2. Remove the large cover plate from the top profile.
3. Slide the lighting & electricity module in the top profile. Attention:
make sure the lighting & electrification is facing downwards.
4. Reattach the side plate with the four screws. Attention: make sure the
electricity cable goes through the hole of the side plate.
5. Position the top profile between the two A-frames.
a. Make sure the electricity cables goes through the hole of the
A-frame and faces towards the socket you want to use. Connect the
power supply to this connector.
b. Slide the top profile over the adjusting screws so that it is correctly
located so that it already stays in place.
c. First screw an M10 cap nut & washer onto the two adjusting screws
to hold the top profile in place.
6. Make sure the lighting & electricity module is centered. Now insert
two small cover plates to the top profile, left and right next to the
lighting & electricity module, with the recess facing outwards as
shown in the drawing.
Now go back to step 5 on page 17 (standard module).
Now go back to step 9 on page 34 (extension module).
Connecting multiple LED modules
1. Remove the side plate with hole by unscrewing the four bolts and set
everything aside.
2. Remove the large cover plate from the top profile.
3. Slide the lighting & electricity module in the top profile. Attention:
make sure the lighting & electrification is facing downwards.
4. Reattach the side plate with the four screws. Attention: make sure the
electricity cable goes through the hole of the side plate.
5. Position the top profile between the two A-frames.
a. Make sure the electricity cables goes through the hole of the
A-frame and faces towards the socket you want to use.
b. Slide the top profile over the adjusting screws so that it is correctly
located so that it already stays in place.
