- Page 1 ENGLISH ENGLISH Resolute™ Strength Selectorized Line Glute Extension RSL 618 Assembly Guide...
-
Page 2: Assembly Requirements
Assembly Requirements CAUTION Installation Requirements Required Tools Box cutter Rubber mallet Trademarks ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide... -
Page 3: Parts List
Parts List Part # Name Quantity Part # Name Quantity Handle assembly Kick plate Front frame Weight labels Foot plate frame End cap Foot plate Bumpers Guide rods ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide... -
Page 4: Frame Assembly
DO NOT tighten fasteners until instructed to do so. Image Hardware Instructions plate Align to far left hole. Insert both guide rod fasteners from user side to align kick plate. Hand tighten only. step. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide... - Page 5 ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide...
-
Page 6: Moving Parts
Gently rock the frame to align. Tighten all M12 fasteners to a torque of 55 ft-lb (75 N-m). Do not tighten the M10 screws installed in step 1 at this time. Moving Parts Image Hardware Instructions end cap ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide... -
Page 7: Route The Cable
Route the Cable Image Hardware Instructions 19 mm 25 mm. pulley and then replace the cable retainer. retainers. Tighten to 50 ft-lb (67 N-m) of torque. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide... - Page 8 Finish the Weight Stack Tower Image Hardware Instructions step 1 of the Frame Assembly. guide rods bumpers top plate assembly user side. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide...
- Page 9 Secure them to the kick plate. Let the guide rods drop onto the bolts and fully tighten the bolts. Tighten M10 screws to 32 ft-lb (43 N-m) of torque. bumpers frame. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide...
- Page 10 ALL 41 mm 1.61 inch (41mm). be no more than Tighten the locking bolt against the select stem to 50 ft-lb (81 N-m) of torque. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide...
- Page 11 Repeat for the front middle shrouds Install the upper rear and front shrouds . Ensure to hook them Recommended bolt torque is 25 ft-lb (34 N-m). Securely snap top tray into place. ©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide...
