image in Gallery. -
Page 41: Create Pdf Reports
T Series Handheld Thermal Camera·User Manual Kaiyang (5) Select to set isotherm, please refer to 14.7 for details. (6) Select to set environment parameters, please refer to 13.5 for details. (7) Select to rename the file. (8) Select to add analysis tools, please refer to 14 for details. (9) Select to generate reports, please refer to 11.10 for details. -
Page 42: Delete Image
T Series Handheld Thermal Camera·User Manual Kaiyang (2) Select to save the reports to a memory card. (3) Select to rename a report. 11.11 Delete Image You can delete a single image file from the memory card. Note: Both images in the image file (thermal image and visual image) will be deleted. Please follow these steps. -
Page 43: Delete Multiple Files
T Series Handheld Thermal Camera·User Manual Kaiyang 5. Use the joystick to select OK and press OK button to confirm. 11.13 Delete Multiple Files You can delete multiple files from the memory card. Note: This will delete all files (images, videos, and reports) in the folder. Please follow these steps. -
Page 44: Image Annotations
T Series Handheld Thermal Camera·User Manual Kaiyang 5. Go to Reset Options and press OK button. 6. This will display a dialog box, choose Confirm and press the OK button. 11.15 Image Annotations You can use the annotation function to save additional information for the images, which can also be edited in the device. - Page 45 T Series Handheld Thermal Camera·User Manual Kaiyang 4. Follow these steps to enter free text using the soft keyboard. (1) Press the OK button to bring up a soft keyboard where you can enter the text you want to save by touching the screen.
-
Page 46: Add Voice Annotations
T Series Handheld Thermal Camera·User Manual Kaiyang (3) The recognized text will automatically fill in the text box. 6. Please follow the steps below to enter text by scanning the QR code. (1) Use the joystick to select , and press the OK button to enter the QR code scanning interface. (2) Move the thermal imager to scan the QR code and make sure the image is clear. - Page 47 T Series Handheld Thermal Camera·User Manual Kaiyang Follow these steps. 1. Open the image in a gallery file. 2. Press the OK button and select from the menu. 3. Select (Add Voice Annotation), and then press the OK button. 4. Select (Record) and press the OK button to start recording.
-
Page 48: Add Sketch
T Series Handheld Thermal Camera·User Manual Kaiyang 11.15.3 Add Sketch You can add a hand-drawn graphic to an image. Follow these steps. 1. Open the image in a gallery file. 2. Press the OK button and select from the menu. 3. -
Page 49: Recording Settings
T Series Handheld Thermal Camera·User Manual Kaiyang 12 Recording Settings 12.1 Video Recording You can record and save video clips to memory card. Note: The camera can be configured to save video in *.mp4 or *.irv format. Select (Settings) > Function Settings >... -
Page 50: Video Processing
T Series Handheld Thermal Camera·User Manual Kaiyang (2) Touch (Pause) to pause recording. (3) Touch (Take Photo) to take a photo. 3. The recording will be automatically saved to a file and you can play it in the gallery. 12.2 Video Processing You can view and process videos in the gallery, including (detailed info), (upload cloud),... -
Page 51: Image Effect Adjustment
T Series Handheld Thermal Camera·User Manual Kaiyang 13 Image Effect Adjustment It usually requires one or several parameters to get a good image. Adjust the focus of the thermal imager manually or electrically. Adjust the infrared image by automatic or manual mode. ... -
Page 52: Level And Span Adjustment
T Series Handheld Thermal Camera·User Manual Kaiyang The camera can also be set to continuous autofocus. See 10.8 continuous Autofocus for more information. 13.2 LEVEL and SPAN Adjustment Item Functions Switch Mode Switch Level/Span mode Display the temperature range of the current palette mapping, and Scale the scale displays the temperature range of the current image By clicking... -
Page 53: Temperature Measurement Range
T Series Handheld Thermal Camera·User Manual Kaiyang range of the current scene, and the endpoints are the maximum and minimum values. In manual mode, you can adjust the temperature to a value close to that of a specific object in the image, improve the contrast of ROI image, highlight anomalies and analyze small temperature differences. -
Page 54: Changing The Color Palette
T Series Handheld Thermal Camera·User Manual Kaiyang 3. Select the desired temperature measurement range and press the OK button. 13.4 Changing the color palette You can change the color palette that the camera uses to display different temperatures. A different palette can make it easier to analyze an image. White hot Black hot... - Page 55 T Series Handheld Thermal Camera·User Manual Kaiyang Rainbow HC rainbow Iron Lava...
