User's Manual
LED Module
[Models for indoor use]
LED-FA009i2
LED-FA012i2
LED-FA012i2-SB
LED-FA015i2
LED-FA015i2-SB
LED-FA019i2
LED-FA025i2
LED-FA031i2
LED-FA038i2
MODELS: LED-FA009i2, LED-FA012i2, LED-FA015i2, LED-FA019i2, LED-FA025i2, LED-FA031i2,
LED-FA038i2, LED-FE009i2, LED-FE012i2, LED-FE015i2, LED-FE019i2, LED-FE025i2,
LED-FE031i2, LED-FE038i2
LED-FE009i2
LED-FE012i2
LED-FE015i2
LED-FE019i2
LED-FE025i2
LED-FE031i2
LED-FE038i2
LED-FE012i2-E
LED-FE015i2-E
LED-FE019i2-E

Advertisement

loading
Need help?

Need help?

Do you have a question about the LED-FA009i2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NEC LED-FA009i2

Summary of Contents for NEC LED-FA009i2

  • Page 1 LED Module [Models for indoor use] LED-FA009i2 LED-FE009i2 LED-FA012i2 LED-FE012i2 LED-FA012i2-SB LED-FE015i2 LED-FA015i2 LED-FE019i2 LED-FA015i2-SB LED-FE025i2 LED-FA019i2 LED-FE031i2 LED-FA025i2 LED-FE038i2 LED-FA031i2 LED-FE012i2-E LED-FA038i2 LED-FE015i2-E LED-FE019i2-E MODELS: LED-FA009i2, LED-FA012i2, LED-FA015i2, LED-FA019i2, LED-FA025i2, LED-FA031i2, LED-FA038i2, LED-FE009i2, LED-FE012i2, LED-FE015i2, LED-FE019i2, LED-FE025i2, LED-FE031i2, LED-FE038i2...

  • Page 2: Table Of Contents

    Table of Contents Important Information ..............English-1 Contents ..................English-5 Related Items for Installation ............English-6 Parts Name and Functions ..............English-7 Specifications ................English-10 Diagram ..................English-15 NOTE: (1) The contents of this manual may not be reprinted in part or whole without permission. (2) The contents of this manual are subject to change without notice. (3) Great care has been taken in the preparation of this manual;...

  • Page 3: Important Information

    Important Information Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE LED DISPLAY SYSTEM: About the Symbols To ensure safe and proper use of the product, this manual uses a number of symbols to prevent injury to you and others as well as damage to property.
  • Page 4 ● Be sure to read the following before using the product to use it correctly and safely. WARNING Make sure there are enough people available Do not apply vibrations or shocks to the to ensure safety (at least two people) when product.
  • Page 5 CAUTION Do not use or store the product in the When connecting the power cord to the following places. product’s AC IN terminal, make sure the • Near heaters connector is fully and firmly inserted. • Places with lots of humidity or dust, or Do not damage the power cord.
  • Page 6 Recommended Use & Maintenance About the LED lamps The surface of the pixel card is vulnerable to shocks, so do not press or hit the surface. LED lamps are sensitive to static electricity and surge voltage, which may damage their components and decrease their reliability.

  • Page 7: Contents

    Contents The supplied parts are as follows. In case one of these parts is missing or damaged, contact the retailer. CAUTION Depending on the system you ordered, there is a cabinet without the upper connector. [Cabinet] [Pixel card] Pitches other than 2.5 mm Pitch of 2.5 mm 8 cards per cabinet 4 cards per cabinet...

  • Page 8: Related Items For Installation

    Related Items for Installation The items required when installing the system are shown below. Contact your retailer for more details. [Power cord] To connect the LED module to the power distributor [LAN cable] To connect two LED modules together (120 mm for vertical connection, 135 mm for vertical connection (FA series only), 1000 mm for horizontal connection) [Cabinet alignment bracket] [Screw for Adjustment plates] [Connection screw for LED modules]...

