- Page 1 AT31/AT61/AT61P Online Temperature Measurement Thermal Camera User Manual V1.0.7 IRay Technology Co., Ltd. www.infiray.com...
- Page 2 Introduction to IRay Technology IRay Technology Co., Ltd. concentrates on developing infrared thermal imaging technologies and manufacturing relevant products, with completely independent intellectual property rights. IRay is committed to providing global customers with professional and competitive infrared thermal imaging products and solutions. The main products include IRFPA detectors, thermal imaging modules, and terminal thermal imaging products.
-
Page 3: Table Of Contents
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Table of Contents 1.Legal Disclaimer ............................1 1.1 Legal Disclaimer ..........................1 1.2 Copyright ............................1 1.3 Quality Assurance ..........................1 2.Safety Information .............................2 3.Notice to user ............................3 3.1 Calibration ............................3 3.2 Accuracy ............................3 3.3 Video Teaching .......................... -
Page 4: Legal Disclaimer
TECHNOLOGY or this warranty will not apply. IRAY TECHNOLOGY will, at its option, repair or replace any such defective product free of charge if, upon inspection, the product or accessories prove to be defective, the user can contact with after-sales service department of IRAY TECHNOLOGY within the said warranty period. -
Page 5: Safety Information
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 2.Safety Information WARNING 1. Make sure you read all applicable Material Safety Data Sheets (SDS) and warning labels on containers before you use a liquid. The liquids can be dangerous. Injury to persons can occur. -
Page 6: Notice To User
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 3.Notice to user 3.1 Calibration IRAY TECHNOLOGY recommends that you verify your calibration yearly in order to ensure accuracy. You can verify the calibration through IRAY TECHNOLOGY or third-party organizations. 3.2 Accuracy For very accurate results, we recommended that you wait 30 minutes after you have started the camera before measuring a temperature. -
Page 7: Product Introduction
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 5.Product Introduction Accurate temperature measurement Quick Installation Compact size Main Features Support PoE Several optional lenses The second generation auto-focus algorithm Simultaneous output of temperature data and image data Power detection Industrial detection... -
Page 8: Product Figure And Explanation
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 6.Product Figure and Explanation Explanation Explanation Infrared lens Ethernet/Network cable interface Adapter bracket Reset button Installation holes for tripod and LED light other accessories Accessories from left to right: Power interface Power adapter, gigabit network... - Page 9 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 7. Product Application Scenarios Descriptions PC/Display Exchanger Thermal camera The detected product 5.6.7 Cables...
-
Page 10: Product Models Reference
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 8.Product Models Reference AT31 Model Lens Reserved 3: 7.8mm 4: 13mm AT31 5: 15mm 7: 19mm 8：25mm 3: 7.8mm AT61 5: 15mm 6: 10.6mm 3: 7.8mm 4: 13mm 5: 15mm AT61P 7: 19mm... - Page 11 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual H：support H.264，H.265 and MJPEG network protocols P：support GigE Vision network protocols T should be marked for AT61P with 13mm,15mm,19mm lens Reserved for the customized product Table 8.2 Detailed Info for the Reserved Position For example: AT61P4DSHT stands for AT61P with 13mm lens, Chinese, standard, H.264 ，...
-
Page 12: Lens Parameters
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 9.Lens Parameters Resolution Focal Length FOV（H×V） IFOV 384×288 7.8mm 47°×35.6° 2.17mrad 384×288 13mm 29.6°×22° 1.3mrad 384×288 15mm 25°×18.7° 1.1mrad 384×288 19mm 19.6°×14.7° 0.89mrad 384×288 25mm 14.8°×11.1° 0.68mrad Table 9.1 AT31 Lens Parameters... -
Page 13: Quick Start Guide
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 10.Quick Start Guide Please follow the steps: 1.Install IRT_VMS if the thermal camera is with other networking equipments, and IRT_TAS_AT can be installed on a single thermal camera for temperature measurement and analysis. The software may have version updates. Please refer to the actual version. - Page 14 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 7.The 485 transmission between the thermal camera and the PT can be realized through the RS485 interface on the cable to control the PT. 8.The ALARMIN interface on the cable can be used to manually input signals to trigger the alarm.
-
Page 15: Product And Accessories List
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 11.Product and Accessories List Product and Accessories AT online temperature measuring thermal camera (with adapter bracket) Network cable Power cable Power adapter Table 11.1 Product and Accessories List... -
Page 16: Mechanical Installation
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 12.Mechanical Installation The thermal camera can be mounted via a transfer bracket with four metric M2 mounting holes at the bottom of the mounting interface. WARNING Do not use screws longer than 3.5mm that will damage the thermal camera. -
Page 17: Camera Mounting
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 12.1 Camera Mounting 12.1.1 Illustrations Connecting Camera Interface 1 Interface 2 12.1.2 Explanations 1. Fix the thermal camera at the desired location according to the specific use method. The recommended location is in a sheltered area with a relatively stable thermal state. - Page 18 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Example 1 Cable strain relief with zip ties Example 2 cable strain relief with cable clamps...
