- Page 1 Model No.: MSA035 Z1, MSA050 Z1 Lifebeing Sensor User’s Manual...
-
Page 2: Product Introduction
Product Introduction This product adopts ZigBee wireless communication data transmission, combined with Merrytek 5.8GHz high-gain microwave presence sensing technology, can analyze people’s behavior status (active, leisure, presence and unoccupied status), and collect environmental illuminance output. The human body state and... - Page 3 MSA035 Z1 Sensing Surface Input: Connecting 120-277Vac Button MSA050 Z1 Input: Connecting Sensing Surface 120-277Vac Button Tolerances: ±0.3mm...
- Page 4 (Radius) (Note 3) Breathing (Stationary state): 2-3m Mounting Height 2.5-4m Installation Flush Mounted (MSA035 Z1), Surface Mounted (MSA050 Z1) Operating Temperature 0℃- 50℃ Storage Temperature -35℃- 80℃ Note: 1. The higher sensitivity, the farther detection range. In case of microwave crossing the wall or false triggering, the sensitivity should be reduced.
-
Page 5: Installation Instruction
Wiring MSA035 Z1 MSA050 Z1 Remarks: Ground wire can be left unconnected 70mm Installation Instruction MSA035 Z1 1. Cut a hole of 70-80mm on the ceiling. 2. Open cover by small straight screw. 3. Loosing clamp and wiring. 4. Screw clamp and put the cover. - Page 6 MSA050 Z1 Bottom Case Mounted Ceiling Mounted To dig a groove on the installation surface to embed the bottom case first: Catch the Self-tapping screws: concealed M3.5x25mm screw chute of the product to the nut of screw A and push it to the end.
- Page 7 Pairing instructions: Long-press the connecting button of sensor to access the pairing mode. Open the APP, go to Add Manually>Sensors>Motion Detector>Motion Detector (Zigbee) and select the gateway to connect. MSA035 Z1 MSA050 Z1 1) Long press the connecting button for more than 3 seconds to enter the pairing mode.
-
Page 8: App Interface
App Interface Human Activity Analysis: 1) No Motion: no one in the detection area. 2) Big Motion: the person is in a state of large movement, such as walking. 3) Minor Motion: people are in a state of micro-movement, such as reading a book or drinking tea. 4) Breathing: The person is in a static state, and only the breathing signal is detected. - Page 9 Fault Cause Remedy Microwave can penetrate Reduce the detection area. glass, wood and other non-metallic materials. The sensor is Installed the sensor 2 meters The sensor is installed close self-triggered away from the wireless to the wireless device. or the load will devices.
- Page 10 After-sales and Warranty Free maintenance service is provided for failures caused by the product during the warranty period. Damages that are not caused by our company's actions such as handling, dropping, installation, use, maintenance, and improper storage by the user are not covered by the warranty. Unauthorized smearing or tampering with labels, model no., product appearances, and circuits are not covered by the warranty.
-
Page 11: Product Details
Merrytek Sensor Warranty Certificate Customer Information: Male/ Customer’s Name Customer’s Phone Female Customer’s Address Product Details: Product Name Model No. Batch Code Date of Purchasing Place of Purchasing Invoice No. Store Address Merrytek Sensor Warranty Certificate Customer Information: Male/ Customer’s Name Customer’s Phone... - Page 12 The product model, parameters and performance of this manual are subject to change without notice. The copyright belongs to Shenzhen Merrytek Technology Co., LTD Shenzhen Merrytek Technology Co., LTD No.17th Building, Dianda Guyuan Industrial Park, Mashantou, Matian, Guangming District, Shenzhen, China, 518106...
