  • Page 1 Installer manual Indoor module NIBE VVM 310 IHB EN 2235-1 731202...
  • Page 2 Quick guide Navigation Ok button (confirm/select) Back button (back/undo/exit) Control knob (move/increase/reduce) A detailed explanation of the button functions can be found on page 35. How to scroll through menus and make different settings is described on page 37. Set the indoor climate INDOOR CLIMATE HOT WATER MY INSTALLATION...

  • Page 3: Table Of Contents

    Transport 9 Service Assembly Service actions Supplied components Removing panels 10 Disturbances in comfort Info-menu 3 Design VVM 310 Manage alarm List of components Troubleshooting 4 Pipe connections Electrical addition only General pipe connections 11 Accessories Dimensions and pipe connections...

  • Page 4: Important Information

    VVM 310 must be installed via an isolator switch. The cable area has to be dimen- sioned based on the fuse rating used.

  • Page 5: Inspection Of The Installation

    Safety valve Electricity, see section "Electrical connections" Connected communication Fuses, indoor module Fuses property Outside sensor Room sensor Current sensor Safety breaker Earth circuit-breaker Setting of emergency mode thermostat Miscellaneous Docked to NIBE VVM 310 Chapter 1 | Important information...

  • Page 6: Outdoor Modules

    Part no. 064 235 Part no. 067 668 AMS 20-10 HBS 20-10 Part no. 064 319 Part no. 067 819 Check the software version of compatible older NIBE air/water heat pumps, see page 16. Chapter 1 | Important information NIBE VVM 310...

  • Page 7: Delivery And Handling

    VVM 310 should be transported and stored vertically in a dry service on VVM 310 can be carried out from the front. place. However, the VVM 310 can be carefully laid on its back when 10-25 being moved into a building.

  • Page 8: Removing Panels

    Twist the panel slightly outwards. 3. Move the panel backwards and slightly to the side. 4. Pull the panel to one side. 5. Pull the panel forwards. 6. Assembly takes place in the reverse order. Chapter 2 | Delivery and handling NIBE VVM 310...

  • Page 9: Design Vvm

    VVM 310 AA4-XF4 AA3-X4 BF1* BT30 FQ10 FQ10-S2 AA1-X3 AA1-S2 BT54 AA1-X7 AA1-X1 QN35 GP12 XL30 XL18 XL19 *Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets. NIBE VVM 310 Chapter 3 | Design VVM 310...

  • Page 10: List Of Components

    Temperature limiter FQ10-S2 Resetting temperature limiter Auxiliary relay, emergency mode. Switch W130 Network cable for NIBE Uplink 1 Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets. Chapter 3 | Design VVM 310 NIBE VVM 310...

  • Page 11: Pipe Connections

    55 °C on the supply line (100% pump sion (DN) sion (mm) and 45 °C on the return line, but VVM 310 can handle up to speed (l/s) 70 °C on the supply line. AMS 20-6/ HBS 20-6 NIBE recommends installing VVM 310 as close to the heat 0.19...
  • Page 12 Switch (SF1) must not be moved to " " or " " until dimensioned according to the maximum height (H) between VVM 310 has been filled with water. Otherwise the the vessel and the highest positioned radiator, see figure. temperature limiter, thermostat and the immersion A pre-pressure of 0.5 bar (5 mvp) means a maximum permit-...
  • Page 13 SYMBOL KEY SYSTEM DIAGRAM VVM 310 consists of hot water coil for hot water heating, Symbol Meaning immersion heater, circulation pumps, buffer vessel and Shut-off valve control system. VVM 310 connects to the climate system. Non-return valve VVM 310 is directly adapted for connection and communic-...

  • Page 14: Dimensions And Pipe Connections

    Connection, solar heating system supply line Ø22 mm XL14 Connection, solar heating system return line Ø22 mm XL18 Connection, docking in high temp Ø22 mm XL19 Connection, docking out high temp Ø22 mm XL30 Connection, expansion tank G20 int. Chapter 4 | Pipe connections NIBE VVM 310...