-
Page 19: Technical Data
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 13.Technical Data 13.1 AT31 Imaging and Optical Data Resolution 384×288 Thermal Sensitivity/NETD ＜50mK(40mK is optional) @25℃, F#1.0 Image Frequency 50Hz Focus Support Auto-focus/Manual focusing Detector Data Detector Type VOx, Uncooled FPA detector Spectral Range 8～14μm... - Page 20 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Ethernet Ethernet Control and imaging Ethernet Type Gigabit Ethernet Standard IEEE 802.3 Ethernet Connector Type RJ45 Ethernet Image Stream RTSP，ONVIF Ethernet Power Supply POE power supply supported Ethernet Protocol TCP,UDP,ICMP,DHCP Image Adjustment...
- Page 21 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Environmental Data Operating Temperature Range -20℃～60℃ Storage Temperature Range -45℃～85℃ Humidity (operating & storage) 5%～95%RH(no condensation) With EMC design Shock 30g,11ms, all axial Vibration 4.3g, random vibration, all axial Physical Data Weight 430g±5g(without adapter bracket)）...
-
Page 22: At61
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 13.2 AT61 Imaging and Optical Data Resolution 640×512 Thermal Sensitivity/NETD ＜50mK(40mK is optional) @25℃, F#1.0 Image Frequency 25Hz Focus Support Auto-focus/Manual focusing Detector Data Detector Type VOx, Uncooled FPA detector Spectral Range 8～14μm... - Page 23 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Ethernet Ethernet Control and imaging Ethernet Type Gigabit Ethernet Standard IEEE 802.3 Ethernet Connector Type RJ45 RTSP，ONVIF Ethernet Image Stream Ethernet Power Supply POE power supply supported Ethernet Protocol TCP,UDP,ICMP,DHCP Image Adjustment...
- Page 24 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Environmental Data Operating Temperature Range -20℃～60℃ Storage Temperature Range -45℃～85℃ Humidity (operating & storage) 5%～95%RH(no condensation) With EMC design Shock 30g,11ms, all axial Vibration 4.3g, random vibration, all axial Physical Data Weight 430g±5g(without adapter bracket)）...
-
Page 25: At61P
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 13.3 AT61P Imaging and Optical Data Resolution 640×512 Thermal Sensitivity/NETD ＜50mK(40mK is optional) @25℃, F#1.0 Image Frequency 25Hz Focus Support Auto-focus/Manual focusing Detector Data Detector Type VOx, Uncooled FPA detector Spectral Range 8～14μm... - Page 26 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Ethernet Ethernet Control and imaging Ethernet Type Gigabit Ethernet Standard IEEE 802.3 Ethernet Connector Type RJ45 Ethernet Image Stream RTSP，ONVIF Ethernet Power Supply POE power supply supported Ethernet Protocol TCP,UDP,ICMP,DHCP Image Adjustment...
- Page 27 AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Physical Data Weight 430g±5g(without adapter bracket)） Thermal Camera（L×W×H） 55mm×55mm×110mm Base Installation Fix the adapter bracket on the thermal camera with 4 M2*6 screws Housing Material Aluminum Shipping Information Packing Type Carton List of Contents...
-
Page 28: Mechanical Drawings
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 14.Mechanical Drawings... -
Page 29: Common Troubleshooting
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 15.Common Troubleshooting Troubles Possible Cause Solutions Objective lens focal length does not Click auto focus in the software after match aiming the thermal camera at the target Images are blurred No image calibration for a long time... -
Page 30: Cleaning Thermal Camera
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 16.Cleaning Thermal Camera 16.1 Cleaning Camera Housing, Cables and Other Items Camera Housing, Cables and Other Items One of the following liquids can be used. Liquids 1.Warm water 2.A Weak detergent solution... -
Page 31: Cleaning Infrared Lens
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 16.2 Cleaning Infrared Lens Cleaning Infrared Lens One of the following liquids can be used. 1. Commercial lens cleaning liquid with more than Liquids 30% is opropyl alcohol. 2. 96% ethyl alcohol(C OH). -
Page 32: Terms And Definitions
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual 17.Terms and Definitions Terms Definition A type of infrared detector (Focal Plane Array) IFOV A resolution measure method of infrared thermal (Instantaneous Field of View) camera (that is, the field of view of a pixel) The angle of view that the infrared camera can see HFOV is the horizontal angle of FOV，VFOV... -
Page 33: Appendix A Emissivity Of Common Materials
AT31/61/61P Online Temperature Measurement Thermal Camera User Manual Appendix A Emissivity of Common Materials Material Temperature（℃） Emissivity Water 0～100 0.95～0.98 Soil(dry) 0.92 Soil(wet) 0.95 Woods 0.962 Sand Sandstone 0.909～0.935 PVC plastic 0.93 Asphalt 0.967 0.92～0.94 Paint Wallpaper 0.85～0.90 Cloth 0.98 Concrete 0.92...