- Page 56 T Series Handheld Thermal Camera·User Manual Kaiyang Ashes red Hot iron Special 1 Warning red Ice fire Green red...
- Page 57 T Series Handheld Thermal Camera·User Manual Kaiyang Special 2 Gradient red Medical Multicolor Warning green Warning blue...
-
Page 58: Changing The Environmental Parameters
T Series Handheld Thermal Camera·User Manual Kaiyang Please follow the below steps. 1. Use the joystick to go to (Palettes). 2. Press the OK button to enter the submenu. 3. Use the joystick to select a different color palette. 4. Press the OK button to confirm. 13.5 Changing the environmental parameters For accurate measurements, it is important to set the environmental parameters: emissivity, reflected temperature, object distance, atmospheric transmittance, and atmospheric temperature. -
Page 59: Set Image Mode
T Series Handheld Thermal Camera·User Manual Kaiyang on the touch screen. Press the Gallery button for more than 2 seconds. 13.7 Set Image Mode The thermal camera captures both thermal and visible light images, and you can choose the type of image you want to display on the screen by setting the image mode. - Page 60 T Series Handheld Thermal Camera·User Manual Kaiyang The different types of image modes are shown in the table below. Image Mode Image Effect Thermal DDE(optional) Fusion Visible...
-
Page 61: Analysis Setting
T Series Handheld Thermal Camera·User Manual Kaiyang Please follow the below steps. 1. Use the joystick to go to (Image Mode). 2. Press the OK button to enter the submenu. 3. Use the joystick to select different mode ( thermal), (fusion), (PIP), DDE,... -
Page 62: Add/Delete Analysis Tools
T Series Handheld Thermal Camera·User Manual Kaiyang 14.1 Add/Delete Analysis Tools Please follow the below steps. 1. Use the joystick to go to (Analyze). 2. Press the Ok button to enter the submenu. (1) Select (spot temperature measurement) to add a spot temperature measurement analysis tool. (2) Select (line temperature measurement) to add a line temperature measurement analysis tool, click... -
Page 63: User Preset Settings
T Series Handheld Thermal Camera·User Manual Kaiyang (7) Select (Cancel) to cancel the last added analysis tool. (8) Select (Clear) to clear all analysis tools. (9) Select (Import User Preset) to apply a set of user preset analysis tools. Please refer to 14.2 User Preset Settings. -
Page 64: Move Or Adjust Analysis Tools
T Series Handheld Thermal Camera·User Manual Kaiyang Select (Import User Preset), press the Ok button to pop up the import dialogue box. Select the template to be imported, and click Confirm in the lower right corner of the dialog box. 14.3 Move or Adjust Analysis Tools You can move or resize analysis tools. - Page 65 T Series Handheld Thermal Camera·User Manual Kaiyang Move the joystick to switch functions, including: (delete), (area parameter), (alarm), (attribute), (temperature trend). Select (Delete) to delete the currently selected analysis tool. Select (Regional parameters), and a dialog box will pop up. Set the environment parameters of the currently selected analysis tool.