  • Page 15: Connecting Air/Water Heat Pump

    You can find a list of compatible air/water heat pumps in A climate system is a system that regulates the indoor section "Compatible air/water heat pumps". temperature with the help of the control system in VVM 310 and, for example, radiators, underfloor heating, underfloor Caution cooling, fan coils, etc.
  • Page 16 F2020 F2025 F2026 CONNECTING HOT WATER CIRCULATION F2030 all versions A circulation pump can be controlled by VVM 310 to circulate F2040 all versions the hot water. The circulating water must have a temperat- F2120 all versions ure that prevents bacterial growth and scalding, and national...

  • Page 17: Electrical Connections

    For electrical wiring diagram for VVM 310, see section Caution "Electrical circuit diagram". When VVM 310 has to be run with an older outdoor • Communication and sensor cables to external connections section, the program version in the outdoor section must not be laid close to high current cables.
  • Page 18 Removing the cover, input circuit board Insert the screwdriver (A) and pry the catch carefully downwards (B). Angle out the cover and remove it. Push the catch down. Angle out the cover and remove it. Chapter 5 | Electrical connections NIBE VVM 310...
  • Page 19 CABLE LOCK Use a suitable tool to release/lock cables in the indoor module terminal blocks. NIBE VVM 310 Chapter 5 | Electrical connections...

  • Page 20: Connections

    Mark up any junction boxes with warnings for ex- ternal voltage. POWER CONNECTION VVM 310 must be installed with a disconnection option on the supply cable. Minimum cable area must be sized accord- NOTE ing to the fuse rating used. The enclosed cable (length ap- During service, all supply circuits must be discon- prox.
  • Page 21 Closed radiator thermostats can also cause problems. VVM 310 operates without the room sensor, but if you want to read the home’s indoor temperature from the display on AA3-X6 VVM 310, the sensor must be fitted.
  • Page 22 COMMUNICATION If VVM 310 is to be connected to the heat pump, it is connec- ted to terminal blocks X4:13, X4:14 and X4:15 on the input board (AA3). AA3-X4 VVM 310 and F2040, F2050 / NIBE SPLIT HBS 05, 20 VVM 310...

  • Page 23: Settings

    ) only the most necessary functions are activated. • No hot water is produced. • The load monitor is not connected. • Fixed temperature in the supply line, see section Emer- gency mode thermostat. NIBE VVM 310 Chapter 5 | Electrical connections...

  • Page 24: Optional Connections

    VVM 310 is equipped with a load monitor that, with the help of a current sensor, controls the power steps for the...
  • Page 25 AA3-X6 External activation of functions AA3-X6 An external switch function can be connected to VVM 310 to activate various functions. The function is activated The example above uses the inputs AUX1 (X6:9-10) and AUX2 (X6:11-12) on during the time the switch is closed.
  • Page 26 4-pipe system This accessory may require a software update • external heating medium pump in your VVM 310. The version can be checked in • additional heat in charge circuit the “Service info” menu 3.1. Visit nibeuplink.com...
  • Page 27 (BT64) for cooling out and the cooling set point value. If the “active cooling 4-pipes” accessory has been activated, the function is switched off. Cooling is then operated from the accessory instead. NIBE VVM 310 Chapter 5 | Electrical connections...

  • Page 28: Connecting Accessories

    See page 57 for the board AA3. Use cable type LiYY, EKKX or equivalent. list of the accessories that can be used with VVM 310. Refer to the accessory manual for further instructions. Connection for communication with the most common ac- cessories is shown here.

  • Page 29: Commissioning And Adjusting

    Turn off the power supply to VVM 310. Check that the switch (SF1) is in position " ". Vent VVM 310 through the vent valve (QM20) and other Check that the drain valve is fully closed and that the climate systems through their relevant vent valves.

  • Page 30: Start-Up And Inspection

    Set switch (SF1) on VVM 310 to position " ". Follow the instructions in the display’s start guide. If the start guide does not start when you start the VVM 310, you can start it manually in menu 5.7. If the start guide is left on this page it...
  • Page 31 Select operating mode "auto" if the indoor module is to be used as an electric boiler without a heat pump. PUMP SPEED Both the circulation pumps in VVM 310 are frequency con- trolled and set themselves using control and external heating requirement. Available pressure circulation pump, GP1 Available pressure Tillgängligt tryck...

