Preset Programs; Problem Solving - Concept2 FR8000 Manual

EN
• Note: If you press the start/pause button while cooking and no action is taken within 5 minutes, the appliance
switches to standby mode (only the off/on button is lit).
Button for synchronous preparation of both vessels
This function is used to cook larger quantities of the same food or to cook different types of food using the same
program, temperature and time.
1. Press the button (3) to select zone L, which will flash.
2. Select the desired cooking programme.
3. Use the button (1) to set the desired temperature.
4. Use the button (11) to set the desired time.
5. Press the synchronous cooking button (7) to copy the setting of the left zone (L) to the right zone (R).
6. Press the start/pause button (2) to start cooking in both zones.
Note: If you first press the L=R button (7) and then the program selection button, both containers will be in the same
setting.
Left and right cooking settings
• The two zones start cooking at the same time but end at different times.
• Repeat steps 1-4 to set the left pot (L) and then repeat steps 1-4 to set the right pot (R).
• Press the start/pause button to start cooking in both pots.
Synchronous completion button
This function is used to finish cooking in both zones at the same time. Independent of temperature, cooking time or
program.
1. Press the button (3) to select zone L, which will flash.
2. Select the desired cooking programme.
3. Use the button (1) to set the desired temperature.
4. Use the button (11) to set the desired time.
5. Press button (9) to select zone R, which will flash.
6. Select the desired cooking programme.
7. Use the button (1) to set the desired temperature.
8. Use the button (11) to set the desired time.
9. Press the synchronous completion button (5), the button will light up when the program starts.
10. Press the start/pause button (2) to start cooking in the zone with the longer cooking time.
11. The second zone display will show "Hold". The second zone is activated when the same time remains in both zones.
Note: This function is not suitable for the drying programme.
Off and on button
• If you press the off/on button during operation, an audible signal sounds and the fryer switches off.
AUTOMATIC SHUTDOWN - PAUSE FUNCTION AFTER REMOVING THE CONTAINER
• It is recommended to stir/turn the food halfway through cooking for some dishes. At any time during operation,
the frying container(s) can be removed.
• When the fryer is removed, the power to the fryer is automatically switched off and "Out" is displayed on the display
of the removed fryer.
• After inserting the frying container back into the body of the appliance within 90 seconds, the fryer resumes its
original settings.
• In Synchronous Prep or Synchronous Finish mode, both zones pause when one container is removed and the display
of the removed container will show "Out". If the container is not reinserted within 90 seconds, the unremoved
container will automatically resume operation after 90 seconds. The side of the removed container will not heat up
and the synchronous functions will be inactive (the 5 or 7 icon will not light).
• If one or both containers are not reinserted within 5 minutes, the side without the container switches to standby
mode (the display stops flashing and goes off after 5 minutes) and the side where the container has not been
removed automatically resumes operation after 90 seconds.
48
Interior light on/off button
Pressing the on/off button for the internal lighting (6) illuminates the interior of the container, so that it is not necessary
to remove the container to check the cooking process. Press the button (6) repeatedly to switch off the lighting.
Note: The fan icon lights up while the program is running. After the fan stops running, the fan icon will turn off.
Note: OFF
• You will be alerted 5 times with an audible signal when the set preparation time has elapsed. The fan continues to
run for approximately 20 seconds after switching off and the display shows "Cool". After the fan stops running, the
display shows "End" and after 5 minutes the appliance goes into standby mode (only the off/on icon is lit). Check
that the food is ready. Remove the frying pan from the appliance and place it on a heat-resistant mat. Remove the
food.
• Do not use sharp kitchen tools to avoid damaging the non-stick surface! If the food is not yet ready, simply slide
the container back into the appliance and adjust the cooking time by a few extra minutes. The fryer can be used to
prepare the next batch immediately. After switching off the appliance, disconnect it from the mains.
WARNING: Do not turn the frying pan upside down while the frying plate is still inside, as any excess oil that may have
accumulated at the bottom of the pan will spill out onto the food and the hot frying plate may fall down!

PRESET PROGRAMS

Program Time (min)
Potatoes and Fries 20
Chicken 25
Fish 16
Desert 15
Vegetables 16
Fruit drying 8h
Note: These settings are approximate. If you start cooking when the fryer is still cold, extend the cooking time by
approx. 3 minutes.
All of these programmes except the fruit drying programme can be set between 1-60 minutes and a temperature
range of 80-200°C. The fruit drying programme can be set between 1-24 hours and a temperature range of 40-80°C.

PROBLEM SOLVING

FAILURE POSSIBLE CAUSE
The fryer not connected to
power mains.
The appliance does not work.
The program was not started
using the start/pause button.
The fryer container is too full.
The food has not been fully fried.
The set preparation time is too
short.
Temperature set too low.
Temperature (°C)
200
200
180
160
160
60
REMEDY
Connect the fryer to power mains.
Make sure you have pressed the
start/pause button, see the Owner's
Manual.
Reduce the quantity of ingredients
in the glass container, thus making
the frying equal.
Extend the preparation time.
Increase the temperature.
EN
49
