Page 1: Micro Component System
MICRO COMPONENT SYSTEM UX-QX3W Consists of CA-UXQX3W and SP-UXQX1W UX-QX3A Consists of CA-UXQX3A and SP-UXQX1A To disable the demonstration display, refer to page 7. INSTRUCTIONS GVT0182-005A... - Page 2 CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. CAUTION — F (STANDBY/ON) button! Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off). When installing the apparatus, ensure that the plug is easily accessible.
-
Page 3: Table Of Contents
Table of Contents Introduction Notes on Operations... 2 Installation ... 2 Notes on Handling... 2 Moisture Condensation ... 2 Listener's Etiquette... 2 About CDs/CD-Rs/CD-RWs... 2 Supplied Accessories... 2 Preparation Part Identification... 3 Remote Control ... 4 Inserting Batteries into the Remote Control... 4 Connections... -
Page 4: Notes On Operations
Installation • Install the System in a location with adequate ventilation to prevent internal heat buildup in the System. • DO NOT install the System in a location near heat sources, or in a place subjected to direct sunlight, excessive dust or vibration. •... -
Page 5: Part Identification
Part Identification 11, 22 9, 13 9,14 9, 15 - 17 Remote control sensor: 4 13 - 15, 17 When the power is turned off, the STANDBY lamp lights red. When the power is turned on, the STANDBY lamp goes off. ** This terminal is for connecting a pair of headphones equipped with a stereo mini plug (not supplied). -
Page 6: Remote Control
8, 14, 16, 17, 20 9, 14 9, 15, 16, 17 16, 17 The numbers in the figure indicate the pages where the details of the parts are. Inserting Batteries into the Remote Control 9, 18, 17, 21 8, 14, 18, 20, 21 8, 14, 15, 17,... -
Page 7: Connections
Connections Connecting the Antennas Connecting the AM antenna Set up the AM loop antenna (supplied). Connect the antenna cord. Main unit (side view) Main unit (rear view) When insulation covers the tips of the antenna cord, twist and pull off the insulation. -
Page 8: Connecting The Speakers
Connections Connecting the Speakers There is no difference between the left and right speakers. After connecting the speakers, gently pull the speaker cords to make sure that they are firmly connected. Speaker cord White Black Right speaker (rear view) CAUTION •... -
Page 9: Connecting A Digital Audio Player
Do not connect the AC power cord until all other connections have been made. Connecting a Digital Audio Player ■ To listen to a Digital Audio Player Main unit (front view) To the audio output Stereo mini plug audio cord (not supplied) NOTE •... -
Page 10: Basic Operations And Settings
About this manual In this manual, operations mainly using the remote control are explained; however, some buttons on the main unit work the same way as those on the remote control. You can use either button in this case. Number buttons Setting the Clock You can set the clock when the System is turned... -
Page 11: Turning On/Off The System
"AHB PRO ON" (initial setting) and "AHB PRO OFF." • When the AHB PRO function is activated, Sound Mode Sound mode A combination of JVC sound technologies enables you to select the desired sound pattern. Press • Each time you press follows: again. -
Page 12: Adjusting The Tone
Sound α (alpha) waves are regarded as one type of brain wave that is emitted when a person is relaxed. JVC's , "NO OPERATE" to produce natural and comfortable sound that makes you feel relaxed. The natural effect is completed by 1) modulation which adds fluctuation with the α... -
Page 13: Changing The Illumination Color
Changing the Illumination Color Press repeatedly. • Each time you press , the illumination color for the front panel changes as follows: UX-QX3W RAINBOW SPACE SEASONS CANARY ECOLOGY MARSHMALLOW COSMIC SHERBET POP CANDY POLAR STAR KIWI ROSE QUARTZ AMETHYST EMERALD TOPAZ AQUAMARINE SOFT LIGHT1... -
Page 14: Changing The Display Brightness (Dimmer)
Basic Operations and Settings Changing the Display Brightness (DIMMER) Press repeatedly. • Each time you press , the brightness of the front panel changes as follows: : Dims the display. : Dims the display more than DIMMER 1 and the front panel lights blue. -