  • Page 32: Setting The Heating Curve

    Based on this curve, ures. the VVM 310 determines the temperature of the water to Supply temperature the climate system (the supply temperature) and thus the Framledningstempereratur (°C)

  • Page 33: Cooling In 2-Pipe System

    Setting range: 5.0 – 80.0 °C Cooling in 2-pipe system Factory setting: 22.0 °C VVM 310 contains a built-in function for operating cooling stop temperature in a 2-pipe system down to 17 °C, factory setting 18 °C. This Setting range: 5.0 – 80.0 °C requires that the outdoor module can perform cooling.
  • Page 34 With overcapacity mode on "SG Ready", the desired pool temperature (start and stop temperature) is increased by 2 °C. NOTE The function must be connected to two AUX inputs and activated in menu 5.4. Chapter 6 | Commissioning and adjusting NIBE VVM 310...

  • Page 35: Control - Introduction

    The USB port is hidden beneath the plastic badge with the product name on it. The USB port is used to update the software. Visit nibeuplink.com and click the "Software" tab to download the latest software for your installation. NIBE VVM 310 Chapter 7 | Control - Introduction...
  • Page 36 This symbol indicates whether "holiday setting" is active in 4.7. This symbol indicates whether VVM 310 has con- tact with NIBE Uplink. This symbol indicates the actual speed of the fan if the speed has changed from the normal setting.
  • Page 37 Back button. Mark the applicable option. One of the options is pre-selected (white). Press the OK button to confirm the selected option. The selected option has a green tick. NIBE VVM 310 Chapter 7 | Control - Introduction...
  • Page 38 (at the page number) has been marked. Press the OK button to skip between the steps in the start guide. If the start guide is left on this page it closes automatically in 60 min Chapter 7 | Control - Introduction NIBE VVM 310...

  • Page 39: Control - Menus

    1.9.6 - fan return time * 1.9.7 - own curve 1.9.7.1 - heating 1.9.7.2 - cooling * 1.9.8 - point offset 1.9.9 - night cooling * 1.9.11 - +Adjust * Accessories are needed. NIBE VVM 310 Chapter 8 | Control – Menus...

  • Page 40: Menu 2 - Hot Water

    Menu 3 - INFO 3 - INFO 3.1 - service info 3.2 - compressor info 3.3 - add. heat info 3.4 - alarm log 3.5 - indoor temp. log * Accessories are needed. Chapter 8 | Control – Menus NIBE VVM 310...

  • Page 41: Menu 4 - My System

    Menu 4 - MY SYSTEM 4 - MY SYSTEM 4.1 - plus functions 4.1.1 - pool * 4.1.3 - internet 4.1.3.1 - NIBE Uplink 4.1.3.8 - tcp/ip settings 4.1.3.9 - proxy settings 4.1.4 - sms * 4.1.5 - SG Ready 4.1.6 - smart price adaption™...

  • Page 42: Menu 5 - Service

    5.11.1.1 - heat pump 5.11.1.2 - charge pump (GP12) 5.12 - country * Accessory needed. Go to the main menu and hold the Back button in for 7 seconds to access the Service menu. Chapter 8 | Control – Menus NIBE VVM 310...
  • Page 43 Factory setting stop temp. lux: 58 °C energy consumption in the event of an alarm. Here you set the start and stop temperature of the hot water for the different comfort options in menu 2.2. NIBE VVM 310 Chapter 8 | Control – Menus...
  • Page 44 Here you set the max. electrical output of the internal elec- Set the operating mode of the heating medium pump here. trical addition in VVM 310 and the fuse size for the installa- auto: The heating medium pump runs according to the cur- tion.
  • Page 45 MENU 5.1.23 - COMPRESSOR CURVE minimum running time Caution Setting range: 0 – 48 h This menu is only displayed if VVM 310 is connec- Default value: 12 h ted to a heat pump with inverter controlled com- pressor. min temp.
  • Page 46 This is to protect against excess temperatures in the for cooling. This setting means that the sub-shunt for the solar tank. extra climate system closes when cooling operation is activ- ated. Chapter 8 | Control – Menus NIBE VVM 310...
  • Page 47 See the accessory installation instructions for function de- for a function description. scription. MENY 5.3.12 - EXHAUST/SUPPLY AIR MODULE months btwn filter alarms Setting range: 1 – 24 Default value: 3 NIBE VVM 310 Chapter 8 | Control – Menus...
  • Page 48 VVM 310. See the Installer Manual for HTS 40 for function description. Caution MENU 5.3.18 - POOL The software in VVM 310 must be software version Here you select which pump to use in the system. 9085 or later. Visit nibeuplink.com and click on the MENU 5.3.19 - ACTIVE COOLING 4 PIPE...
  • Page 49 Factory setting, period 4: 3 days pulses per kWh: Here you set the number of pulses per kWh that are sent to VVM 310. temp. period 1 – 7 Setting range: 15 – 70 °C MENU 5.4 - SOFT IN/OUTPUTS...
  • Page 50 Set the operating mode for the charge pump here. auto: The charge pump runs according to the current oper- ating mode for VVM 310. intermittent: The charge pump starts and stops 20 seconds before, and after, the compressor in the heat pump.