-
Page 66: Changing Parameters Of Analysis Tool
T Series Handheld Thermal Camera·User Manual Kaiyang Select (temperature trend) to pop up the temperature trend chart of the analysis tool, which records the temperature change of the analysis tool within 15 minutes, you can also save the temperature trend which you can replay or analyze by secondary analysis. (This function is unavailable for some models). -
Page 67: Parameter Type
T Series Handheld Thermal Camera·User Manual Kaiyang 14.4.1 Parameter Type The following parameters can be configured. Distance: the distance between the thermal camera and the target, you can click to configure the distance via laser ranging module. Ambient temperature: the temperature of the air between the thermal camera and the target. ... -
Page 68: Recommended Values
T Series Handheld Thermal Camera·User Manual Kaiyang correlated when the distance is large. 14.4.2 Recommended Values If you are not sure about these values, please follow the below recommended values. Distance 2.0m Ambient Temperature 25℃ 25℃ Reflected Temperature Emissivity 0.95 Atmospheric Transmittance 14.4.3 Change Parameters You can set global object parameters, or modify parameters for each analysis tool separately, such as... - Page 69 T Series Handheld Thermal Camera·User Manual Kaiyang atmospheric transmittance, and ambient temperature. (4) Moves the joystick up and down to set the parameters. (5) Go to and press the Ok button to confirm the modification and close. (6) Go to and press the return key, cancel the modification and close.
-
Page 70: Change Properties Of Analysis Tool
T Series Handheld Thermal Camera·User Manual Kaiyang (4) Moves the joystick up and down to set the parameters. (5) Go to and press the OK button to confirm the modification and close. (6) Go to and press the return key, cancel the modification and close. 14.5 Change Properties of Analysis Tool You can set the properties of the analysis tool separately, including maximum temperature, minimum temperature, average temperature, and ambient temperature difference. -
Page 71: Set Analysis Tool Alarm
T Series Handheld Thermal Camera·User Manual Kaiyang 14.6 Set Analysis Tool Alarm You can make the camera trigger an alarm when the set analysis conditions are met. 14.6.1 Alarm Type You can choose the following alarm types. Above: When the temperature is higher than the preset alarm temperature, an alarm will be triggered. ... -
Page 72: Isotherm
T Series Handheld Thermal Camera·User Manual Kaiyang Touch to enable the alarm settings. Move the joystick left and right to switch parameters: Max temperature, Min temperature, Avg temperature, and ambient temperature difference. Move the joystick up and down to enable or disable the display of this property. Press the OK button to confirm the modification and close. - Page 73 T Series Handheld Thermal Camera·User Manual Kaiyang The camera can be set to trigger the following types of color alarms. Above alarms: This will apply a contrasting color to all pixels whose temperature is above the specified temperature threshold. Below alarms: This will apply a contrasting color to all pixels whose temperature is below the ...
-
Page 74: Remote Connection And Control
T Series Handheld Thermal Camera·User Manual Kaiyang 1. Use the joystick to go to isotherm 2. Press the OK button to enter the secondary menu. Move the joystick to select the alarm type, above alarm , below alarm , interval alarm 3. -
Page 75: Cloud Platform(Optional)
T Series Handheld Thermal Camera·User Manual Kaiyang (1) Visit Gallery File: You can visit the gallery data via PC TAS software or mobile App. You can also visit the gallery via the FTP service of third-party software, please refer to Chapter 18. (2) Projection Screen: The real-time image can be viewed via PC IR_Discovery software or mobile App. -
Page 76: Wireless Projection
T Series Handheld Thermal Camera·User Manual Kaiyang After clicking Login, you can connect to the cloud platform. Internet connection is necessary to use the cloud platform. For internet connection, please refer to 20.6.1 Connecting to WLAN. 17 Wireless Projection You can cast the screen of the current device to other large screens in the network that support the Miracast protocol. - Page 77 T Series Handheld Thermal Camera·User Manual Kaiyang upload or download files through the FTP protocol. Note: you can access data via anonymous FTP login, please change user name and password instantly. Please follow the below steps. Slide down to expand the shortcut toolbar. Use the joystick to go to (FTP) to start the dialog.
