Summary of Contents for Victron energy MultiPlus 12/3000/120-16

  • Page 1 Manual Handleiding Manuel Anleitung Manual Användarhandbok MultiPlus (with firmware xxxx400 or higher) 12 | 3000 | 120 - 16 | 230/240V 12 | 3000 | 120 - 50 | 230/240V 24 | 3000 | 70 - 16 | 230/240V 24 | 3000 | 70 - 50 | 230/240V 48 | 3000 | 35 - 16 | 230/240V 48 | 3000 | 35 - 50 | 230/240V...
  • Page 2: Safety Instructions

    NOTE: This manual is intended for products with firmware xxxx400 or higher (with x any number) The firmware number can be found on the microprocessor, after removing the front panel. It is possible to update older units, as long as that same 7 digit number starts with either 26 or 27. When it starts with 19 or 20 you have an old microprocessor and it is not possible to update to 400 or higher.
  • Page 3: Automatic And Uninterruptible Switching

    MultiPlus will supply additional power from the battery. For more information see our white papar Self Consumption or Grid independence with the Victron Energy Storage Hub.
  • Page 4: Battery Charger

    General Technical Information our website. 2.3 Self consumption – solar energy storage systems For more information see our white paper Self Consumption or Grid independence with the Victron Energy Storage Hub. The appropriate software can be downloaded from our website.
  • Page 5: Operation

    3. OPERATION 3.1 On/Off/Charger Only Switch When switched to "on", the product is fully functional. The inverter will come into operation and the LED "inverter on" will light up. An AC voltage connected to the "AC in" terminal will be switched through to the "AC out" terminal, if within specifications. The inverter will switch off, the "mains on"...
  • Page 6 3.4 LED Indications LED off LED flashes LED illuminated Inverter Charger Inverter Mains on Inverter on Bulk Overload The inverter is on and supplies power to the load. Absorption Low battery charger only Float Temperature Charger Inverter Mains on Inverter on The nominal output of the inverter is Bulk Overload...
  • Page 7 Charger Inverter Mains on Inverter on The inverter has switched off due to Bulk Overload the electronics temperature being too high. Absorption Low battery charger only Float Temperature Charger Inverter Mains on Inverter on -If the LEDs are flashing alternately, the battery is nearly exhausted and Bulk Overload...
  • Page 8 Charger Inverter Mains on Inverter on The mains voltage is switched Bulk Overload through and the charger operates in float mode. Absorption Low battery charger only Float Temperature Charger Inverter Mains on Inverter on The mains voltage is switched Bulk Overload through and the charger operates in equalize mode.
  • Page 9: Installation

    4. Installation This product may only be installed by a qualified electrical engineer. 4.1 Location The product must be installed in a dry and well-ventilated area, as close as possible to the batteries. There should be a clear space of at least 10 cm around the appliance for cooling.
  • Page 10 Maximum torque: 1,6 Nm The terminal blocks can be found on the printed circuit board, see Appendix A. 4.3.1 Models with 16 A transfer capacity (eg MultiPlus 12/3000/120-16 230 V) AC-in • The AC input cable must be connected to the terminal block “AC–in”.
  • Page 11 4.4 Optional Connections A number of optional connections are possible: 4.4.1 Second Battery The MultiPlus has a connection for charging a starter battery. For connection see Appendix A. 4.4.2 Voltage Sense For compensating possible cable losses during charging, two sense wires can be connected with which the voltage directly on the battery or on the positive and negative distribution points can be measured.
  • Page 12 5. Configuration • Settings may only be changed by a qualified electrical engineer. • Read the instructions thoroughly before implementing changes. During setting of the charger, the AC input must be removed. • 5.1 Standard settings: ready for use On delivery, the MultiPlus is set to standard factory values. In general, these settings are suitable for single-unit operation. Warning: Possibly, the standard battery charging voltage is not suitable for your batteries! Refer to the manufacturer's documentation, or to your battery supplier!
  • Page 13: Inverter Voltage

