Braeburn 7300 Installer's Manual

Braeburn 7300 Installer's Manual

Bluelink universal programmable smart wi-fi thermostats, up to 2/3 heat / 1/2 cool heat pump 1/2 heat / 1/2 cool conventional
Hide thumbs Also See for 7300:

Advertisement

Table of Contents

Installer Guide
Universal Programmable Smart Wi-Fi Thermostats
7300 Up to 2 Heat / 1 Cool Heat Pump
7305 Up to 3 Heat / 2 Cool Heat Pump
See Wi-Fi Setup Guide for Wi-Fi Setup Instructions
1 Specifications
Warning
For installation by experienced service technicians only.
Caution
• Possible electric shock or damage to equipment can occur.
• Disconnect power before beginning installation.
This thermostat requires 24 Volt AC Power or 2 properly installed "AA" Alkaline
batteries for proper operation. If connecting this thermostat to a Wi-Fi network,
a 24 VAC common (C wire) is required.
For use only as described in this manual. Any other use will void warranty.
1 Specifications
This thermostat is compatible with:
• Single stage heat / cool conventional and heat pump systems
• Single stage heat pumps with auxiliary heat
• Conventional systems up to 2 stages of heating and 2 stages of cooling (7305 only)
• Heat pump systems up to 3 stages of heating and 2 stages of cooling (7305 only)
• 2 or 3 wire hydronic zone systems
Electrical and control specifications:
• Electrical Rating: 24 Volt AC
• 1 amp maximum load per terminal
• AC Power: 18 – 30 Volts AC
• DC Power: 3.0 Volt DC (2 "AA" Alkaline Batteries Included)
• Control Range: 45° – 90° F (7° – 32° C)
• Temperature Accuracy: +/- 1° F (+/- .5° C)
• Outdoor Temperature Display Range: -40° - 120° F (-40° - 49° C)
Terminations
• 7300: Rc, Rh, W1/E, C, Y1, K, O/B/V3, G, S2, S1
• 7305: Rc, Rh, W2, W1/E/W3, A, C, L, Y2, Y1, K, O/B/V3, G, S2, S1
1 Heat / 1 Cool Conventional
Up to 2 Heat / 2 Cool Conventional
Model number is located on back of thermostat.
2 Installation and Wiring
4 Installer Settings
®
3 Quick Reference
5 System Testing
®
"C" Common
Wire Required
for Wi-Fi
7300-100-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7300 and is the answer not in the manual?

Questions and answers

Related Manuals for Braeburn 7300

Summary of Contents for Braeburn 7300

  • Page 1 • Outdoor Temperature Display Range: -40° - 120° F (-40° - 49° C) Terminations • 7300: Rc, Rh, W1/E, C, Y1, K, O/B/V3, G, S2, S1 7300-100-04 • 7305: Rc, Rh, W2, W1/E/W3, A, C, L, Y2, Y1, K, O/B/V3, G, S2, S1...

  • Page 2: Installation And Wiring

    Avoid installation in locations where the thermostat can be affected by drafts, dead air spots, hot or cold air ducts, sunlight, appliances, concealed pipes, chimneys and outside walls. Install your new Braeburn thermostat in 4 basic steps: 1 Install the Sub-Base...
  • Page 3 Make sure to position the Positive (+) and Negative (-) sides of the batteries correctly with the +/- symbols in the battery compartment. • If connecting this thermostat to a Wi-Fi network, a 24 VAC common (C wire) is required. Connect Your Wires Wiring Terminations for model 7300 Terminal Function Description...
  • Page 4 Connecting Your Wires (continued) Wiring Terminations for model 7305 Terminal Function Description Input 24 Volt AC Cooling Transformer (Dual Transformer Systems Only) Input Power Connection (24 Volt AC Heating Transformer) Output Fan Control W1 / E / W3 Output (W1) 1st Stage Conventional Heat, (E) Emergency Heat, (W3) 3rd Stage Auxiliary Heat Output...
  • Page 5 Conventional Systems Typical Wiring Configurations NOTE: The “System Type” option will be configured in the Installer Settings section. Shaded areas do not apply to the 7300. 1 HEAT / 1 COOL Single or Dual Transformer Heat Only Set System Type to 11CONV...
  • Page 6 Typical Wiring Configurations NOTE: The “System Type” option will be configured in the Installer Settings section. Shaded areas do not apply to the 7300. 1 HEAT / 1 COOL - No Auxiliary Heat 2 HEAT / 1 COOL - Including Auxiliary Heat...
  • Page 7 NOTE: Additional options are configured in the NOTES - Additional Wiring Options Installer Settings section. [1] These terminals can be used to connect a Braeburn indoor or outdoor remote sensor. ® [2] Can be used to share a wire on existing installations Indoor or Outdoor Remote Sensor [note 1] where a common connection (C wire) is required.

  • Page 8: Quick Reference

    3 Quick Reference BACK NEXT Thermostat Display Room Temperature ...... Displays the current room temperature Set Temperature ......Displays the current set point temperature Outdoor Temperature Indicator ... Displays along with the outdoor temperature reading** BACK Indicator* ......BACK button is active NEXT Indicator*......
  • Page 9 Quick Reference Instructions ..Stored in slot located at top of thermostat SpeedBar ........Increases or decreases settings (time, temperature, etc.) ® Outdoor Temperature ....If a Braeburn outdoor sensor was connected you can view the outdoor ® temperature by pressing the PROG and HOLD buttons at the same time.

  • Page 10: Installer Settings

    4. Press NEXT (HOLD) or BACK (PROG) to move to the next or previous setting, press RETURN to exit. BACK NEXT DAY/TIME DAY/TIME NOTE: Shaded areas below do not apply to the 7300. No. Installer Setting Factory Setting Comments Default Options...
  • Page 11 28 Installer Clear Clear Off - No changes made to settings CLR2 Clears all thermostat settings (factory defaults) *When a Braeburn outdoor sensor is connected, the thermostat automatically recognizes it. Press PROG and HOLD at the same ® time to display outdoor temperature.
  • Page 12 ® 10 Only available if auto changeover was enabled in option 5. 11 Only available if a Braeburn outdoor sensor was connected. 12 Only available if a Commercial profile was selected in option 1. Detailed Explanation of Installer Settings (also see NOTES above): Profile –...
  • Page 13 (I SENS), remote sensor only (E SENS) or combining the thermostat and the remote sensor (A SENS). NOTE: This option does not apply to a Braeburn outdoor sensor. When an outdoor sensor is connected the thermostat automatically recognizes it and no further configuration is necessary.
  • Page 14 25 Economizer, Fresh Air or Output Control [note 12] – Selects control options. Select between disabled (NONE), economizer mode (ECON) and time of day (TOD) mode. Time Step / Override Cooling Call External Air or Output Control (A) Economizer Time of Disabled Mode Day Mode...

  • Page 15: System Testing

    5 System Testing Warning Read Before Testing • Do not short (or jumper) across terminals on the gas valve or at the heating or cooling system control board to test the thermostat installation. This could damage the thermostat and void the warranty. •...

  • Page 16: Limited Warranty

    For online access visit: www.bluelinksmartconnect.com ® Braeburn Systems LLC 2215 Cornell Avenue • Montgomery, IL 60538 Technical Assistance: www.braeburnonline.com Call us toll-free: 866-268-5599 (U.S.) 630-844-1968 (Outside the U.S.) 7300-100-04 ©2019 Braeburn Systems LLC • All Rights Reserved • Made in China.