-
Page 78: Data Sharing
T Series Handheld Thermal Camera·User Manual Kaiyang Touch Stop Service to stop the FTP service. Follow the prompts to enter the FTP server address in the address bar of the PC, input the user name/password to enter the gallery, and make sure that the PC and the thermal camera are in the same local network. -
Page 79: Settings
T Series Handheld Thermal Camera·User Manual Kaiyang Use the joystick to go to (Data Sharing) to enable the service. 20 Settings Settings can be changed in the thermal camera. The settings menu includes the followings. (Function Settings), (Environmental Parameters), (Analysis Settings), (Alarm Settings), (Time-lapse image capture), (System Settings),... - Page 80 T Series Handheld Thermal Camera·User Manual Kaiyang Touch to start the dialog to add default text. After entering the text, click OK to save. Click the text, the toolbar will pop up, and click to delete the default text. To delete all preset texts, click...
-
Page 81: Filename Prefixes
T Series Handheld Thermal Camera·User Manual Kaiyang 20.1.2 Filename Prefixes You can customize the filename prefix of the image. Use the joystick to go to Edit Filename Prefix to enter the prefixes. 20.1.3 Edit Report Templates You can edit templates for generating analysis reports. Please follow the below steps. -
Page 82: Analysis Settings
T Series Handheld Thermal Camera·User Manual Kaiyang 20.3 Analysis Settings You can configure the properties of the whole frame and analysis tools, including the maximum temperature, center temperature, minimum temperature, and ambient temperature difference of the whole frame; maximum temperature, average temperature, minimum temperature, and ambient temperature difference of analysis tools. - Page 83 T Series Handheld Thermal Camera·User Manual Kaiyang Please follow the below steps. Go to (Settings) via the joystick, and press the OK button. Select (time-lapse image capture) to enter the secondary menu to set parameters. 3. Time-lapse image capture: (On) or (Off).
-
Page 84: System Settings
T Series Handheld Thermal Camera·User Manual Kaiyang 4. Interval: Set the interval of capturing time-lapse images, ranging from 5s to 24 hours. 5. Quantity: The default is 100, ranging from 1 to 1000. 6. Upload to cloud: After enabled, the photos will be uploaded to the cloud by default. (Not available for some models) 7. - Page 85 T Series Handheld Thermal Camera·User Manual Kaiyang Note: You can only choose one of these two modes. Please follow the below steps to connect to a wireless access point. Use the joystick to go to Hotspot Sharing, and then press the OK button. Touch to configure the hotspot name and hotspot password.
-
Page 86: Configure Mobile Data（Optional
T Series Handheld Thermal Camera·User Manual Kaiyang Select the network to be connected, and press the OK button to pop up a dialog box. After entering the password, use the joystick to go to Connect and press the OK button to confirm. 20.6.2 Configure Mobile Data（Optional）... -
Page 87: Language And Date
T Series Handheld Thermal Camera·User Manual Kaiyang If the Bluetooth is off, press the OK button to activate Bluetooth. Note: make sure the external Bluetooth device is available. Select an available device and press the OK button. It will take about 15 seconds to wait for the list of available devices to appear. When a Bluetooth device is found, select the device to be added and begin pairing. -
Page 88: Auto Screen Timeout
T Series Handheld Thermal Camera·User Manual Kaiyang Date & Time > Date & Time. 20.6.5 Auto Screen Timeout You can set the automatic screen timeout time, and use the joystick to go to the automatic screen timeout. Never by default. 20.6.6 Brightness The screen brightness slider is used to control the brightness of the screen, or you can enable automatic screen brightness. -
Page 89: Gps
T Series Handheld Thermal Camera·User Manual Kaiyang 20.6.8 GPS You can turn GPS on or off, and you can see the location information after turning it on. 20.6.9 Virtual Buttons After virtual buttons are enabled, you can use touch screen instead of physical buttons. The virtual buttons include Image Capture, Video Recording, Gallery, and Auto Focus. -
Page 90: Storage Settings
T Series Handheld Thermal Camera·User Manual Kaiyang 20.6.10 Storage Settings There are two kinds of storage available, cover or pause if the memory is full. Cover if the memory is full: historical files will be covered. Taking pictures or videos at regular ... -
Page 91: Software Update
T Series Handheld Thermal Camera·User Manual Kaiyang Note: This operation will clear all data, including images and other data. Please take cautions. 20.6.13 Software Update You can choose online update (OTA) upgrade or update from SD card. OTA: The device should be connected to the Internet. For the network operation, see 20.6.1 ... - Page 92 T Series Handheld Thermal Camera·User Manual Kaiyang Please follow the below steps. Use the joystick to go to (Import), and press the OK button to pop up a dialog box. Select SD card for importing. (1) Select the path and file to save the smart capture package, and click to import.
