User Manual
7300
7305
See Wi-Fi Setup Guide for Wi-Fi Setup Instructions
Read all instructions before proceeding
Store this manual for future reference
©2016 Braeburn Systems LLC • All Rights Reserved • Made in China.
Universal Programmable
Smart Wi-Fi Thermostats
For 1 Heat / 1 Cool Systems
For Systems Up to 3 Heat / 2 Cool
®
7300-110-01
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Braeburn 7305
Summary of Contents for Braeburn 7305
- Page 1 For Systems Up to 3 Heat / 2 Cool See Wi-Fi Setup Guide for Wi-Fi Setup Instructions Read all instructions before proceeding Store this manual for future reference 7300-110-01 ©2016 Braeburn Systems LLC • All Rights Reserved • Made in China.
-
Page 2: Table Of Contents
Contents 1 About Your Thermostat 4 Operating Your Thermostat Thermostat Features ..........3 Setting the System Control Mode ......21 Thermostat and Display ........... 4 Setting the Fan Control Mode ....... 22 Setting the Temperature ........23 2 Setting User Options Status Indicators .......... -
Page 3: About Your Thermostat
Congratulations! You are in control of one of the easiest-to-use thermostats on the market today. This thermostat has been designed to provide you with years of reliable performance and comfort control. Features • Optional Wi-Fi connectivity – control and monitor thermostat from a smartphone, tablet or computer. •... - Page 4 1 About Your Thermostat BACK NEXT User Manual...
-
Page 5: Thermostat And Display
Thermostat Display Room Temperature ...... Displays the current room temperature Set Temperature ......Displays the current set point temperature Outdoor Temperature Indicator ... Displays along with the outdoor temperature reading** BACK Indicator* ......BACK button is active NEXT Indicator*......NEXT button is active Service Indicators ...... - Page 6 1 About Your Thermostat INSTRUCTIONS BACK NEXT DAY/TIME User Manual...
- Page 7 Quick Reference Instructions ..Stored in slot located at top of thermostat SpeedBar ........Increases or decreases settings (time, temperature, etc.) ® Outdoor Temperature ....If a Braeburn outdoor sensor was connected you can view the outdoor ® PROG and HOLD temperature by pressing the buttons at the same time.
-
Page 8: Setting User Options
2 Setting User Options INSTRUCTIONS Advanced User Options User options allow you to customize some of your INSTRUCTIONS thermostat’s features. Most users will not need to make any changes to the settings in this section. To access the User Options menu, press and hold the RETURN button for approximately 3 seconds until the screen changes and displays the first User Option. -
Page 9: Table Of User Options
Table of User Options NOTE: Some user options may not be available, depending on how your thermostat was configured in the Installer Settings (see Installer Guide). A detailed description of each User Option follows this table. No. User Options Factory Setting Comments Default... -
Page 10: Service Monitors (Filter, Uv And Humidifier Pad)
Service Monitors (Filter, UV and Humidifier Pad) User Options 1, 2 and 3 There are three user selectable service monitors that will display reminders for a required air filter, UV bulb or humidifier pad replacement. The SERVICE segment flashes in the display along with FILTER, UV or HUMID. -
Page 11: Temporary Override Adjustment Limit
Temporary Override Adjustment Limit User Option 5 The Temporary Override Adjustment Limit will limit how much the temperature can be adjusted from the current set point when the thermostat is used in the programmable mode. This setting will not allow the user to override the temperature past the selected limit amount of 1, 2 or 3 degrees from the current set point. -
Page 12: Wi-Fi Clear
Wi-Fi Clear User Option 8 Use this setting if you no longer want to be connected to your Wi-Fi network or if you change Wi-Fi routers. Select WIFI to skip changes to your network settings. Select CL WIFI to clear all Wi-Fi network settings. You can set up Wi-Fi again at a later time if desired (see Wi-Fi Setup Guide). -
Page 13: Tips Before Setting Your Program Schedule
Tips Before Setting Your Program Schedule • Make sure your current time and day of the week are set correctly. • When programming, make sure the AM and PM indicators are correct. • Various installer settings such as auto changeover mode and temperature adjustment limits may affect your programming flexibility. -
Page 14: Energy Saving Programs
Energy Saving Programs This thermostat comes pre-programmed with a default energy saving program. The following tables outline the pre-programmed times and temperatures for heating and cooling in each of your 4 daily events (2 events if configured for commercial mode). If you wish to use these settings then no further programming is necessary: Residential 7 Day Programming Commercial 2 Event Programming Factory Settings... - Page 15 Residential 5-2 Day Programming– Weekday/Weekend Factory Settings 4 Event Time: 6:00 am Time: 6:00 am Heat: 70˚ F (21˚ C) Heat: 70˚ F (21˚ C) Cool: 78˚ F (26˚ C) Cool: 78˚ F (26˚ C) Time: 8:00 am Time: 8:00 am Heat: 62˚...
