PROGRAMMING AND ALARMS
HANDBOOK
CONSOLE
V59
Code 8209009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V59 and is the answer not in the manual?

Questions and answers

Related Manuals for vimec V59

Summary of Contents for vimec V59

  • Page 1 PROGRAMMING AND ALARMS HANDBOOK CONSOLE Code 8209009...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. PROGRAMMING CONSOLE 2. MAIN MENU 2.1 "TEST" menu ............................ 5 2.2 "SET" menu ............................7 2.2.1 Procedure for set menu data storage .................... 8 2.3 "CONFIGURATION" menu ......................... 9 2.3.1 Procedure for configuration menu data storage ................10 2.4 "SAVE/RESTORE"...

  • Page 3: Programming Console

    1. PROGRAMMING CONSOLE The Vimec console connects to the V59 system via a can link. It allows programming of all machine control parameters and allows you to run tests to check external links. The console can be used as a human-machine interface that displays malfunctions and the related alarms.

  • Page 4: Main Menu

    ENTER opens the submenu shown in Fig. 2. UP and DOWN scroll through the submenu, and pressing ENTER opens the submenu. Error? Batt 100% Current error : Vimec 5 9 Error Enter Checks the inputs and the Select mode: Enter...

  • Page 5: Test" Menu

    2.1 "TEST" Menu The "test" menu allows you to check the status of the machine. Pressing ENTER enters into the menu and UP-DOWN scroll through all the test situations. Select mode : “ MAIN MENU Test Enter Actual speed revolutions Motor speed : per second of the motor x .
  • Page 6 The "inputs test" menu is a submenu of the "test" menu and allows you to check the status of all inputs: Eg. Ascent. If pressed the console displays 1, not pressed the console displays 0. Inputs : inputs Test Enter Line: tilt-housing-SB0 Inputs : Tilt/SB0...

  • Page 7: Set" Menu

    2.2 "SET" menu In the "set" submenu you can carry out the machine's adjustment in power and current. To enter it, press ENTER, to return to the main menu press ESC. To scroll through the programming items use UP-DOWN. “Main” menu Select mode : Enter Enter...

  • Page 8: Procedure For Set Menu Data Storage

    2.2.1 Procedure for SET menu data storage PHASE 1 PHASE 3 SELEC PARAMETER Press ENTER to enter into EDIT then press UP to Press ENTER increase the value or DOWN to Decrease it. Press ENTER to go on to the next box PHASE 2 PHASE 4 After...

  • Page 9: Configuration" Menu

    2.3 "CONFIGURATION" menu In the "configuration" submenu you can select the type of machine (right or left), the battery type (lead or lithium), the path and the speed. To change a parameter, enter the corresponding menu and press "ENTER", use "UP / DOWN" to increase or decrease the value. Select mode: “...

  • Page 10: Procedure For Configuration Menu Data Storage

    2.3.1 Procedure for CONFIGURATION menu data storage PHASE 1 PHASE 3 SELEC CONFIG. CONFIG. PARAMETER Press ENTER to enter into EDIT then press UP to Press ENTER increase the Value or DOWN to Decrease it. Press ENTER to go on to the next box PHASE 2 PHASE 4...

  • Page 11: Save/Restore" Menu

    2.4 "SAVE/RESTORE" menu In the console, "upload param" saves up to 9 settings, linking each of them with a sequence number from 1 to 9. With "download param" you can choose one of the programs saved from 1 to 9, and download it to the motor control.

  • Page 12: Position" Menu

    2.5 "POSITION" menu In the "position" menu you can define the floor data, deceleration zones, parking locations. NB: The first thing to do is to "Zero" (moving the machine to the magnet installed on the rail). The maximum permitted length is 50 metres. Select mode : “...

  • Page 13: Floor Data Storage Procedure - Park Or Slow Zone In Manual

    2.5.1 Floor data storage procedure - park or slow zone in manual PHASE 1 PHASE 3 SELEC 0000 left POSITION Floor …… Press ENTER to open EDIT then press UP to Press ENTER increase the Value or DOWN to Decrease it. Press ENTER to go on to the next box...

  • Page 14: Floor Data Storage Procedure - Park Or Slow Zone In Self-Learning

    2.5.2 Floor data storage procedure - park or slow zone in self-learning PHASE 1 PHASE 3 SELEC 0200 on the POSITION Floor …… left Press ENTER 2 times quickly; the right level shows Press ENTER automatically the current value on the left PHASE 4 PHASE 2 0200 on the...

  • Page 15: Alarms" Menu

    2.6 "Alarms" menu In the "alarms" submenu you can record up to 20 alarms, thus creating a log of any malfunctions. In addition to the type of error associated with a number, you can store the hour and the minute when the alarm occurred.

  • Page 16: Config Console" Menu

    2.7 "Config Console" menu In the "config. console" submenu we can select the language, contrast and brightness. Select mode : “Main” menu Config console Enter Press ENTER to choose the type of Language : language. By scrolling UP-DOWN you xxxx can select ITALIAN, ENGLISH, ESPANOL, FRANCAIS, DEUTSCH.

  • Page 17: Table Of Default Parameters

    3 TABLE OF DEFAULT PARAMETERS CONFIGURATION Left / right Acceleration curve: Brake delay 100 ms Deceleration curve Slow zone 40 cm Max ascent speed: 100% Floor zone 30 cm Max descent speed: 100% Battery level (Pb.) 170 Slow zone speed: Battery level (lt) 240 Floor zone speed: Tilt offset...

  • Page 18: Alarms Description

    4 ALARMS DESCRIPTION ERRORS ALARMS Console Green Orange Buzzer Alarm description code light light Crc alarm indication on the console. It occurs after uploading a new software version to the motor; to remove the indication on the console to go on the first page of the alarms and reset all Low battery indication.

  • Page 19: Troubleshooting

    5 TROUBLESHOOTING Load new software (new revision) [26] Reset the alarm going into the first alarm page and setting everything to zero Low battery Low battery [12] The machine goes slow march until it reaches the first intermediate floor or parking position, where it stops until the battery is recharged check the battery if the alarm persists, replace the battery...
  • Page 20 Input tilt Emergency switch SB0 activation [62] Check whether the emergency button is pressed Check the sheath NB: for more complete troubleshooting, refer to handbook 8885375 Main Relay Error The contact of the general relay remains closed The fault is detected when the contact closure is requested. [63] It cannot be restored.
