MICRO COMPONENT MD SYSTEM
MD 微型组合音响
UX-QD70S
Consists of CA-UXQD70S and SP-UXK30S
由 CA-UXQD70S 和 SP-UXK30S 组成
UX-QD70W
Consists of CA-UXQD70W and SP-UXK30W
由 CA-UXQD70W 和 SP-UXK30W 组成
For turning off the demonstration
display, refer to page 15.
关闭演示显示的有关详情，请参阅
15
第
页。
INSTRUCTIONS
使用说明书
中
文
LVT1367-002A
[UB]
Advertisement
Table of Contents
Related Manuals for JVC UX-QD70SUB
Summary of Contents for JVC UX-QD70SUB
- Page 1 MICRO COMPONENT MD SYSTEM MD 微型组合音响 中 UX-QD70S 文 Consists of CA-UXQD70S and SP-UXK30S 由 CA-UXQD70S 和 SP-UXK30S 组成 UX-QD70W Consists of CA-UXQD70W and SP-UXK30W 由 CA-UXQD70W 和 SP-UXK30W 组成 For turning off the demonstration display, refer to page 15. 关闭演示显示的有关详情，请参阅...
- Page 2 Warnings, Cautions and Others / 警告，注意及其他须知事项 Introduction CAUTION 注意 To reduce the risk of electrical shocks, fire, etc.: 为了减少触电、火灾等危险： 1. Do not remove screws, covers or cabinet. 1. 请勿擅自卸下螺丝钉、盖子或机壳。 2. Do not expose this appliance to rain or moisture. 2. 请勿让本机受雨淋或置于潮湿环境中。 CAUTION —...
- Page 3 CAUTION — Proper Ventilation 注意 — 正确的通风方法 To avoid risk of electric shock and fire and to protect from 为了防止触电，火灾及避免损坏， damage, locate the apparatus as follows: 按如下要求放置机器： Top/Front/Back/Sides: No obstructions should be placed in 上面 / 前面 / 后面 / 侧面： 在图中所示范围中，不应放置任何障 the areas shown by the dimensions 碍物。...
-