  • Page 9: Parts Name And Functions

    Parts Name and Functions ⑥ ② ④ ⑫ Front Rear ⑪ ⑦ ⑩ ⑧ ① ③ ⑤ ⑨ FA series Name Description Interface connectors Input and output connectors for the signal and AC power. To input the signal from the LED controller or the previous LED module. 12 Signal input/output (master) When a signal is input into 1, the signal is output from 2.
  • Page 10 FE series Name Description Interface connectors Input and output connectors for the signal and AC power. To input the signal from the LED controller or the previous LED module. 12 Signal input/output When a signal is input into 1, the signal is output from 2. When a signal is input into 2, the signal is output from 1.
  • Page 11 There are three types of cabinets. (1) When using other than the top (Type A) The connectors are equipped on the top and bottom sides. There are guide pins on the top. FA series FE series Receiving Power unit2 card Slave Receiving Receiving...

  • Page 12: Specifications

    Specifications LED-FA012i2 LED-FA015i2 LED-FA019i2 LED-FA025i2 LED-FA031i2 LED-FA038i2 LED configuration 3in1 SMD Pixel pitch 1.27 mm 1.58 mm 1.90 mm 2.53 mm 3.17 mm 3.80 mm Number of displayed pixels 480×270 384×216 320×180 240×135 192×108 160×90 (resolution/module) Brightness 800 cd/m 1200 cd/m Contrast ratio 5000:1 7000:1...
  • Page 13 LED-FA012i2-SB LED-FA015i2-SB LED-FA009i2 LED configuration 3in1 SMD Super Black 4in1 SMD (IMD) Pixel pitch 1.27 mm 1.58 mm 0.95 mm Number of displayed pixels 480×270 384×216 640×360 (resolution/module) Brightness 400 cd/m 600 cd/m Contrast ratio 5000:1 Brightness adjustment range 0 to 100% (256 increments) Gamma correction 1.0 to 4.0 (default setting: 2.8)
  • Page 14 LED-FE012i2 LED-FE015i2 LED-FE019i2 LED-FE025i2 LED-FE031i2 LED-FE038i2 LED configuration 3in1 SMD Pixel pitch 1.27 mm 1.58 mm 1.90 mm 2.53 mm 3.17 mm 3.80 mm Number of displayed pixels 480×270 384×216 320×180 240×135 192×108 160×90 (resolution/module) Brightness 700 cd/m 1000 cd/m Contrast ratio 4000:1 5000:1...
  • Page 15 LED-FE009i2 LED configuration 4in1 SMD (IMD) Pixel pitch 0.95 mm Number of displayed pixels 640×360 (resolution/module) Brightness 600 cd/m Contrast ratio 5000:1 Brightness adjustment range 0 to 100% (256 increments) Gamma correction 1.0 to 4.0 (default setting: 2.8) Color temperature 3000 K to 9500 K (default setting: 6500 K) Viewing angle Up 70°, Down 70°, Left 70°, Right 70°...
  • Page 16 LED-FE012i2-E LED-FE015i2-E LED-FE019i2-E LED configuration 3in1 SMD Pixel pitch 1.27 mm 1.58 mm 1.90 mm Number of displayed pixels 480×270 384×216 320×180 (resolution/module) Brightness 600 cd/m Contrast ratio 4000:1 Brightness adjustment range 0 to 100% (256 increments) Gamma correction 1.0 to 4.0 (default setting: 2.8) Color temperature 3000 K to 9500 K (default setting: 6500 K) Viewing angle...

  • Page 17: Diagram

    Diagram LED-FA009i2, LED-FA012i2, LED-FA015i2, LED-FA019i2, LED-FA031i2, LED-FA038i2, LED- FE009i2, LED-FE012i2, LED-FE015i2, LED-FE019i2, LED-FE031i2, LED-FE038i2, LED-FE012i2-E, LED-FE015i2-E, LED-FE019i2-E Rear 4 x M8 18.5 (Unit: mm) English - 15...
  • Page 18 LED-FA025i2, LED-FE025i2 Rear 4 x M8 18.5 (Unit: mm) English - 16...
  • Page 19 Adjustment plate 4-Φ8.5 (Unit: mm) English - 17...
  • Page 20 According to EU directive 2006/66/EC and amendments, the battery can’t be disposed improperly. The battery shall be separated to collect by local service. Service & Support in Europe Please contact: Sharp NEC Display Solutions Europe GmbH. Landshuter Allee 12-14, D-80637 München Phone: + 49 (0) 89/99699-0...