- Page 93 T Series Handheld Thermal Camera·User Manual Kaiyang To import from the cloud platform, you need to ensure that you have followed the cloud platform connection operation. For details, see 16 Cloud Platform. (1) Select the smart capture package to be imported, click (Download), and then import.
- Page 94 T Series Handheld Thermal Camera·User Manual Kaiyang Touch the device name to expand the list of subjects. (1) Move the joystick to switch the subject in the list. (2) Go to (Return) to return to the live shooting screen and continue shooting. (3) Go to (Settings), expand Properties Settings, and select the File Name field as required.
-
Page 95: Smart Diagnostics
T Series Handheld Thermal Camera·User Manual Kaiyang 20.8 Smart Diagnostics Generally, there will be different degrees of aging during the work of power equipment, and heating defects caused by current and voltage will occur. In such situation, periodic inspection is required. The inspection process with a thermal camera requires a lot of practical experience. - Page 96 T Series Handheld Thermal Camera·User Manual Kaiyang Select SD card for importing. Select the path and file to save the smart capture package, and click to import. Click (Select All),and (Exit Import). To import from the cloud platform, you need to ensure that you have followed the cloud platform connection operation.
- Page 97 T Series Handheld Thermal Camera·User Manual Kaiyang 4. After importing the smart diagnostic package, it can be used in smart capture mode. For loading the smart capture package, please refer to 20.7 Smart Capture. 5. Touch to view the reference graph and analysis tool settings in the current mode, and then touch the screen to return.
-
Page 98: Technical Data
T Series Handheld Thermal Camera·User Manual Kaiyang 21 Technical Data 21.1 T400 Detector Resolution 480×360 Super Resolution 4× Super-Resolution 25° lens with auto and manual focus; Lens Configuration auto identification after lens change 25°×20° Manual, motorized, one-button center focus, Focus Mode smart focus, 1-touch focus, laser-assisted focus Thermal features IFOV（Spatial... - Page 99 T Series Handheld Thermal Camera·User Manual Kaiyang Temperature Scale Auto, Manual, Linear SD card, standard 64GB, support hot plug, Storage Media max. extendable to 2TB Image Format State Grid Format Yes, add text annotations via text input, preset Image Storage Text Annotations texts, OCR recognition, QR code scanning, voice-text conversion...
- Page 100 T Series Handheld Thermal Camera·User Manual Kaiyang The location information will be displayed on the image, support GPS, BDS or GLONASS Compass Support DMC indication PDF format, the template can be edited and Analysis Report exported in camera Laser Pointer Support Support Area Measurement...
- Page 101 T Series Handheld Thermal Camera·User Manual Kaiyang TYPE-C USB3.0, SD card, SIM card, Tripod External Interfaces Mounting Encapsulation IP54 Weight and Dimension <1.3kg(incl. Battery), 143.53×129.19×307.28 （L×W×H） 1. Camera 2. Standard lens 3. Li-ion battery ×2 4. Charging dock 5. Battery charger 6.