    Inverter voltage Output voltage of the MultiPlus in battery operation. Adjustability: 210 – 245 V Stand-alone / parallel operation / 2-3 phase setting Using several devices, it is possible to: • increase total inverter power (several devices in parallel) create a split-phase system by stacking (only for MultiPlus units with 120 V output voltage) •...
  • Page 14 Note: when WeakAC is on, the maximum charge current is reduced by approximately 20 %. Not adjustable with DIP switches. BoostFactor Change this setting only after consulting with Victron Energy or with an engineer trained by Victron Energy! Not adjustable with DIP switches. Programmable relays The models with 16 A transfer capacity (see section 4) are equipped with one programmable relay that by default is set as an alarm relay.
  • Page 15 5.3 Configuration by computer All settings can be changed by means of a computer or with a VE.Net panel (except for the multi-functional relay and the VirtualSwitch when using VE.Net). The most common settings can be changed by means of DIP switches (see Section 5.5). NOTE: This manual is intended for products with firmware xxxx400 or higher (with x any number) The firmware number can be found on the microprocessor, after removing the front panel.
  • Page 16 5.5 Configuration with DIP switches A number of settings can be changed using DIP switches (see appendix A, position M). Note: When changing settings with DIP switches in a parallel or split-phase/3-phase system one should be aware that not all settings are relevant on all Multis.
  • Page 17 Procedure The AC input current limit can be set using DIP switches ds8, ds7 and ds6 (default setting: 50 A, automatically limited to 16 A in 16 A models). Procedure: set the DIP switches to the required value: off = 6 A (1.4 kVA at 230 V) on = 10 A (2.3 kVA at 230 V) off = 12 A (2.8 kVA at 230 V) on = 16 A (3.7 kVA at 230 V)
  • Page 18 5.5.1.5 Examples examples of settings: DS-8 AC input DS-8 DS-8 DS-8 DS-7 AC input DS-7 DS-7 DS-7 DS-6 AC input DS-6 DS-6 DS-6 DS-5 AES DS-5 DS-5 DS-5 DS-4 Ch. current DS-4 DS-4 DS-4 DS-3 Ch. current DS-3 DS-3 DS-3 DS-2 N/A DS-2 DS-2...
  • Page 19 Step 2: Exemplary settings Example 1 is the factory setting (since factory settings are entered by computer, all DIP switches of a new product are set to ‘off’ and do not reflect the actual settings in the microprocessor). DS-8 Ch. voltage DS-8 DS-8 DS-8...
  • Page 20: Maintenance

    The MultiPlus does not require specific maintenance. It will suffice to check all connections once a year. Avoid moisture and oil/soot/vapours, and keep the device clean. 7. Error indications With the procedures below, most errors can be quickly identified. If an error cannot be resolved, please refer to your Victron Energy supplier. 7.1 General error indications...
  • Page 21 One alarm LED The inverter is switched off due to Check this table for appropriate lights and the alarm activation by the lighted LED. measures in regard to this alarm second flashes. The flashing LED indicates that the state. inverter was about to switch off due to the related alarm.
  • Page 22 7.2 Special LED indications (for the normal LED indications, see section 3.4) Bulk and absorption LEDs flash Voltage sense error. The voltage measured at the voltage synchronously (simultaneously). sense connection deviates too much (more than 7 V) from the voltage on the positive and negative connection of the device. There is probably a connection error.
  • Page 23 3) Switch on all other devices one by one until the error message reoccurs. conjunction with this device. 4) Update the firmware in the last device that was switched on. Should not occur. Switch all equipment off, and then on again. Contact Internal error. Victron Energy if the problem persists.
  • Page 24: Technical Specifications

