CPLPCONV013C00: Installation Instructions
CPLPCONV013C00
Small Packaged Products Accessory Propane Gas Conversion Kit
Standard Altitude Only 0-2000 FT (0-610 m)
40,000-130,000 Btu/hr
NOTE: Read the entire instruction manual before starting the
installation.
This kit is used on:
Two-Stage (2 - 5 Tons) Models: 48DU, 48DT, 48VG (208/230 VAC
models), 48VR, 48XL, 48XT, 577B, 577D, 577E (208/230 VAC
models), 677B, 677D and 677E. (Two-Stage conversion starts on
page 7.)
Single-Stage (1-1/2 - 5 Tons) Models: 48ES, ("1") series or later
(Examples: 48ES-060130311, 48ES-060130511, 48ES-060130611),
48ES-A,
48ESNA,
48EZ
48EZ-060130311,
48EZ-060130511,
48EZNA, 48VG (460 VAC models), 48VL, 48VT, 574D "B" series or
later
(Examples:
574DNW060130NB,
574DEW060130NB), 574D*WA, 577C, 577E (460 VAC models), 674D
"B"
series
or
later
674DPW060130NB, 674DEW060130NB), 674D*WA, 677C, all PY3G
except "B" series (Example: PY3GNA060115AB) and PY4G.
(Single-Stage conversion starts on page 2.)
This kit must not be used on 48VGU, 48VLU, 577*********U,
PY4G*******U models. These models are for Natural Gas Only.
Safety Considerations
Installation and servicing of this equipment can be hazardous due to
mechanical and electrical components. Only trained and qualified
personnel should install, repair, or service this equipment.
Untrained personnel can perform basic maintenance functions such as
cleaning and replacing air filters. All other operations must be performed
by trained service personnel. When working on this equipment, observe
precautions in the literature, on tags, and on labels attached to or shipped
with the unit and other safety precautions that may apply.
Follow all safety codes. Wear safety glasses, protective clothing, and
work gloves. Use quenching cloth for brazing operations. Have fire
extinguisher available. Read these instructions thoroughly and follow all
warnings or cautions included in literature and attached to the unit.
Consult local building codes, the current editions of the National
Electrical Code (NEC) NFPA 70 and NFPA 90B-Installation Warm Air
Heating and A/C Systems (Residential). In Canada refer to the current
editions of the Canadian Electrical Code CSA C22.1.
Recognize safety information. This is the safety-alert symbol
you see this symbol on the unit and in instructions or manuals, be alert to
the potential for personal injury. Understand these signal words:
DANGER, WARNING, and CAUTION. These words are used with the
safety-alert symbol. DANGER identifies the most serious hazards which
will result in severe personal injury or death. WARNING signifies
hazards which could result in personal injury or death. CAUTION is
used to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Installation Instructions
"1"
series
or
later
(Examples:
48EZ-060130611),
48EZ-A,
574DPW060130NB,
(Examples:
674DNW060130NB,
FIRE, EXPLOSION, CARBON MONOXIDE POISONING,
PROPERTY DAMAGE HAZARD
Failure to follow this warning could result in personal injury, death or
property damage.
This conversion kit shall be installed by a qualified service agency in
accordance with the manufacturer's instructions and all applicable
codes and requirements of the authority having jurisdiction. The
qualified service agency is responsible for the proper installation of this
kit. The installation is not proper and complete until the operation of the
converted furnace is checked as specified in the manufacturer's
instructions supplied in the kit.
FFEU, EXPLOSION, EMPOISONNEMENT PAR
CARBON DE MONOXYDE, RISQUE DE DOMMAGE À
LA PROPRIÉTÉ
La négligeance de suivre l'avis suivant, peut causer des blessures
personnelles, la mort ou du dommage à la propriété.
Cette trousse de conversion doit être installée par un Entrepreneur
qualifié, selon les instructions du fabricant et doit se conformer à toutes
les exigences et tout les codes pertinents de l'autorité compétente.
L'Entrepreneur qualifié
est responsable, et doit s'assurer de bien suivre les instructions dans cet
avis. L'installation sera considèrèè conforme et rencontrant les
spécifications et instructions du fabriquant qui sont inclus dans la
trousse, seulement aprés vérification de l'opération de la fournaise
convertie.
UNIT OPERATION HAZARD
Failure to follow this caution may result in damage to unit components.
Before converting a unit to propane gas, remove the burner assembly
and inspect the heat exchanger tubes. If there are V-shaped NOx baffles
installed in the firing tubes, (see
. When
PRIOR TO CONVERTING THIS UNIT TO PROPANE GAS.
1
WARNING
!
WARNING
!
WARNING
!
Fig.
1). THEY MUST BE REMOVED
