Plug In And Turn On - gCreate gMax 2 Getting Started

Insert Filament In Extruder
3. Pinch the extruder arm above the spring and insert
filament in the white PTFE tube.
4. Slide filament in un l you see it enter the top of the
tube just under the metal drive gear. The filament
should slide in about 4 inches more.

Plug In and Turn On

1. We recommend cu ng off the first 12" of a new spool of filament.
2. Every me you insert filament, cut end of filament at a 45 degree
angle and straighten 4" of the end of the filament by bending it.
1. Plug in the printer to a surge
protected power strip.
2. Make sure power switch is
on.
Pg 4
