Setup

VOLUME CONTROL SETUP

SETUP VOLUME CONTROLS
Opens the VOLUME CONTROL SETUP menu, which is used to configure Main Zone and Zone 2 volume levels.
MAIN MENU SETUP
INPUTS
MODE ADJUST
SPEAKERS
AUDIO CONTROLS
REAR PANEL CONFIG
SETUP
DISPLAYS
VOLUME CONTROLS
TRIGGER
LOCK OPTIONS
LIVE! CALIBRATION
Default
Parameter
Setting
MAIN PWR ON –30dB
MUTE LEVEL –30dB
ZONE PWR ON –30dB
MAX VOLUME +12dB
MAIN PWR ON
LAST LVL, –80 to +12dB
SETUP VOLUME CONTROLS MAIN PWR ON
Sets the Main Zone volume level that will be selected whenever the
Main Zone is activated. When set to LAST LVL, the Main Zone
activates at the volume level that was last selected in the previous
operating session.
3-66

VOLUME CONTROL SETUP

MAIN PWR ON
MUTE LEVEL
ZONE PWR ON
MAX VOL
Possible Settings
LAST LVL, –80 to +12dB
FULL, –40dB, –30dB, –20dB, –10dB
LAST LVL, –80 to +12dB
–80 to +12dB
LAST LVL, -80 to +12dB
-30dB
-30dB
-30dB
+12dB
MUTE LEVEL
FULL MUTE, –40dB, –30dB, –20dB, –10dB
SETUP VOLUME CONTROLS
Sets the amount of attenuation that occurs in the Main Zone when the
front-panel or remote control Mute button is pressed. When set to FULL
MUTE, Main Zone volume level will be fully attenuated. Otherwise,
Main Zone volume level will be attenuated to the selected level.
ZONE PWR ON
SETUP VOLUME CONTROLS
Sets the Zone 2 volume level that will be selected whenever Zone 2 is
activated. When set to LAST LVL, Zone 2 activates at the volume level
that was last selected in the previous operating session.
MAX VOLUME
SETUP VOLUME CONTROLS
Limits the volume to the MAX VOLUME parameter value if you
attempt to adjust the volume above that level.
VOLUME CONTROL SETUP
MAIN PWR ON -30dB
MUTE LEVEL -30dB
ZONE PWR ON -30dB
MAX VOL +12dB
MUTE LEVEL
LAST LVL, –80 to +12dB
ZONE PWR ON
–80 to +12dB
MAX VOLUME
Lexicon
-10dB
-20dB
-30dB
-40dB
FULL MUTE
-80 to +12dB
