- Page 1 Operating Instructions Air Top Evo 40 | 55 English www.butlertechnik.com...
-
Page 2: Table Of Contents
Malfunctions ........ 6 Service signal ........ 7 10 Maintenance........ 7 11 Disposal .......... 7 12 Service and customer services .... 7 13 Declaration of Conformity .... 7 14 Type approval AT40|55....... 8 9030680C OI Air Top Evo 40 _ 55 EN www.butlertechnik.com... -
Page 3: General Information
This liability exclusion particularly applies to: Risk of injury from the defective unit l Installation or maintenance by untrained personnel. Do not operate a defective Air Top Evo 40 | 55 and put l Improper use. it out of service by removing the fuse: l Repairs not carried out by a Webasto service workshop. -
Page 4: Regulations And Legal Requirements
Danger of poisoning and suffocation due to ex- The type approvals in accordance with the regulations ECE-R haust fumes 122 (heating) and ECE-R 10 (EMC) for the Air Top Evo 40 | 55 Make sure that: heater apply in the area where the European regulation 2018/858 is valid. -
Page 5: Switch The Heater On And Off
Fuel | 4 – Air Top Evo 40 | 55 D: Diesel DIN EN 590, biodiesel DIN Switch the heater on and off EN 14214, HVO DIN EN 15940 The heater is switched on and off by different switch signals. -
Page 6: Malfunctions
The number of long pulses corresponds to the number of the fault code. F00 is just rapid flashing. l In event of an error occurring, check the fuse and plug connectors. l If the fault cannot be rectified by the measure described, contact your Webasto service workshop. NOTE Independent maintenance work, particularly using flammable gases or liquids such as accelerators, is forbidden. -
Page 7: Service Signal | 9
At the beginning of the heating period, have the heater checked by a professional. Disposal The Air Top Evo 40 | 55 must not be disposed of in household waste. Observe the regional regulations for disposal of electronic products. -
Page 8: Type Approval At40|55
14 | Type approval AT40|55 Type approval AT40|55 122R - 00 0385 Fig. 2 Type approval Air Top 40 (page 1) 8 / 11 9030680C OI Air Top Evo 40 _ 55 EN www.butlertechnik.com... - Page 9 Fig. 5 Type approval Air Top 55 (page 1) 122R - 00 0386 122R - 00 0385 Fig. 4 Type approval Air Top 40 (page 3) Fig. 6 Type approval Air Top 55 (page 2) 9030680C OI Air Top Evo 40 _ 55 EN 9 / 11 www.butlertechnik.com...
- Page 10 14 | Type approval AT40|55 122R - 00 0386 Fig. 7 Type approval Air Top 55 (page 3) 10 / 11 9030680C OI Air Top Evo 40 _ 55 EN www.butlertechnik.com...
- Page 11 To request this documentation in another language, please locate and contact your local Webasto dealer. You can find your nearest dealer at: https://dealerlocator.webasto.com/en-int. To provide feedback (in English or German), please email: feedback2tdt@webasto.com Europe, Asia Pacific: UK only: Webasto Webasto Thermo &...