Page 15: Listening To The Radio
Listening to the Radio The System can receive FM and AM radio broadcasts. Number buttons Setting the AM Tuner Spacing Before operating the tuner, it is required to select the appropriate AM space interval used for your area. On the main unit: While the System is turned off... -
Page 16: Tuning In To A Radio Station
Listening to the Radio Tuning in to a Radio Station Press Example: When FM is selected as the source Preset number ( STEREO indicator Frequency Press repeatedly to select a radio station (frequency). • You can also select a radio station using the automatic tuning. -
Page 17: Listening To Discs
Listening to Discs The System can play back regular CDs and finalized CD-Rs/CD-RWs (recorded in audio CD or MP3 format). Number buttons Operation Play Press Stop Press Press during playback. Pause Pressing again resumes playback. : Press the button repeatedly. Skip : Press the button to skip groups (only for MP3... -
Page 18: Specifying The Track (Direct Track Selection)
Listening to Discs Specifying the Track (Direct Track Selection) Press the number buttons to select the track you want to listen to. • Refer to "Using the number buttons" ( Repeat Playback This function allows you to listen repeatedly to the same track (or group: only for MP3 disc). -
Page 19: Random Playback
■ To confirm the programmed track order While playback is stopped... Press repeatedly. ■ To add tracks You can add a track as the last track in the program. While playback is stopped... Press the number buttons to select the track number you want to add. -
Page 20: Listening To A Digital Audio Player Readily (Qp Link)
Connect a Digital Audio Player to the LINE IN jack in advance ( page 7). Press Start playing the Digital Audio Player. • For details, refer to the instruction manual for the Digital Audio Player. Adjust the volume of the System and the Digital Audio Player. -
Page 21: Using The Timer
Using the Timer The System is equipped with the two timers: the sleep timer and the playback timer. You can enter up to three timer settings in total for the playback timer ( page 20). • The playback timer settings remain in memory until you change it. -
Page 22: Playback Timer
Using the Timer Playback Timer With the playback timer, you can wake up with your favorite music. Prepare the source you want to play back Source Operation Insert a disc ( page 15). FM/AM Preset the radio station you want to listen to page 14). - Page 23 Press repeatedly to select the following, then press When "FM" or "AM" is selected as the source in step 6: Select the preset number of the radio station you want ( When "CD/MP3" is selected as the source in step 6: Select the group (for only MP3 disc) and track number you want to play back first.
-
Page 24: Using The Snooze Function
While the playback timer ( page 20) is working to play the selected source, you can turn off the sound temporarily by touching main unit. ■ Setting the snooze function Press • Each time you press , the snooze function changes between "SNOOZE ON"... -
Page 25: Disc Lock
Disc Lock You can prohibit disc ejection. On the main unit ONLY: When the System is turned off... While holding down , press on the main unit. The disc tray is locked. Even if you press , "LOCKED" appears on the display window and the disc does not come out. -
Page 26: Warning Message
CD NO DISC Disc is not loaded. Disc is placed upside down. Unplayable disc is loaded. Troubleshooting Check the following points before contacting the JVC service center. Problem No sound is produced from the Improper connection. speakers. Headphones are connected. -
Page 27: Specifications
Specifications ■ CD receiver section (CA-UXQX3W/CA-UXQX3A) Amplifier 20 W × 2ch (THD 10%/4 ⇐) Output power Input terminal LINE IN × 1: 500 mV/47 k⇐: LEVEL1 250 mV/47 k⇐: LEVEL2 125 mV/47 k⇐: LEVEL3 Speaker × 2: 20 W/4 ⇐ Output terminals Impedance: 4 ⇐... - Page 28 2006 Victor Company of Japan, Limited 0706YAMMDWJEM...