  • Page 51: Service

    Service actions NOTE Servicing should only be carried out by persons with the necessary expertise. When replacing components on VVM 310 only re- placement parts from NIBE may be used. EMERGENCY MODE Emergency mode is used in event of operational interference and in conjunction with service.
  • Page 52 INDOOR CLIMATE HOT WATER starts and you can now follow the progress of the update on the display. When the update is complete VVM 310 re- starts. A software update does not reset the menu set- tings in VVM 310.
  • Page 53 Here you can choose how current measurement values from memory in order to restore them later or to copy the settings VVM 310 should be saved onto a log file on the USB memory. to another VVM 310. Set the desired interval between loggings.

  • Page 54: Disturbances In Comfort

    Disturbances in comfort In most cases, VVM 310 notes a malfunction (a malfunction Caution can lead to disruption in comfort) and indicates this with alarms, and instructions for action, in the display. Selecting "aid mode” is not the same as correcting the problem that caused the alarm.
  • Page 55 Low room temperature • Closed thermostats in several rooms. – VVM 310 does not call on heating, hot water or cooling. – Set the thermostats to max, in as many rooms as pos- • Compressor blocked due to the temperature conditions.

  • Page 56: Electrical Addition Only

    Go to menu 4.2 op. mode. Mark ”add. heat only” using the control knob and then press the OK button. 3. Return to the main menus by pressing the Back button. Chapter 10 | Disturbances in comfort NIBE VVM 310...

  • Page 57: Accessories

    Not all accessories are available on all markets. unit ventilates the house and heats the supply air as neces- ACTIVE COOLING ACS 310* sary. ACS 310 is an accessory that enables VVM 310 to control the pro- ERS 30-400 duction of cooling. ERS S10-400 Part no.

  • Page 58: Technical Data

    Technical data Dimensions Chapter 12 | Technical data NIBE VVM 310...

  • Page 59: Technical Specifications

    Technical specifications 3 x 400 V Electrical data Maximum additional power (internal) Max available heating output from VVM 310 with extra additional heat (for example ELK 15) Maximum connectable external additional heat Rated voltage 400V 3N~50Hz Maximum operating current 19.4...

  • Page 60: Electrical Circuit Diagram

    Electrical circuit diagram 3 X 400 V Chapter 12 | Technical data NIBE VVM 310...
  • Page 61 NIBE VVM 310 Chapter 12 | Technical data...
  • Page 62 Chapter 12 | Technical data NIBE VVM 310...
  • Page 63 NIBE VVM 310 Chapter 12 | Technical data...
  • Page 64 Chapter 12 | Technical data NIBE VVM 310...

  • Page 65: Item Register

    Compatible Air/water heat pumps, 6 OK button, 35 Inspection of the installation, 5 Status lamp, 35 Marking, 4 Switch, 35 Outdoor modules, 6 Disturbances in comfort, 54 Recovery, 5 Alarm, 54 Safety information, 4 Manage alarm, 54 NIBE VVM 310 Item register...
  • Page 66 Power connection, 20 Preparations, 29 Pump speed, 31 Recovery, 5 Removing panels, 8 Removing the cover, base board, 18 Removing the cover, immersion heater circuit board, 18 Removing the hatch, input circuit board, 18 Room sensor, 21 Item register NIBE VVM 310...

  • Page 67: Contact Information

    Tel: +48 (0)85 66 28 490 Hannabadsvägen 5, 285 21 Markaryd Tel. +41 (0)58 252 21 00 biawar.com.pl Tel: +46 (0)433-27 3000 info@nibe.ch info@nibe.se nibe.ch nibe.se For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
  • Page 68 WS release date: 2022-06-28 10:07 Publish date: 2022-09-01 07:29 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
