- Page 1 User’s manual Digital Audio Baby Monitor ht t p: // hk phones.v tec h.c om Model: BM2000...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMpOrTANT SAFETy INSTrUCTIONS ......1 SET Up THE BABy MONITOr ..........4 Package Contents ...............4 Baby unit installation ............5 Parent unit installation ............6 GET TO KNOW THE BABy MONITOr ......7 Baby unit overview ..............7 Parent unit overview ............8 Parent unit lights ..............9 Parent unit display .............10 Positioning and operating range ........11 3.5.1... - Page 3 DEFAULT SETTINGS ............21 TECHNICAL SpECIFICATIONS ........22...
-
Page 4: Important Safety Instructions
IMpOrTANT SAFETy INSTrUCTIONS When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: Follow all warnings and instructions marked on the product. Adult setup is required. This product is intended as an aid. - Page 5 Do not place this product on an unstable table, shelf, stand or other unstable surfaces. This product should not be placed in any area where proper ventilation is not provided. Slots and openings in the back or bottom of this product are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug.
- Page 6 Cautions Use and store the product at a temperature between 10 C and 39 Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source. Batteries should not be exposed to excessive heat such as bright sunshine or fire.
-
Page 7: Set Up The Baby Monitor
SET Up THE BABy MONITOr package Contents The package contains the following items: • 1 Parent unit (BM2000 PU) • 1 Baby unit (BM2000 BU) • 1 Parent unit battery compartment cover • 2 Batteries for parent unit • 2 Power adapters •... -
Page 8: Baby Unit Installation
Baby unit installation The baby unit is powered by mains power. To connect the baby unit to the mains power: Choose either power adapter that comes with the package. Insert the DC plug of the power adapter into the DC socket on the side of the baby unit. -
Page 9: Parent Unit Installation
parent unit installation The package comes with two rechargeable batteries. You can power up the parent unit by using two rechargeable batteries or by connecting it to the mains power. However, even if the parent unit is connected to the mains power, we recommend you to also install the rechargeble batteries. -
Page 10: Get To Know The Baby Monitor
GET TO KNOW THE BABy MONITOr Baby unit overview 1 _ power indicator On when the baby unit is switched on. Off when the baby unit is switched off. (On / off) Press and hold to turn the baby unit on / off. (Skip) 4 _ _ (Volume down) Press to decrease the speaker volume. -
Page 11: Parent Unit Overview
parent unit overview 1 _ Sensitivity LEDs 11 _ Talk 2 _ power Indicator Light Press and hold to talk to the baby unit. (On / off) 12 _ Belt Clip Press and hold to turn on or 13 _ Battery Compartment off. -
Page 12: Parent Unit Lights
parent unit lights 3 green lights and 2 red lights indicating the sound level detected by the baby unit. Green lights indicate a moderate level of sound is detected. Red lights indicate a higher level of sound is detected. More lights turn on when the sound level detected increases. -
Page 13: Parent Unit Display
parent unit display Connection status displays when strong signal strength is detected between the baby unit and the parent unit. displays when moderate signal strength is detected between the baby unit and the parent unit. displays when the link between the baby unit and the parent unit is lost. -
Page 14: Positioning And Operating Range
positioning and operating range 3.5.1 position the audio monitor Place the parent unit within the operating range of the baby unit. We recommend the parent unit is at least 1.5 metres away from the baby unit to avoid audio feedback. If you still experience audio feedback, move the parent unit and the baby unit farther apart. -
Page 15: Using Your Baby Monitor
USING yOUr BABy MONITOr Using the menu 4.1.1 To enter the parent unit menu: Press MENU when the parent unit is not in use. MENU Press to scroll to the desired feature. Press to enter that feature menu. MENU Press to scroll to the desired option. -
Page 16: Sound Alert
Sound alert When the parent unit speaker volume is set to off, you can set the parent unit to beep whenever the baby unit detects sounds above the preset threshold volume. To set the sound alert: Press MENU when the parent unit is not in use. Press to scroll to SOUND ALErT, then press MENU. -
Page 17: Reset
reset You can restore all the adjustable settings back to their original factory settings. To reset the baby monitor: Press MENU when the parent unit is not in use. Press to scroll to rESET, then press MENU. The screen displays CONFIrM? Press MENU to confirm. The screen displays SAVED. -
Page 18: Baby Unit Operation
BABy UNIT OpErATION power the bay unit on or off • Press and hold for 2 seconds to turn on the baby unit. The Power indicator light flashes once and turns on. • Press and hold for 2 seconds to turn off the baby unit. The Power indicator light turns off. -
Page 19: Play Lullaby
play lullaby There are 5 lullabies to choose from. The selected lullaby plays repeatedly. 5.4.1 To play lullabies: Press to play lullabies. 5.4.2 To stop lullabies: Press again to stop playing lullabies. 5.4.3 To skip to the next lullabies: Press to skip to the next lullaby. -
Page 20: Talk To The Baby Unit
Talk to the baby unit You can broadcast messages from the parent unit to the baby unit. To talk to the baby unit: Press and hold TALK on the side of the parent unit. Speak towards the microphone on the parent unit. The screen displays TALK. Your voice is broadcast to the baby unit. -
Page 21: Troubleshooting
TrOUBLESHOOTING If you have difficulty with your audio monitor, please try the suggestions below. My audio monitor does not work at all. • Make sure the baby unit, parent unit and the batteries are installed and charged correctly. For optimum daily performance, charge the parent unit when it is not in use. - Page 22 The parent unit plays any sounds from the baby unit and I think it is too noisy. • You may need to adjust the speaker volume on the parent unit. The parent unit does not play any sound when there is noise from the baby unit.
- Page 23 The battery does not charge in the parent unit or the parent unit battery does not accept charge. • Make sure the batteries are installed in the parent unit battery compartment correctly. The Charging indicator light on the parent unit should be on when charging. •...
-
Page 24: Default Settings
DEFAULT SETTINGS Features parent unit Baby unit Nightlight Language ENGLISH Lullaby Lullaby 1- TWINKLE STAR Sound Alert Termperature Celcius format Speaker volume Level 3 Level 3... -
Page 25: Technical Specifications
TECHNICAL SpECIFICATIONS No. of channels: Frequency: 1881.792 - 1897.344 MHz power supply Electrical power: Baby unit: Ten Pao - S004LS0600045 Input: 100 - 240VAC 50/60Hz 150mA Output: 6VDC 450mA Parent unit: Ten Pao - S004LS0600045 Input: 100 - 240VAC 50/60Hz 150mA Output 6VDC 450mA Battery Information: Parent unit: GPI - VTHC043C00,... - Page 26 Suite 1601, Lever Tech Centre, 69-71 King Yip Street, Kwun Tong, Kowloon, Hong Kong. Customer Service Hotline: (852) 2666 5558 Technical Inquiry Hotline: (852) 2667 7433 VTECH TELECOMMUNCATIONS LTD. A member of THE VTECH GrOUp OF COMpANIES. © 2013 VTech Telecommunications Ltd. All Rights Reserved.
