8x8 4K HDR HDMI Matrix with Audio Breakout
MX-0808-H2A
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
Built-in Web UI for Configuration and Control
Requires connection to LAN (Local Area Network)
Copyright © 2019 WyreStorm Technologies |
MX-0808-H2A Quickstart Guide | 190529
section for important wiring
Router
Ethernet
AC
Mains
HDMI
HDMI
HDR Source
HDR Source
wyrestorm.com
In the Box
1x MX-0808-H2A Matrix
1x AC Power Cord with EU pins
1x AC Power Cord with US pins
1x AC Power Cord with UK pins
1x AC Power Cord with AU pins
1x IR Remote (CR2025 Battery not Included)
1x IR Receiver
2x Matrix Mounting Brackets with screws
1x Quickstart Guide (this document)
Control System
RS-232
Digtial Audio
HDMI
HDR Display
1 of 4
Quickstart Guide
KEY
Passive HDMI
Active HDMI
HDBaseT / Ethernet
Digital Audio
Control
Power
Amplifier
Active HDMI (CAB-HAOC-xx)
Runs of 10m/33ft or more
HDR Display
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
support@wyrestorm.com
MX-0808-H2A
IR Receiver