    8. Technical specifications MultiPlus 12/3000/120-16 230 V 24/3000/70-16 230 V 48/3000/35-16 230 V 12/3000/120-50 230 V 24/3000/70-50 230 V 48/3000/35-50 230 V Nominal Battery voltage 12 V battery 24 V battery 48 V Battery PowerControl / PowerAssist AC input Input voltage range: 187-250 VAC Input frequency: 50/60 Hz Cos Φ...
  • Page 25 Modèles ayant une capacité de transfert de 16 A (Ex. : MultiPlus 12/3000/120 - 16 230 V) Modelle mit 16 A Transferkapazität (z. B. MultiPlus 12/3000/120-16 230 V) Modelos con capacidad de transferencia de 16 A (p.ej. MultiPlus 12/3000/120-16 230V)
  • Page 26 Models with 50 A transfer capacity (eg MultiPlus 12/3000/120-50 230V) Modèles ayant une capacité de transfert de 50 A (Ex. : MultiPlus 12/3000/120 - 50 230 V) Modelle mit 50 A Transferkapazität (z. B. MultiPlus 12/3000/120-50 230 V) Modelos con capacidad de transferencia de 50 A (p.ej. MultiPlus 12/3000/120-50 230V) Modeller med 50 A överföringskapacitet (t.ex.
  • Page 27 A AC input 16 A. Left to right: PE (earth/ground), L (phase), N (neutral). AC input 50 A. Left to right: L (phase), N (neutral), PE (earth/ground). B 2x RJ45 connector for remote control and/or parallel / three-phase operation C Load connection. AC out1. Left to right: L (phase), N (neutral), PE (earth/ground). D Load connection.
  • Page 28 Modèles ayant une capacité de transfert de 16 A (Ex. : MultiPlus 12/3000/120 - 16 230 V) Modelle mit 16 A Transferkapazität (z. B. MultiPlus 12/3000/120-16 230 V) Modelos con capacidad de transferencia de 16 A (p.ej. MultiPlus 12/3000/120-16 230V) Modeller med 16 A överföringskapacitet (t.ex. MultiPlus12/3000/120-16 230 V)
  • Page 29 Models with 50 A transfer capacity (eg MultiPlus 12/3000/120-50 230V) Modèles ayant une capacité de transfert de 50 A (Ex. : MultiPlus 12/3000/120 - 50 230 V) Modelle mit 50 A Transferkapazität (z. B. MultiPlus 12/3000/120-50 230 V) Modelos con capacidad de transferencia de 50 A (p.ej. MultiPlus 12/3000/120-50 230V) Modeller med 50 A överföringskapacitet (t.ex.
  • Page 30 APPENDIX C: Parallelconnection ANNEXE C : Connexion en parallèle ANHANG C: Parallelbetrieb APÉNDICE C: Conexión en paralelo APPENDIX C: Parallellanslutning SLAVE Unit 3 SLAVE Unit 2 MASTER Unit 1 Panel BAT- BAT- BAT- BAT+ BAT+ BAT+ PE OUT To load AC OUT 1 N AC OUT 1 L To load...
  • Page 31 APPENDIX D: Three phase connection ANNEXE D : Configuration triphasée ANHANG D: Drei Phasen-Betrieb APÉNDICE D: Conexión trifásica APPENDIX D: Trefasanslutning SLAVE Unit 3 SLAVE Unit 2 MASTER Unit 1 Panel BAT- BAT- BAT- BAT+ BAT+ PE OUT To load AC OUT 1 AC OUT 1 L3 AC OUT 1 L2...
  • Page 32 APPENDIX E: Charge characteristic ANNEXE E : Courbe de charge ANHANG E: Ladekennlinie APÉNDICE E: Características de carga APPENDIX E: Laddningsfunktion Charge current 120% 100% Amps Time Volts Charge voltage Time 4-stage charging: Bulk Entered when charger is started. Constant current is applied until nominal battery voltage is reached, depending on temperature and input voltage, after which constant power is applied up to the point where excessive gassing is starting (14.4 V resp.
  • Page 33 APPENDIX F: Temperature compensation ANNEXE F : Compensation de température APPENDIX F: Temperaturkompensation APÉNDICE F: Compensación de temperatura APPENDIX F: Temperaturkompensation EN Default output voltages for Float and Absorption are at 25 °C. Reduced Float voltage follows Float voltage and Raised Absorption voltage follows Absorption voltage.
  • Page 34 APPENDIX G: Dimensions ANNEXE G : Dimensions ANHANG G: Maße APÉNDICE G: Dimensiones APPENDIX G: Dimensioner...