-
Page 16: Programming A 7 Day Residential Schedule
Programming a 7 Day Residential Schedule The 7 day residential programming mode gives you the option to program individual days (1 day at a time) or to use SpeedSet and program the entire week (all 7 days) with a 4 event program schedule. Setting All 7 Days at Once (SpeedSet ®... - Page 17 Setting Individual Days (7 Day Residential) 1. Press the PROG button. The display will switch to programming mode. M (Monday) will be displayed and the hour will be flashing. 2. Press SYSTEM to select HEAT or COOL. 3. Press DAY/TIME to select the day you would like to program.
-
Page 18: Programming A 5-2 Day Residential Schedule
Programming a 5-2 Day Residential Schedule The 5-2 day residential programming mode allows you to program Monday - Friday with one 4 event schedule and then allows you to change Saturday and Sunday with a different 4 event schedule. 1. Press the PROG button. The display will switch to programming mode. -
Page 19: Programming A 7 Day Commercial Schedule
Programming a 7 Day Commercial Schedule The 7 day commercial programming mode gives you the option to program individual days (1 day at a time) or to use SpeedSet and program the entire week (all 7 days) with a 2 event program schedule. Setting All 7 Days at Once (SpeedSet ®... - Page 20 Setting Individual Days (7 Day Commercial) 1. Press the PROG button. The display will switch to programming mode. M (Monday) will appear and the hour will flash. 2. Press SYSTEM to select HEAT or COOL. 3. Press DAY/TIME to select an individual day. 4.
-
Page 21: Operating Your Thermostat
HEAT or COOL. COOL Only your cooling system will operate. Heating and cooling systems are off. HEAT Only your heating system will operate EMER Operates a backup heat source (Emergency Heat) for heat pump systems only (Model 7305 only). User Manual... -
Page 22: Setting The Fan Control Mode
Setting the FAN Control Mode The Fan Control has 3 modes of operation – AUTO, ON, and PROG. The mode can be selected by pressing the FAN button to scroll through the different modes. NOTE: Depending on how your thermostat was configured, some fan modes may not be available. AUTO The system fan will run only when your heating or cooling system is running. -
Page 23: Setting The Temperature
Setting the Temperature SpeedBar Temporary Adjustment – Press the SpeedBar up or ® down to adjust the current set temperature. If your thermostat is running in 5-2 or 7 day programmable mode, the set temperature will change back to your original programmed settings when your next scheduled change in temperature occurs. -
Page 24: Status Indicators
(model 7305 heat pump systems only). CHECK There is a potential problem with your system. Contact a local service technician (model 7305 only). SERVICE User selectable service reminder for changing a filter, UV air purifier bulb or humidifier pad (see Service Monitors, page 10). -
Page 25: Program Event Indicator
Program Event Indicators Program Event Indicator Program event indicators appear in the display to let you know what part of your current program is active. • In Residential Program Mode, MORN, DAY, EVE or NIGHT will appear. • In Commercial Program Mode, OCCUPIED or UNOCCUPIED will appear. -
Page 26: Additional Operation Features
5 Additional Operation Features Auto Changeover Mode Auto Changeover mode is a feature enabled/ disabled in the Installer Settings (see Installer Manual). If enabled, it is selected by pressing the SYSTEM button until AUTO HEAT or AUTO COOL appears in the display. When Auto Changeover mode is enabled and selected, the system automatically switches between heating and cooling when the room... -
Page 27: Adaptive Recovery Mode
Adaptive Recovery Mode (ARM ™ Adaptive Recovery Mode is a feature enabled/disabled in the Installer Settings (See Installer Guide). If enabled, the feature is automatically present while in programmable mode. Adaptive Recovery Mode tries to reach your desired heating or cooling temperature at the time you have set in your current program schedule, after a setback period. -
Page 28: Compressor Protection
Compressor Protection Compressor protection is enabled/disabled in the Installer Settings (See Installer Guide). If enabled, this feature is automatically present in cooling and/or heating modes. This thermostat includes an automatic compressor protection delay to avoid potential damage to your system from short cycling. This feature activates a short delay after turning off the system compressor. -
Page 29: Ac Power Monitor
If you entered a valid code the thermostat will be locked or unlocked (depending on its previous state). When locked, the word LOCKED appears in the display (Figure 1). If an invalid code is entered the word NO will briefly appear, indicating that an incorrect code was entered (Figure 2). -
Page 30: Indoor Remote Sensing
Installer Settings (See Installer Guide). If a Braeburn indoor remote sensor was installed and properly configured in the Installer Settings, the thermostat will sense temperature at a remote location or a combination of a remote location and the thermostat location. -
Page 31: Thermostat Maintenance
6 Thermostat Maintenance Thermostat Cleaning Never spray any liquid directly on the thermostat. Using a soft damp cloth wipe the outer body of the thermostat. Never use any abrasive cleansers to clean your thermostat. Changing the Batteries This thermostat requires two (2) properly installed “AA” alkaline batteries to maintain the thermostat clock and to provide power for the thermostat if 24 volt AC power is not connected. -
Page 32: Limited Warranty
For online access visit: www.bluelinksmartconnect.com ® Braeburn Systems LLC 2215 Cornell Avenue • Montgomery, IL 60538 Technical Assistance: www.braeburnonline.com Call us toll-free: 866-268-5599 (U.S.) 630-844-1968 (Outside the U.S.) 7300-110-01 ©2016 Braeburn Systems LLC • All Rights Reserved • Made in China.