-
Page 102: T630
T Series Handheld Thermal Camera·User Manual Kaiyang 21.1 T630 Detector Resolution 640×512 Super Resolution 4× Super-Resolution 25° lens with auto and manual focus; Lens Configuration auto identification after lens change 25°×20° Manual, motorized, one-button center focus, Focus Mode smart focus, 1-touch focus, laser-assisted focus Thermal features IFOV（Spatial 0.68 mrad... - Page 103 T Series Handheld Thermal Camera·User Manual Kaiyang SD card, standard 64GB, support hot plug, Storage Media max. extendable to 2TB Image Format State Grid Format Yes, add text annotations via text input, preset Image Storage Text Annotations texts, OCR recognition, QR code scanning, voice-text conversion Voice Annotation Support, up to 300s voice...
- Page 104 T Series Handheld Thermal Camera·User Manual Kaiyang （Isotherm） The location information will be displayed on the image, support GPS, BDS or GLONASS Compass Support DMC indication PDF format, the template can be edited and Analysis Report exported in camera Laser Pointer Support Support, displayed on screen Area Measurement...
- Page 105 T Series Handheld Thermal Camera·User Manual Kaiyang Storage Temperature -40°C~ 70°C Range TYPE-C USB3.0, SD card, SIM card, Tripod External Interfaces Mounting Encapsulation IP54 Weight and Dimension 1.3kg(incl. Battery), 143.53×129.19×307.28 （L×W×H） 1. Camera 2. Standard lens 3. Li-ion battery ×2 4.
-
Page 106: Applications Introduction
T Series Handheld Thermal Camera·User Manual Kaiyang 22 Applications Introduction 22.1 Smart Power Inspection and Diagnosis With the development of the power system, higher requirements have also been put forward for the safe operation of infrastructure such as power grids and power plant equipment. Major power companies have invested a lot of manpower and material resources in the inspection and maintenance of lines and equipment to ensure the power transmission quality of power enterprises. -
Page 107: Storage Level Detection
T Series Handheld Thermal Camera·User Manual Kaiyang 22.2 Storage Level Detection There is a temperature difference between the liquid stored in the storage tank and the upper gas. With T series thermal camera, the liquid level of the storage tank can be observed from a long distance, preventing unexpected failures caused by the failure of the liquid level gauge. -
Page 108: Rotary Kiln Defect Monitoring
T Series Handheld Thermal Camera·User Manual Kaiyang 22.4 Rotary Kiln Defect Monitoring Rotary kiln is an important equipment for hazardous waste incineration. The interior of the kiln body is made of refractory materials and the exterior is surrounded by steel plates. With the long-term operation of the rotary kiln, the lining material may get erosive and thin, or even fall off, resulting in abnormally high external temperatures. -
Page 109: Structure Drawing
T Series Handheld Thermal Camera·User Manual Kaiyang 23 Structure Drawing... -
Page 110: Download Software And Update Firmware
T Series Handheld Thermal Camera·User Manual Kaiyang 24 Download Software and Update Firmware 24.1 Download Software 1. Visit our official website: www.infiray.com, and enter Service Support-Product Support Center to find T630. Click to enter Client, download T series handheld PC client Discovery_V2.8.8(001)_WIN64.exe or the Android client android_irpt_tas_V1.5.0_S_build_31.apk. -
Page 111: Cleaning Thermal Camera
T Series Handheld Thermal Camera·User Manual Kaiyang 25 Cleaning Thermal Camera 25.1 Cleaning Camera Housing, Cables and Other Items Camera Housing, Cables and Other Items One of the following liquids can be used. Liquids 1.Warm water 2. Weak detergent solution Cleaning Tools A soft cloth Please follow this procedure:... -
Page 112: Clean Infrared Detector
T Series Handheld Thermal Camera·User Manual Kaiyang Cleaning Tools Absorbent cotton Please follow this procedure (Take dustless cloth as an example). 1.Soak the dustless cloth in the liquid. Cleaning Procedure 2. Squeeze the absorbent cotton to squeeze out the excess cleaning solution. 3. -
Page 113: Technical Hotline
T Series Handheld Thermal Camera·User Manual Kaiyang Worth comes from Service Technical Hotline 400-883-0800 24H Hotline 400-998-3088 Customized Services Visit http://www.infiray.com for more information...
