Altronix TROVE T1RAL3F8D Installation Manual

Access & Power Integration
Altronix Rack Kits
Models Include:
T1RAL3F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
Altronix backplane (TAL1R)
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output
Power Distribution Module
- (1) ACMS8 - Fused Dual Output
Access Power Controller
T1RAL33F16
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
Altronix backplane (TAL1R)
- (2) eFlow6NB - Power Supply/Chargers
- (2) ACMS8 - Fused Dual Output
Access Power Controllers
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
Rev. T1RAL111518
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
T1RAL3F8D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
Altronix backplane (TAL1R)
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8CB - PTC Dual Output
Power Distribution Module
- (1) ACMS8CB - PTC Dual Output
Access Power Controller
T1RAL33F16D
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
Altronix backplane (TAL1R)
- (2) eFlow6NB - Power Supply/Chargers
- (2) ACMS8CB - PTC Dual Output
Access Power Controllers
