- Page 1 User manual Indoor module NIBE VVM S330 UHB EN 2314-1 631492...
- Page 2 When there is new software to download, you can do it here (provided that VVM S330 is connected to myUplink). IN THE EVENT OF DISTURBANCES IN COMFORT If you experience a disturbance in comfort of any kind, there are various measures you can take yourself before contacting...
-
Page 3: Table Of Contents
3 Control - Introduction Display unit Navigation Menu types Menu system 4 myUplink Specification Connection Range of services 5 Maintenance of VVM S330 Regular checks Saving tips 6 Disturbances in comfort Info-menu Manage alarm Troubleshooting Add. heat only Contact information... -
Page 4: Important Information
Lowest supply heating Accessories Serial number must always be given. Certification that the installation is carried out according to instructions in the accompanying installer manual and applicable regulations. Date ______________________________ Signed __________________________________________ Chapter 1 | Important information NIBE VVM S330... -
Page 5: Symbols
Serial number The serial number can be found at the bottom right on VVM S330, in the display on the home screen "Product overview" and on the type plate. Caution You need the product's (14 digit) serial number for servicing and support. -
Page 6: Installation Function
(3) . 5 ºC 80 ºC 6 ºC 55 ºC 1 ºC 45 ºC 0 ºC The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | Installation function NIBE VVM S330... - Page 7 The indoor module produces hot water using a hot water heat exchanger. The heating medium flows through the hot water heat exchanger and heats up the domestic hot water as it is consumed. NIBE VVM S330 Chapter 2 | Installation function...
-
Page 8: Control - Introduction
For hard switch off: press and hold the on/off button for 5 seconds. To activate emergency mode when VVM S330 is switched off: press and hold the on/off button for 5 seconds. (Deac- THE STATUS LAMP tivate the emergency mode by pressing once.) -
Page 9: Navigation
Navigation FACTORY SETTING Factory set values are marked with *. VVM S330 has a touchscreen where you simply navigate by Your installer may have chosen other values that suit your pressing and dragging with your finger. system better. SELECT Most options and functions are activated by lightly pressing on the display with your finger. - Page 10 Current temperature The drop-down menu shows the current status for Set temperature VVM S330, what is in operation and what VVM S330 is doing Works to set temperature at the moment. The functions that are in operation are highlighted with a frame.
-
Page 11: Menu System
Info Menu 8 - USB This menu lights up when a USB memory is connected. You My system can update the software here, for example. Connection NIBE VVM S330 Chapter 3 | Control - Introduction... -
Page 12: Myuplink
Installer Manual. Specification You need the following in order for myUplink to be able to communicate with your VVM S330: • wireless network or network cable •... -
Page 13: Maintenance Of Vvm S330
CHECK PRESSURE VVM S330 has a pressure gauge, which shows the heating system pressure. The pressure should be between 0.5 and 1.5 bar, but varies during temperature changes. If the pres- sure drops to 0 or rises to 2.5 bar frequently, contact your... -
Page 14: Saving Tips
This is important, as fully or partially closed thermostat valves slow the flow in the climate system, which results in VVM S330 working at a higher temperature. This in turn can lead to increased energy consumption. -
Page 15: Disturbances In Comfort
Disturbances in comfort Troubleshooting In most cases, VVM S330 notes a malfunction (a malfunction can lead to disruption in comfort) and indicates this with If the operational interference is not shown in the display alarms, and instructions for action, in the display. -
Page 16: Add. Heat Only
There is no heating or hot water demand, nor cooling de- mand. • VVM S330 in incorrect operating mode. – VVM S330 does not call on heating, hot water or cooling. – Contact your installer! • Compressor blocked due to the temperature conditions. -
Page 19: Contact Information
Tel: +48 (0)85 66 28 490 Hannabadsvägen 5, 285 21 Markaryd Tel. +41 (0)58 252 21 00 biawar.com.pl Tel: +46 (0)433-27 30 00 info@nibe.ch info@nibe.se nibe.ch nibe.se For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information. - Page 20 WS release date: 2023-04-03 13:12 Publish date: 2023-05-12 07:43 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
