Tronair 02-7837C0110 Operation & Service Manual

5 ton (4.5 metric ton) two stage jack
Hide thumbs

Advertisement

Table of Contents

OPERATION & SERVICE MANUAL
Models: 02-7837C0110
02A7837C0110
5 Ton (4.5 Metric Ton)
Two Stage Jack
07/2018 - Rev. 03
Tronair, Inc.
Phone: (419) 866-6301 | 800-426-6301
1 Air Cargo Pkwy East
Web: www.tronair.com
Swanton, OH 43558
Email: sales@tronair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 02-7837C0110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tronair 02-7837C0110

Summary of Contents for Tronair 02-7837C0110

  • Page 1 OPERATION & SERVICE MANUAL Models: 02-7837C0110 02A7837C0110 5 Ton (4.5 Metric Ton) Two Stage Jack 07/2018 - Rev. 03 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
  • Page 2 REVISION DATE TEXT AFFECTED 04/2007 Original Release 02/2012 Major Revision 04/2014 Modified Parts list 07/2018 Major Revision...
  • Page 3 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 DESCRIPTION..............................1 MODEL & SERIAL NUMBER ..........................1 MANUFACTURER .............................. 1 FUNCTION................................1 SAFETY INFORMATION ..............................1 USAGE AND SAFETY INFORMATION ......................1 WARNING AND DANGER SIGNS ........................
  • Page 4 5 Ton Two Stage Jack This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
  • Page 5 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack ENVIRONMENTAL SAFETY FEATURES: Jack is non-polluting. See Appendix V Material Safety Data Sheet for the recommended hydraulic fluid (MIL-PRF-5606). NECESSARY PERSONAL PROTECTIVE EQUIPMENT CAUTION! Always wear safety glasses. SAFETY GUIDELINES CAUTION! Do not place hands on top of jack near ram locknuts while lowering jack.

  • Page 6: Installation

    Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack ASSEMBLY This product is shipped completely assembled and tested and requires no further assembly before operation. The following sections apply when servicing the unit. GENERAL INSTRUCTIONS  This product should be assembled and/or repaired using good workmanship practices and proper tools. Bolts and elastic stopnuts should be tightened to a torque not to exceed industry standards for Grade '5' bolts.

  • Page 7: Numerical Values

    Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack OPERATION OPERATING PARAMETERS:  The user shall work in accordance with the Operation & Service Manual.  It is not allowed to work under the raised load until it is secured by suitable means, i.e. Ram Locknut.
  • Page 8  Load test jacks annually.  Only order replacement parts from Tronair.  Failure to comply could result in premature failure below certified weight and could cause serious injury including death. Correct Pin Placement 07/2018 | Rev.
  • Page 9 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack 6.4.2 Jack Instructions (continued) Incorrect Pin Placements Washer In Ball Lock In Washer On Top Of Locking Pin Not In Ram Protection Ring Ram Protection Ring Ram Protection Ring Ram Protection Ring...
  • Page 10 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack 6.4.2 Jack Instructions (continued) If air pump is to be used, be sure shop air needle valve is closed and attach shop air (125 psi/8.6 bars Maximum) to needle valve. Open needle valve and operate air pump. Close needle valve when ram reaches required height.

  • Page 11: Troubleshooting

    Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack TROUBLE SHOOTING TROUBLE PROBABLE CAUSE ACTION Fluid leakage at pump piston Damaged backup ring, o-ring, piston or Replace pump or pump body pump body External fluid leakage at Damaged o-ring, backup ring or inner Remove ram(s) as a unit from cylinder.

  • Page 12: Maintenance Schedule

    Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack 10.0 MAINTENANCE 10.1 GENERAL  All maintenance and/or repair work should be done using good workmanship practices and proper tools.  The work area should be clean and free of dirt.
  • Page 13 GUARANTEES/LIMITATION OF LIABILITY Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the...
  • Page 14 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description H-1009-01 Assembly, Handle H-1128-02 Spring K-2649 Kit, Jack Weldment Replacement; consists of:...
  • Page 15 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description N-2788-02-S-B Elbow, 90 Male, 1/4 Hose x SAE #6 TF-1043-03*21.0 Assembly, Hose N-2001-08-S-B Elbow, Straight Thread, SAE #6 x 3/8-37...
  • Page 16 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description N-2789-01-S-B Connector, Straight Male, 1/4 Hose x SAE #4 N-2740-04-S-B Tee, Male Branch, SAE #4 K-1061-02 Kit, Reservoir Replacement;...
  • Page 17 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description K-3333 Assembly, Blowgun H-1536-19 Caplug, Tapered Z-3840 Assembly, Air Pump; consists of: TF-1043-03*23.0...
  • Page 18 Models: 02-7837C0110 and 02A7837C0110 5 Ton Two Stage Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Pin, ½" diameter x 2.5" long “D” G-1318-0825 TR-1026 Ring, Ram Protection...
  • Page 19 APPENDIX I Hydraulic Schematic...
  • Page 21 Hydraulic Schematic...
  • Page 23 APPENDIX II Haskel Air Pump Manufacturer Data...
  • Page 51 APPENDIX III Declaration of Conformity...

  • Page 53: Declaration Of Conformity

    Relevant standards complied with by the machinery: EN ISO 12100-1 Identification of person empowered to sign on behalf of the Manufacturer: Quality Assurance Representative Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558...
  • Page 55 APPENDIX IV Safety Data Sheet MIL-PRF-5606 Hydraulic Fluid...
  • Page 69 APPENDIX V Maintenance Schedule...
